Instruction set design


Jehan-François Pâris

Chapter organization

Chapter Organization

  • General Overview

    • Objectives

    • Realizations

  • The MIPS instruction set



  • The instruction set of a processor is its interface with the outside world

    • Defined by the hardware

    • Used by assemblers, compilers and interpreters

  • Remained very visible to the users up to the 80’s

    • Earlier PC programs were written in assembler

General overview


Common features

Common features

  • A machine instruction normally consists of

    • An operation code

    • One, two or three operand addresses

    • Various flags

  • Some operands can be immediate

    • Address field contains the value of the operand instead of its address

Common features1

Common features

  • One or more operands can be in high-speed registers

    • Dedicated registers:

      • Very old solution

      • Register address can be specified in the opcode

    • General purpose registers

Common features2

Common features

  • Memory operand addresses are represented in a compact form

    • Base + displacement:

      • The address is specified by the contents of a base register plus a displacement

        • Saves space because displacement is generally small



  • IS should be

    • Expressive:

      • Powerful instructions

    • Designed for speed:

      • Should be able to run fast and allow extensive prefetching

    • Compact:

      • Faster fetches from disk and from main memory



  • User friendly:

    • Very important when people were expected to program is assembler

      • Manufacturers loved that because

        • Instruction sets were mostly proprietary:IBM 360/370 was the exception

        • Programs could not be ported to a different architecture

The story of gene amdahl

The story of Gene Amdahl

  • Raised on a farm without electricity until he went to high school

  • PhD from U Wisconsin-Madison

  • Became one of the top architects of the IBM/360 series

  • Had his next design rejected by IBM

  • Started his own company (Amdahl ) building big mainframes and selling them at a much lower cost than comparable IBM machines

How could they do that ii

How could they do that? (II)

  • Amdahl could undersell IBM by focusing on larger "mainframes"

  • Andahl's computers were air-cooled while IBM's water-cooled

    • "[D]ecreased installation costs by $50,000 to $250,000."


How could they do that i

How could they do that? (I)

  • IBM 360 series was first series of computers with

    • Very different capacities

    • Same instruction set

  • IBM pricing policy was keeping computer prices proportional to their capacity

    • Did not reflect proportionally lower manufacturing cost of high-end machines

The end of the story

The end of the story

  • Left Amdahl in 1979 to pursue unsuccessfully several ventures

  • Amdahl Computers is now part of Fujitsu and focuses on services

Inherent conflicts

Inherent conflicts

  • Expressiveness vs. Speed

    • CISC instructions were powerful but microcoded

  • Compactness vs. Speed

    • Many instruction sets had instructions of different length

    • Cannot know start of next instruction before decoding the opcode of current one

What is microcode

What is microcode?

  • Some machine language below the instruction set

    • Invisible to the programmer/compiler

    • Each instruction corresponded to one or more microinstructions

    • Some architectures allowed the user to program new instructions or a whole new instruction set

An example ibm 360 370

AN EXAMPLE: IBM 360/370/…

The 360 architecture i

The 360 architecture (I)

  • Developed in the 60’s but kept almost unchanged for 30+ years

  • Thirty-two bit words and 8-bit bytes

  • Memory was byte-addressable

    • Had 24-bit addresses restricting main memory size to 16 MB (enormous at that time!)

    • Later extended to 32 then 64 bits

The 360 architecture ii

The 360 architecture (II)

  • Instruction set included

    • 32-bit operations for scientific and engineering computing (FORTRAN)

    • Byte-oriented operations for character processing and decimal arithmetic then judged essential for business applications

  • Name of series referred to wide range of applications that could run on the machine

Ibm 360 instruction set i




IBM 360 instruction set (I)

  • Had multiple instructions formats all with

    • Mostly 8-bit opcodes

    • 16 general purpose registers

  • RR (register to register)

    • 16 bits

Ibm 360 instruction set ii






IBM 360 instruction set (II)

  • RX (register to/from indexed storage)

    • 32 bits

    • Address of memory operand was:contents of base and index registers plus12-bit displacement D

