  1. COS 318 - Operating System Fall 2004 Assignment 2Non-preemptive scheduling

  2. Main things you need to deal with Process Control Block (PCB) Context Switch procedure System Call mechanism Stacks Synchronization Inline assembly Design review requirements

  3. Process Control Block (PCB) File: kernel.h What should be in the PCB? pid, in_kernel, stack? next, previous What else should goes in PCB? Design review.

  4. Context Switch Procedure How to switch between processes and threads? They must call yield() explicitly. Time slice expires. (Preemptive, next assignment) Where to save it? Stack? PCB.

  5. System Call Mechanism How does a process get services from the kernel? This assignment: special function call - a “jump table” Real stuff: Interrupt/trap mechanism (later assignments)

  6. System Call Mechanism (continued) At runtime, load the address of kernel_entry() into memory location 0xf00. How to do that? Define this #define ENTRY_POINT (void(**)(int))0xf00 Declare the following in syslib.c void (**entry_point)(int)=ENTRY_POINT To load *entry_point = kernel_entry

  7. System Call Mechanism (continued) The following diagram shows the kernel_entry in the memory 0x1000 0xf00 kernel_entry()

  8. Stacks How many stacks? 2 per process, 1 pre thread. Why? Where to put them in memory? Upper limit: 640K (= 0xa0000) Suggestion: between 0x10000 and 0x20000 See memory layout on the next slide Size of each stack: 4KB should be fine.

  9. Memory Layout BIOS Kernel and Processes Bootblock Stacks Video RAM 0x01000 0x07C00 0xA0000 0xB8000

  10. Synchronization Locks are used by threads Many threads can try to acquire a lock Need to maintain queue of threads waiting for a lock. (where?) Lock_acquire() 1. Check lock 2. Get lock? Great! 3. If not, block itself Lock_init(), Lock_release()

  11. Inline Assembly See guide on course page http://linuxassembly.org/resources.html http://linuxassembly.org/articles/rmiyagi-inline-asm.txt ask google. Ask us. To access a C variable in inline assembly asm volatile(“statements”:output_regs:input_regs:used_regs); Examples asm volatile(“movl %%esp,%0”:”=q”(cur_running->stack)); asm volatile(“movl %0,%%esp”::”q”(cur_running->stack));

  12. Design Review • Process Control Block (PCB) • Whats in it ? • Context Switch procedure • System Call mechanism • Stacks • Synchronization • How are locks implemented ? • Will put up detailed grading scheme soon (tomorrow?)

  13. Some more hints for this assignment1. Flat Address Space The bootblock code switches to protected mode. It also sets up the CS, DS, and other segment registers so that you can use the entire memory using just registers like eax. Do NOT modify the segment registers. You have access to the first 1MB of memory which includes the video-memory area(0xB8000). To be safe make sure your code, data, and stacks reside within the first 640KB of memory.

  14. Some more hints for this assignment2. Synchronization The synchronization primitives can only be used by threads within the kernel. You will notice that there are two functions block() and unblock() in the kernel that are to be used by the synchronization code. This has been done since blocking a process is not specific to locks, but is a general purpose service that the kernel should support.
