Presentation Transcript


Slide1 l.jpg

30 Years of

Measuring Machines

30 Years of

Measuring Machines


Company history l.jpg

Company history

Coord3 was established in 1973.The company mission was the manufacturing of marking-out machines for the automotivetool makers.


Company history3 l.jpg

Company history

  • Throughout 70’s and 80’s more than 400 machines of this kind were built and installed.

In the late 80’s the range was enhanced to include different architectures of machines: bridge, gantry, horizontal.


Company history4 l.jpg

Company history

  • In 1992 Coord3 was one of the first makers to develop a Windows™ based CMM software for manual and CNC machines.


Recent facts l.jpg

Recent facts

  • 1999: new shareholders contribute with financing and management with the vision of an accelerated growth path for the company.


The growth l.jpg

The growth

  • Priorities:

  • Brand visibility

  • Local presence

  • Product development


Now coord3 has l.jpg

Now Coord3 has…

Style...

A new

  • Support

Machines

...new

Control

…a new

Software

...new

enhanced local

...and

Certified Quality System

UNI EN ISO 9001:2000


And also l.jpg

…and also…

  • Coord3 is a SIT (Italian Calibration Institute) centre

  • qualified to execute performance tests ofCMMs according to ISO 10360-2 standard,being guaranteed:

  • the reference of the measurements to theNational Masters

  • the evaluation of the uncertainties of the measurements

  • the repeatability and reproducibility of the results

  • the compliance of the data output with the SIT standard


Direct distribution support in italy l.jpg

Direct distribution & supportin Italy…

Torino

Milano

Verona

Pistoia

Bari


And in the world l.jpg

BRANCHES

DISTRIBUTORS

… and in the World

Coord3 Beijing

Coord3 Brasil


Sales main sectors recent major customers l.jpg

Sales: Main Sectors& Recent Major Customers

AUTOMOTIVE INDUSTRY

ALFA LANCIA INDUSTRIALE

AUDI/VOLKSWAGEN

BMW

BOSCH

CAGIVA CENTRO RICERCHE

CAGIVA MOTOR

CARROZZERIA BERTONE

CENTRO RICERCHE FIAT

DONGFENG MOTOR CORP.

EATON

FAGCC

FASA-RENAULT

FAW HAINAN

FIAT AUTO

FORD

IVECO

KARMAN STAMPOSTECH

LEAR CORPORATION

MAGNETI MARELLI

PIAGGIO

PININFARINA INDUSTRIE

POLMO KALISZ

RENAULT DO BRASIL

TELCO

TRW AIR BAG SYSTEMS

UTIL INDUSTRIES

VOLKSWAGEN

ZDAS

GENERAL MECHANICAL INDUSTRY

COMAU

FATA ALUMINIUM

DALMINE

JOBS

S.C.M. GROUP

CHARMILLES TECHNOLOGIE

MAKINO

AMADA LTD.

CATERPILLAR

AEROSPACE

ALENIA

G. AGUSTA

FIAT AVIAZIONE

MATRA MARCONI SPACE

STAMPING

EMARC

LAMIER

M.A.C.

KIKUCHI

STYLING CENTRES

BERTONE

IDEA

ITALDESIGN

LANDRA

PININFARINA

STOLA

RANGER ITALIANA

ALLGAIER WERKE

HI-TECH MOLD

TEXTRON AUTOMOTIVE

OTHERS

FERROVIE DELLO STATO

SAFILO

ENEA BRASIMONE

NUOVO PIGNONE

WHIRLPOOL EUROPE

KRYPTON ELECTRONIC ENG.