Ibm 360 instruction set iii





IBM 360 instruction set (III)

  • SI ( storage and immediate)

    • 32 bits

    • Has an 8-bit wide immediate field I

    • Address of memory operand was:contents of base register B plus12-bit displacement D

Ibm 360 instruction set iv







IBM 360 instruction set (IV)

  • SS ( storage to storage)

    • 48 bits

    • Two memory operands

      • First addresses offields of length L

Ibm 360 instruction set v




IBM 360 instruction set (V)

  • S ( storage )

    • 32 bits with a 16-bit opcode

    • Mostly for privileged instructions

Discussion i

Discussion (I)

  • Flexible and compact

    • Multiple instruction sizes

      • Must decode current instruction to know start of the next one

  • Regular design

  • Many operations can be RR, RS, RX, SI and SS (character manipulation and decimal arithmetic)

Discussion ii

Discussion (II)

  • RX format:

    • Memory address is indexed by base register and index register

      • a[i] can be decomposed into

        • Current base register

        • Offset of a[0] relative to base register

        • Index i multiplied by size of array element in index register

Discussion iii

Discussion (III)

  • Why such a complex addressing format?

    • Index register was used to access arrays

    • Base register allowed for a much shorter address field

      • 4 bits for base register + 12 bits for displacement


      • 24 bits for a full address

The mips instruction set


Mips i


  • Originally stood for Microprocessor without Interlocked Pipeline Stages

  • First RISC microprocessor

  • Development started in 1981 under John Hennessy at Stanford University

  • Started a company:MIPS Computer Systems, Inc.

Mips ii


  • Owned by SGI from 1992 to 1998

    • Until SGI switched to the Intel Itanium architecture

  • Used by used by DEC, NEC, Pyramid Technology, Siemens Nixdorf, Tandem and others during the late 80s and 90s

    • Until Intel Pentium took over

  • Now primarily used in embedded systems



  • Two versions

    • MIPS32 with 32-bit addresses (discussed here)

    • MIPS64 with 64-bit addresses

  • Both MIPS architectures have

    • Thirty-two registers (32 bits on MIPS 32)

    • A byte-addressable memory

    • Byte, half-word and word-oriented operations

Bit ordering

Bit ordering

  • All examples assume that byte-ordering islittle-endian:

    • Bits are numbered from right to left



Number representation i

Number representation (I)

  • MIPS uses two’s complement representation for negative numbers:

    • 00….0 represents 0

    • 00….1 represents 1

    • 01….1 represents 2n–1 – 1

    • 10….0 represents – 2n–1

    • 11….1 represents – 1

Two complement representation

Two-complement representation

  • Assume n-bit integers

    • All positive integers have first bit equal to zero

    • All negative integers have first bit equal to one

  • To negate an integer, we compute its complement to 2n in unsigned arithmetic



  • Assume n = 4

    • 0000, 0001, 0010, 0011, 0100, 0101, 0110 and 0111 represent integers 0 to 7

    • To find the representation of -3, we do

      • 16 -3 = 13, that is, 1101

    • More generally 1000, 1001, 1010, 1011, 1100, 1101, 1110, 1111 represent negative integers -8 to -1

Another way to look at it i

Another way to look at it (I)

Another way to look at it ii

Another way to look at it (II)

Number representation ii

all zeroes


all ones


Number representation (II)

  • Can create problems when we fetch a byte or half-word into a 32 bit register

  • If we fetch the 16-bit half-word

  • we have two possible outcomes




Mips instruction set

MIPS instruction set

  • Designed for speed and prefetching ease

  • All instructions are 32-bit long

    • Five instruction formats

      • Three basic formats

        • R, I and J

      • Two floating point formats

        • FR and FJ

The r format







The R format

  • Six-bit opcode

  • R instructions have three operands

    • Five bits per register 32 registers

  • Shamt specifies a shift amount (5 bits)

  • Funct selects the specific variant of operation defined in opcode (6 bits)

