  1. Imagine

  2. SENIOR PROJECTWireless Weather MonitorFinal Presentation • Project Team • Dale McClure • Dave McHugh • Joe Russo

  3. Project Results • Project Schedule • On Time • On Budget • Minimal Setbacks • Team Motto

  4. SCHEDULE

  5. Project Components Rx Tx

  6. RF Components • Laipac Tech Inc. - Holtec Semiconductor Agent • Series LP 434@433.92MHz Components

  7. Project Components • Transmitter Section • Temperature Sensor – National Semi LM34 • Humidity Sensor – Honeywell 3610 • Motorola 68HC11 Microcontroller • Power Supply – 9V Alkaline cell • Voltage Regulation – MC7805 for 5 Volt Operation • Laipac Tx #TLP – 434 @ 433.92 MHz

  8. Tx Section with Sensor Array 9V battery Temp Sensor Humidity Sensor RF Transmitter Op-Amps Motorola CME11E9-EVBU

  9. Tx Section with Case Enclosure RS-232 Port LED Power On Indicator On-Off Switch 50 Ohm Collapsible Antenna Ventilation Holes for air Transfer

  10. Humidity Sensor • Honeywell 3610 Humidity sensor • Linear output voltage vs % RH • Given a 5v supply Voltage output is 0.8 – 3.9 volts • Motorola MC3303 single supply op-amps

  11. Temperature Sensor • National Semiconductors LM34 Temperature sensor • Linear +10.0 mV/°F scale factor • Rated for full -50° to +300°F range • Motorola MC3303 single supply op-amps

  12. Project Components • Receiver Section • Laipac Rx #RLP – 434@433.92 MHz • Motorola 68HC11 Microcontroller • OPTREX LCD Screen • ACT 5x5 keypad • Power Supply – 9V Alkaline cell • Voltage Regulation – MC7805 for 5 Volt Operation

  13. On-Off Switch Rx Section LED Power On Indicator LCD display for Sensor Outputs Keypad for choosing Sensor information and Future Options Shock Resistant Enclosure

  14. Rx Section Motorola CME11E9-EVBU RS-232 Port AC/DC Variable Power Supply Keypad Driver RF Receiver

  15. Software Bugs Addressed • Serial Connection for Tx and Rx • Sensor Code Conversion • Sensor Calibrations • LCD Display • Modulation Type

  16. The Wireless Weather Monitor is Assembled in State of the Art Facilities by Highly Trained Personnel