EROWA VERTRIEBS

SWAROVSKY CRISTALLERIA

N. 39 RESEARCH INSTITUTE


A new coord3 l.jpg

A new Coord3


Domestic export market value l.jpg

2004 (BUDGET)

export

domestic

2003

export

domestic

2000

export

domestic

domestic/export market(value)


Coord3 employees l.jpg

Employees

Years

Coord3 employees


Coord3 sales l.jpg

millions of Euro

Years

Coord3 Sales


Product overview l.jpg

Product overview

Machines


Slide17 l.jpg

EOS

  • Half-bridge type CMM

  • Full aluminum technology design

  • Manual or motorized

  • Travel range

  • X 500 mmY 400 mmZ 400 mm

  • Accuracy2.5 + 3.0 L µm

  • 3D speed0.52 m/s


Slide18 l.jpg

ARES

  • Bridge type CMM

  • Aluminum movable structure

  • Base in granite

  • Manual or motorized

  • Travel rangeX from 700 to 1400 mmY from 550 to 650 mmZ from 400 to 500 mm

  • Accuracy3.0 + 3.5L µm

  • 3D speed0.52 m/s


Slide19 l.jpg

AXIA

  • Bridge type CMM

  • Aluminum movable structure

  • Base in granite

  • Integrated Numeric Control

  • Travel rangeX from 700 to 1200 mmY from 600 to 700 mmZ from 550 to 650 mm

  • Accuracyfrom 1.9 + 2.5L µm

  • 3D speed0.87 m/s


Slide20 l.jpg

HERA

  • Bridge type CMM

  • Aluminum movable structure

  • Base in granite

  • Travel rangeX from 1200 to 2400 mmY from 850 to 1000 mmZ from 700 to 1000 mm

  • Accuracyfrom 2.5 + 3.5L µm

  • 3D speed0.75 m/s


Kronos l.jpg

KRONOS

  • Bridge type CMM

  • Aluminum movable structure

  • Base in granite

  • Travel rangeX from 1500 to 3000 mmY from 1300 to 1500 mmZ from 1000 to 1300 mm

  • Accuracyfrom 3.7+4.0L µm

  • 3D speed0.66 m/s


Athena l.jpg

ATHENA

  • Gantry CMM

  • Aluminum movable structure

  • Protected guideways by appropriate bellows

  • Travel rangeX from 3000 to 5000 mmY from 2000 to 2500 mmZ from 1000 to 1500 mm

  • Accuracyfrom 6 + 6 L µm

  • 3D speed0.66 m/s


Mct starlight l.jpg

MCT Starlight

  • Gantry CMM

  • Manual or motorized

  • Monolithic version

  • Travel rangeX from 2500 to 6000 mmY from 1500 to 2500 mmZ from 1000 to 2000 mm

  • Accuracyfrom 5.0+5.0L µm

  • 3D speed0.60 m/s


Mct plus l.jpg

MCT Plus

  • Gantry CMM

  • Large working volume

  • High accuracy

  • Travel rangeX from 5000 to 12000 mmY from 2500 to 3500 mmZ from 2000 to 2500 mm

  • Accuracyfrom 7.0+ 8.0L µm

  • 3D speed0.53 m/s


Swan l l.jpg

SWAN L

  • Horizontal ram CMM

  • Aluminum movable structure

  • Lateral air bearing guideway integrated with the plane

  • Travel rangeX from 2000 to 6000 mmY from 1000 to 1500 mmZ from 1200 to 2000 mm

  • Accuracyfrom 10+15L µm

  • 3D speed0.52 m/s


Swan si l.jpg

SWAN SI

  • Horizontal ram CMM

  • Aluminum movable structure

  • Independent guideway

  • Travel rangeX from 3000 to 6000 mmY from 1000 to 1500 mmZ from 1200 to 2000 mm

  • Accuracyfrom 10+15L µm

  • 3D speed0.52 m/s


Jupiter l.jpg

JUPITER

  • Horizontal ram CMM

  • Aluminum movable structure

  • Independent guideway

  • Travel rangeX from 5000 to 8000 mmY from 1400 to 1600 mmZ from 2000 to 3000 mm

  • Accuracyfrom 14 + 14 L µm

  • 3D speed0.58 m/s


Slide28 l.jpg

ECHO

  • Portable Measuring System

  • Six completely balanced axes

  • Wide range of accessories

  • Measuring rangefrom 1500 to 4000 mm

  • Single point accuracy (2)from 0.026 mm

  • Single point accuracy (E Max)from 0.036 mm


Special and customized products l.jpg

Special and customized products

  • MAGAM

    Flush & gap measurement


Cc3 proprietary cnc l.jpg

CC3 proprietary CNC

  • Optimized installation layout

  • Easily upgradeable also after installation

  • Last generation CPU, it can perform 180 millions operations per second in floating point

