Emerging trends in biofloc aquaculture

In this presentation, we will look at the emerging trends in Biofloc aquaculture taking into consideration - Biomass / Stocking density, salinity, temperature, species, water movement. For an insight into biofloc aquaculture : https://www.airoxitube.com/<br>

airoxitube
Download Presentation

Emerging trends in biofloc aquaculture

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Pranav Rachh – AirOxi On Aeration requirement for BFT

  2. Pranav Rachh

  3. Key points of aeration in BFT aquaculture • Aeration needs to be intensive , at all points • Vigorous movement of bio floc • Aeration to be calculated for the nitrifying bacteria as well as marine life • Too low aeration – hypoxia will kill the nitrifying bacteria • Too high aeration has also been shown to reduce effectiveness of the nitrifying bacteria (when balance of oxygen and ammonia / nitrogen compounds is imbalanced)

  4. 2 uses of Dissolved Oxygen (DO) • Biological Oxygen Demand (BoD) This is the DO needed by marine life and other micro organisms • Chemical Oxygen Demand (CoD) This is the DO needed for organic and inorganic waste for oxidation. For example to convert what we call as ‘sludge’, waste, excess feed, minerals and other chemicals added to the water and also present in soil and water.

  5. BFT v/s Traditional v/s RAS • In traditional aquaculture, the natural system of DO consumption and replenishment is available, so natural DO fulfils almost 75% or more of the oxygen requirement. And depending on density of fish cultivation, additional aeration may need to be given • In RAS the water is constantly filtered, so except the species being cultivated, very little DO is required as BoD or CoD. Hence it is easier to maintain DO levels • In BFT there is an additional load of BoD created by added nitrifying bacteria. And also there is very little water exchange so CoD is also little higher even after accounting for the biofloc.

  6. Factors affecting aeration in aquaculture • Species reared through BFT • Concentration of micro organisms. • Aerobic (utilizing DO) • Anaerobic (utilizing nitrogen compounds). • Photosynthetic organisms like algae, that produce DO in presence of sunlight • Water temperature • Surface area of water v/s water volume • Salinity • Amount of organic and inorganic waste in the system • External aeration provided

  7. Oxygen saturation at various temperatures Source – FAO website

  8. Oxygen consumption vis a vis water temperature Source FAO website

  9. Points to consider in artificial aeration • Biomass / Stocking density, salinity, temperature, species, water movement. • Low water movement may lead to reduced aeration of nitrifying bacteria. Very high water movement will lead to unnecessary movement and fatigue of the animal, increasing their oxygen requirement. • Depth of water and hence aeration • Drop / bubble size • Path of bubble and time in water, in case of diffused aeration • Duration for which aeration is provided

  10. Independent study on biofloc aeration A study on aeration methods for biofloc culture of L. Vannamei published in Aquaculture International February 2017 found diffused aeration to be the best aeration method for biofloc Stocking Density - 40 / sqmt 9 tanks of 35 sqmtr size (4900 pieces per tank) Initial weight – about 4.5 gram Study period – 33 days.

  11. Comparative Efficiency of aeration methods kg/kwh lb/hp-h General Oxygen Transfer Efficiency (standard conditions) 11 10 6 High-Density / Low-Flux – Aeration Systems (fine bubble diffuser arranged in high density layout) 9 8 7 5 4 6 5 4 Typical Fine Bubble Diffuser System 3 3 Jet Aerators & Coarse Bubble Diffuser Systems Mechanical Floating Aerators 2 2 1 1 Aspirating FloatingAerators Source - Environmental DynamicsInternational, Aeration efficiency guide 2011

  12. Eventual Benefits to Farmers Higher and more uniform DO, Faster DO leading to: • Higher Stocking Density – increase by 40-50% • Higher Immunity • Higher Survival – 85% to 95% • Faster Growth (saving of 10-20 days, even one additional crop/ year) • Low FCR • Reduced cost of power used for aeration – saving of 40-60%

  13. MOBILE AERATION UNIT

  14. For more information and videos……… www.airoxi.com www.airoxitube.com www.Youtube.com/airoxitube www.facebook.com/airoxitube www.twiter.com/airoxitube info@airoxitube.com +91-72850-17087

  15. Visit www.airoxi.in/calculator To calculate the aeration needs of your BFT pond / tank

  16. For more information and videos……… www.airoxi.in www.airoxitube.com www.Youtube.com/airoxitube www.facebook.com/airoxitube www.twiter.com/airoxitube info@airoxitube.com +91-72850-17087