    • Many R instructions have an all-zero opcode

Register naming conventions

Register naming conventions

  • $s0, $s1, …, $s7 for saved registers

    • Saved when we do a procedure call

  • $t0, …, $t9 for temporary registers

    • Not saved when you do a procedure call

  • $0 is the zero register:

    • Always contains zeroes

  • Other conventions are used for registers used in procedures calls

R format instructions i

R format instructions (I)

  • Arithmetic instructions

    • add $sa, $sb, $sc# a = b + c;

    • sub $sd, $se, $sf# d = e – f;

  • Logical instructions

    • and $sa, $sb, $sc# a = b & c;

    • or $sd, $se, $sf# d = e | f;

    • nor $sg, $sh, $si# g = ~(h | i);

    • xor $sj, $sk, $sl# j = (k&~l)|(~k&l)



  • MIPS logical instructions are bitwise operations

    • Implement bitwise & and I operations of C

  • MIPS has no negation instructions

    • Use NOR and specify register $0 as one of the two input registers

      • $0 is hard-wired to contain zero

    • nor $sk, $sl, $0# k = ~l;

R format instructions ii

R format instructions (II)

  • More arithmetic instructions

    • addu $s1, $s2, $s3

    • subu $s1, $s2, $s3

    • Unsigned versions of add and sub

    • Multiply and divide instructions will be covered later

R format instructions iii

R format instructions (III)

  • Shift instructions

    • sll $s1, $s0, n

    • slr $s1, $s0, n

  • Shift contents of source register $s0 by n bits to the left (sll) or to the right (slr)

  • Fill the emptied bits with zero

  • Store results in destination register $s1

Notes ii

Notes (II)

  • A right shift followed by a logical and can be used to extract some specific bits

  • If we are interested in bits 14-15 of register $s0

    • We set up a register $s2 containing 011two

    • We do

      • slr $t0, $s0, 14 # use temporary register $t0

      • and $s1, $t0, $s2 # answer is in $s1

Notes iii

Notes (III)

  • Want to extract bits XY in positions 14 and 15

  • slr $t0, $s0,15

  • and $s1, $t0, $s2 # $s2 contains mask 011




R format instructions iv

R format instructions (IV)

  • Register comparison instructions

    • slt $t0, $s3, $s4

    • sltu $t0, $s3, $s4

  • Sets register $t0 to 1 if $s3 < $s4and to 0 otherwise

    • slt does a signed comparison

    • sltu does an unsigned comparison

R format instructions iv1

R format instructions (IV)

for big jumps

  • Jump instructions

    • jr $s0

      • Jump to address contained in register $s0

      • Since $s0 can contain a 32-bit address, the jump can go anywhere

    • jalr $s0, $s1

      • Jump to address contained in register $s0 and save address of next instruction in register $s1 (defaults to register 31)

The i format




The I format


  • Last field can be

    • a 16-bit displacement:Address of memory operand is the sum of the contents of register rt and this displacement

    • a 16-bit constant:Register rt can then specify a second register operand



  • I format contains instructions involving

    • One register and a memory location

    • Two registers and an immediate value

    • Two registers and a jump address relative to the current value of the program counter (PC)

  • MIPS instruction set uses the same format for three very different instruction styles

    • Simplifies decoding hardware

Register and memory instructions

Register and memory instructions

  • Transfer data

    • To a register: load

    • From a register: store

  • No arithmetic instructions as in the IBM/360 IS

    • All arithmetic and logical operations are either register to register or immediate to register

Register and memory instructions1

Register and memory instructions

  • Load instructions

    • lbu $s1, a($s2)

      • Load unsigned byte into register $s1 from memory address obtained by adding the contents of register $s2 to theaddress field a

    • lbhu $s1, a($s2)

      • Load half-word unsigned

Register and memory instructions2

Register and memory instructions

  • Load instructions (cont’d)

    • lw $s1, a($s2)

      • Load word unsigned

    • ll $t1, a($s2)

      • Load linked: used with store conditional to implement atomic locks

        • The famous spinlocks

Wait for COSC 4330

Register and memory instructions3

Register and memory instructions

  • Store instructions

    • sb $s1, a($s2)