  • Ruggedized components


Product overview31 l.jpg

Product overview

Software


Software offer l.jpg

TM

www.metrologic.fr

www.delcam.it

www.mirai.it

SurferNT

Software offer

  • Coord3 offers a wide selection of metrology software packages in order to support specific customer’s needs.


Arco family l.jpg

ARCO family

  • The new measuring softwarePowerful,User-friendly,Modular

  • Measuring software based on DMIS language

  • It measures prismatic elements, edges and free surfaces

  • Direct Import of PRO-E, CATIA V4, CATIA V5, UNIGRAPHIC, IGES, VDA, DXF

  • Available for manual, point-to-point and continuous scanning measurement

  • The inspection and reverse engineering of profile is very fast

  • Powered by strong tools for graphic programming

  • The flexible module for graphical output allows to create custom reports

  • Graphical results output in QS-STAT and SPC LIGHT, HTML, PDF, MS-WORD, MS-EXCEL, TIFF

  • Use of dual arm measuring system extremely powerful

  • Easy integration of custom components


Arco family34 l.jpg

ARCO family

  • ARCO Quick is the entry level software to measure prismatic elements with the self-teach tools and non CAD-based advanced programming.

  • ARCOQuick fully supports DMIS language in native mode: the portability of the programs created with ARCO is guaranteed

  • The programs in DMIS format are generated automatically by the system during the measurement of the first part

  • The calibration Wizard makes probe qualification quick and efficient, even with unconventional styli and stars tips, regardless of the angular position of the motorized head

  • ARCOQuickallows to create a reference system either in a traditional way or through dedicated procedures

  • Automatic cycles are available to measure elements

  • ARCOQuickhandles the geometrical tolerances in accordance with the international standards

  • The use of the tool changer management is transparent to the operator because it is integrated in probe management

  • The output is available in HTML and in graphical format


Arco family35 l.jpg

ARCO family

ARCO Graphics adds graphics tools to the power of ARCO Quick: the geometrical elements are displayed in a dedicated area and the use of visual selection helps the operator to quickly choose what to use in the measurements.

  • ARCO Graphics allows machine volume and probe representation. The probe is represented, by size and direction, in the actual position within the machine volume and its movement is updated in real time.

  • Graphical representation of the measured geometrical elements

  • Graphical GOTO: on motorized machines it is possible to create the probe positions from the graphic environment

  • Representation of Form Errors: the geometrical elements can be monitor while programming, bad points can be graphically excluded from the calculation in order to realize a better inspection

  • During the creation of the reference systems it is possible to preview them

  • On motorized machines it is possible to pre-define measuring paths (strategies) on geometrical elements


Arco family36 l.jpg

ARCO family

ARCO Cad , due to a powerful CAD engine, completes ARCO Quick and ARCO Graphics features. It is possible to import the CAD models of parts and build the programs with the graphical tools and the measurement of complex surfaces.

  • Direct import of the most used CAD formats: CATIA V4, CATIA V5, PRO-E, UG and the neutral IGES, VDA and DXF formats

  • Complete Layer CAD management, group management andgeometrical elements extraction from CAD

  • On motorized machines it is possible to teach the point to be picked by selecting the point directly on the mathematical model

  • Through the use of the CAD model it is possible to create reference systems on free forms

  • Measuring surfaces and edges in real time. Measuring, creating and exporting profiles. Optimization of an existing reference

  • Graphical outputs available in fully customizable format
