End to End Internet Packet Dynamics Vern Paxson University of California, Berkeley Presented by Kiran Komaravolu
End to End characteristics of Internet paths. • Network Pathologies • Out of order delivery • Packet replication • Packet corruption • Bottleneck Bandwidth • Packet Loss • Loss rates • Data vs. Ack loss • Loss Bursts • TCP retransmission • Packet Delays
Out of Order Delivery • Out of order delivery is fairly prevalent • Re-ordering is asymmetric • Route-Fluttering • Site-dependant • Impact of re-ordering is not very significant.
Packet Replication • Not very common. • Link level retransmissions are one main reason. • Packet Corruption. • Evidence suggests data packet corruption rate of 0.02%. • Pure acks less prone to packet corruption. • TCP provides a 16-bit checksum. Thus it can lose 1 in 65,536 packets to errors. • On average 65,536 x 5000 = 300 million packets will cause an bad packet to be accepted. Paxson argues this is too high.
Bottleneck bandwidth • Self-interference time constant • Qb = packet size / bottleneck bandwidth. • Packet pair Algorithm. • Two packets are sent with interval Δts < Qb. • When they arrive at receiver Δtr = Qb. • ICMP echo packets could be used to measure bandwidth with this idea. • Difficulties • Out of order delivery • Clock resolution limitation • Change in Bottleneck bandwidth • Multichannel links
Packet Loss • Loss rates doubled in 1995 (from 2.7% to 5.2 %) • Bigger windows do not make any impact on Loss rates. • Loaded and Unloaded pkts • Loaded pkts are those which had to wait for a pending transmission to complete. • About 2/3rd of all packets are loaded. • Loaded packets are more prone to be lost. • Acks are more prone to be lost than unloaded pkts. • Packet loss maybe asymmetric.
Packet loss • Losses occur in bursts. • TCP retransmissions • Transmitting TCP may retransmit unnecessarily • Because all acks were lost. • Coarse feedback, sequence “holes” not known to sender. • Timed out too early. • Significant portion of retransmissions are “redundant”.
Packet Delays • Timing Compression • Timing Compression occurs when a flight (burst) of packets sent over a period Ts arrives at the receiver over an interval Tr and Tr < Ts. • Zhang et al predicted that ack compression could occur is a flight arrives at a router and faces no cross traffic. (router is under-utilised) • E = (Tr + Cr) / (Ts – Cs) • Group is compressed if E < 0.75. • Most connections experience at least one compression event. • Ack compression occurs more often for dup-acks. (they are sent with less spacing between them.)
Packet Delays • Compressed acks advance sender TCP window at a faster rate. May lead to network stress. • Bandwidth measurement techniques would fail with ack compression. • Data Packet Timing Compression • Can occur due to sudden advance in receiver advertised window. • Bottleneck will spread out the packets. • Packets “may” still be compressed after the bottleneck. • Data pkt timing compression is rarer than ack compression.
Available Bandwidth • B = (N/W resources used by the connection/ (resources it used) + (resources competitors use). • B is a figurative expression for available bandwidth. B = 1 means entire bottleneck was available. • Internet connections have been found to encounter a broad range of available bandwidth.