      • Store least significant byte

    • sbh $s1, a($s2)

      • Store least significant half-word

    • sw $s1, a($s2)

      • Store word

Register and memory instructions4

Register and memory instructions

  • Store instructions (cont’d)

    • sc $t1, a($s2)

      • Store conditional

        • Always follows a load linked

        • Fails if value in memory changes since the load linked instruction

        • Saves contents of $t1 in memory and sets $t1 to one if store conditional succeeds or to zero otherwise

Wait for COSC 4330

Immediate instructions

Immediate instructions

  • Immediate value is 16-bit wide

  • addi $1, $2, n

    • Store in register $s0 the sum of the contents of register $s1 and the decimal value n

  • addiu $1, $2, n

    • Unsigned version of addi

  • andi $1, $2, n

  • ori $1, $2, n

Three missing instructions

Three missing instructions

  • No subi or subiu

    • Instead of subtracting an immediate value nwe can add a negative value –n

  • No load immediate

    • Replaced by ori with a zero value

    • ori $s0, $0, n # load value n into register $s0

↑ Typo in textbook?

Loading 32 bit constants i

16 MSB

16 LSB

Loading 32-bit constants (I)

  • lui $s0, n

    • load upper immediate

    • Loads the decimal value n into the 16 most significant bits of register $s0

lui $s0, n

Loading 32 bit constants i1

lui $s0, m

ori $s0, #0, n

16 MSB

16 LSB

Loading 32-bit constants (I)

  • Works in combination with ori

Other immediate instructions

Other immediate instructions

  • Comparison instructions

    • slti $t0, $s3, n

    • sltui $t0, $s3, n

    • Both set register $t0

      • To one if $s3 < sign extended value of n

      • To zero otherwise

    • slti does a signed comparison

    • sltui does an unsigned comparison



  • We should use immediate instructions whenever possible

    • They are faster and use one register less than the equivalent R instructions

      • To isolate bits 14-15 of register $s0, use

        • slr $t0, $s0, 14

        • and $s1, $t0, 3 # decimal 3 = binary 011

Immediate branch instructions i

Immediate branch instructions (I)

  • All immediate jump and branch instructions use a very specificaddressing scheme

    • Use the program counter as base register

      • Makes sense

      • Both register fields can be used for conditional branch instructions

Immediate branch instructions ii

Immediate branch instructions (II)

  • Immediate field contains a signed number

    • Can jump ahead or behind the address indicated by the current value of the PC + 4

  • Address is multiplied by four before being added to the value of the PC

New PC = Old PC + 4 + 4×n

Why pc 4

Why PC + 4

  • Because

    • By the time the MIPS CPU adds 4×nto the PC register, it will contain the address of the next instruction

Immediate branch instructions iii

Immediate branch instructions (III)

  • Works well because

    • PC value is a multiple of four as instructions are properly aligned at addresses that are multiple of 4

    • Solution extends the range of the jump from  215 B = 32 KB to  217 B = 128 KB

  • can use J or JR for bigger jumps

Immediate branch instructions iv

Immediate branch instructions (IV)

  • beq $s0, $1 a

    • Branch on equal

    • Jump to address computed by adding 4×a to the current value of the PC + 4 if the values of registers $s0 and $s1 are equal

  • bne $s0, $1 a

    • Branch on not equal

The j format i





The J format (I)

  • Sole operand is a 26-bit address

  • Jump instructions

    • j a

      • Unconditionally jump to a new address

    • jal a

      • Unconditionally jump to a new address and store address of next instruction in $ra

The j format i1





The J format (I)

  • Note that jalhas animplicit operand

    • Register$ra (stands forreturn address)

      • Always register 31

  • In general, implicit operands

    • Allow more compact instruction formats

    • Complicate register management

Computing the new address

Computing the new address

  • Obtained as follows

    • Bits 1:0 are zero (address is multiple of 4)

    • Bits 28:2 come from jump operand (26 bits)

    • Bits 31:29 come from PC+4

Allows to jump to anywhere in memory



  • The overall philosophy used to design the MIPS instruction set was

    • Favor simplicity and regularity

      • Only three instruction formats

    • Optimize for the more frequent cases

      • Immediate to register instructions

    • Make good compromises

Comparison with ibm 360 is

IBM 360

Variable length instructions

Sixteen GP registers

RR format has two register operands

RS format

SI format

SS format


Fixed-size instructions

Thirty-two GP registers

R format has three register operands

An option of I format

No, but the equivalent of a non-existing RI format

No equivalent

Comparison with IBM 360 IS

The stack

The stack

  • Used to store saved registers

  • LIFO structure starting at a high address value and growing downwards

  • MIPS software reserves register 29 for the stack pointer ($sp)

  • We can push registers to the stack and pop them later

The stack1


The stack

Stack pointer sp

Handling procedure calls

Handling procedure calls

  • MIPS software uses the following conventions

    • $a0, … $a3 are the four argument registers that can be used to pass parameters

    • $v0 and $v1 are the two value registers that can be used to return values

    • $ra is the register containing thereturn address

Simple procedure call i

Simple procedure call (I)

  • Before starting the new procedure, we must savethe registers used by the calling procedures

    • Not all of them

      • Save the eight registers $s0, $s1, …, $s7

      • Do not save the ten temporary registers$t0, …, $t9

  • Must also restore these registers when we exit the procedure

Simple procedure call ii

Simple procedure call (II)

  • At call time

    • addi $sp, $sp, -32 # eight times four bytessw $s7, 28($sp)sw $s6, 24($sp)sw $s5, 20($sp)sw $s4, 16($sp)sw $s3, 12($sp)sw $s2, 8($sp)sw $s1, 4($sp)sw $s0, 0($sp

Reality Check:We will only save the

registers that will bereused by the callee

Simple procedure call iii

Simple procedure call (III)

  • At return time

    • lw $s0, 0($sp) # restore the registers $s0 to $s7lw $s1, 4($sp)lw $s2, 8($sp)lw $s3, 12($sp)lw $s4, 16($sp)lw $s5, 20($sp)lw $s6, 24($sp)lw $s7, 28($sp)addi $sp, $sp, 32 # eight times four bytes

Nested procedures i

Nested procedures (I)

  • Procedures that call other procedures

    • Including themselves: recursive procedures

  • Likely to reuse argument registers and temporary registers

  • Caller will save the argument registers and temporary registers it will need after the call

  • Callee will save the saved registers of the caller before reusing them

Nested procedures ii

Nested procedures (II)

  • All saved registers are restored when the procedure returns and the stack is shrunk

The assembler i

The assembler (I)

  • Helps the programmer with

    • Symbolic names

      • Arguments of jump and branch instructions are labels rather than numerical constants

        beq $s0, $s1 done


        done: …

The assembler ii

The assembler (II)

  • Pseudo-instructions

    • To reserve memory locations for data

    • To create user-friendly specialized versionsof very general instructions

      • bzero $s0, address


      • beq $s0, $0, address

A review question

A review question

Which MIPS instructions involve

  • Three explicit operands?

  • Two explicit operands?

  • One explicit operand?

Answer i

Answer (I)

  • Three explicit operands:

    • All R format instructions but jr and jalr

    • All I format instructions involving an immediate value but lui

    • All I format instructions involving a conditional branch

Answer ii

Answer (II)

  • Two explicit operands:

    • All I format instructions involving a load or a store

    • Load upper immediate(lui)

    • Jump and link to register (jalr)

Answer iii

Answer (III)

  • One explicit operand:

    • Jump register instruction (jr)

    • Both J format instructions

      • jal has an implicit second operand that it uses to store the return address ($ra)

Other examples


Another risc is arm i

Another RISC IS: ARM (I)

  • ARM stands for Advanced RISC Machine

  • Originally developed as a CPU architecture for a desktop computer manufactured by Acorn in Britain

    • Now dominates the embedded system market

  • Company has no foundry

    • It licenses its products to manufacturers

Another risc is arm ii

Another RISC IS: ARM (II)

  • Used in cell phones, embedded systems, …

  • Same 32-bit instruction formats

  • Only 8 registers

  • Nine addressing modes

    • Including autoincrement

  • Branches use condition codes of arithmetic unit

Another risc is arm

Another RISC IS: ARM

  • All instructions have a 4-bit condition code allowing their conditional execution

    • Claimed to faster than using a branch

  • NO zero register:

    • Includes instructions like logical not, load immediate, move (R to R)

The x86 instruction set i

The x86 instruction set (I)

  • Not the result of a well-thought design process

    • Evolved over the years

  • 8086 was the first x86 processor architecture

    • Announced in 1978

    • Sixteen-bit architecture

    • Assembly language-compatible extension to Intel 8080 (8-bit microprocessor)

The x86 instruction set ii

The x86 instruction set (II)

  • New instructions were added over the years, mostly by Intel , but also by AMD

    • Floating-point instructions

    • Multimedia instructions

    • More floating-point instructions

    • Vector computing

  • 80836 was the first 32-bit processor

    • Introduced more interesting instructions

The x86 instruction set iii

The x86 instruction set (III)

  • AMD extended the x86 architecture to 64-bit address space and registers in 2003

  • Intel followed AMD’s lead the next year

The x86 instruction set iv

The x86 instruction set (IV)

  • The result is a huge instruction set combining

    • Old instructions kept to insure backward compatibility

      • “Golden handcuff”

    • Newer 32-bit instructions that are in use today

A curious tradeoff

A curious tradeoff

  • Complexity of x86 instruction set

    • Complicates the design of x86 microprocessors

      • More work for Intel and AMD architects

    • Effectively prevents other manufacturers to design and sell x86-compatible microprocessors

  • A mixed blessing for the duopoly Intel/AMD

Stack oriented architectures i

Stack-oriented architectures (I)

  • A rarity in microprocessor architecture

    • Bad solution

  • Used in many interpreted languages

    • Java virtual machine, Python

    • Big exceptions are Dalvik and Lua

      • Register-based virtual machines

Interpreted vs compiled i

Interpreted vs. Compiled (I)

  • Compiled language

  • Machine code is directly executable




Interpreted vs compiled ii

Interpreted vs. Compiled (II)

  • Interpreted language








Stack oriented architectures ii

Stack-oriented architectures (II)

  • Named registers replaced by a stack of registers

  • Two basic operations:

    • PUSH <address>push on stack contents of memory address

    • POP <address>pop top of stack and store it at specified memory address

Stack oriented architecture iii




Stack-oriented architecture (III)

  • Binary arithmetic and logical operations

    • Have both operands on the top of the stack

    • Replace them by the result

  • Example:




  • Advantages

    • Simple compilers and interpreters

    • Very compact object code

  • Main disadvantage

    • More memory references

      • Cannot save partial results into a register



Good design principles i

Good design principles (I)

  • Simplicity favors regularity

    • As few instruction formats as possible for easier decoding

  • Smaller is faster

    • No complicated instructions

Good design principles ii

Good design principles (II)

  • We should make the common case faster

    • PC-relative addressing for branches

  • Good design requires good compromises

    • Limiting address displacements and immediate values to 16 bits ensures that all instructions can fit in a 32-bit word

    • Weird J format addressing mode

Myths i

Myths (I)

  • Adding more powerful instructions will increase performance

    • IBM 360 has an instruction saving multiple registers

    • DEC VAX has an instruction computing polynomial terms

  • These complex instructions limit pipelining options

Myths ii

Myths (II)

  • Writing programs in assembly language produces faster code than that generated by a compiler

    • Compilers are now better than humans for register allocations

  • In addition, programs written in assembly language cannot be ported to other CPU architectures

    • Think of Macintosh programs

Myths iii

Myths (III)

  • Backward compatibility prevents instruction sets from evolving

    • Not true for x86 architecture

      • Can add new instructions

      • Write compilers that avoid the older instructions

  • Login
