Presentation Transcript


Randomized algorithms

Randomized Algorithms

Morteza ZadiMoghaddam

Amin Sayedi


Types of randomized algorithms

Types of Randomized algorithms

  • Las Vegas

  • Monte Carlo


Las vegas

Las Vegas

  • Always gives the true answer.

  • Running time is random.

  • Running time is bounded.

  • Quick sort is a Las Vegas algorithm.


Monte carlo

Monte Carlo

  • It may produce incorrect answer!

  • We are able to bound its probability.

  • By running it many times on independent random variables, we can make the failure probability arbitrarily small at the expense of running time.


Monte carlo example

Monte Carlo Example

  • Suppose we want to find a number among n given numbers which is larger than or equal to the median.


Monte carlo example1

Monte Carlo Example

Suppose A1 < … < An.

We want Ai, such that i ≥ n/2.

It’s obvious that the best deterministic algorithm needs O(n) time to produce the answer.

n may be very large!

Suppose n is 100,000,000,000 !


Monte carlo example2

Monte Carlo Example

  • Choose 100 of the numbers with equal probability.

  • find the maximum among these numbers.

  • Return the maximum.


Monte carlo example3

Monte Carlo Example

  • The running time of the given algorithm is O(1).

  • The probability of Failure is 1/(2100).

  • Consider that the algorithm may return a wrong answer but the probability is very smaller than the hardware failure or even an earthquake!


Monte carlo1

Monte Carlo

  • Suppose the output is Yes or No.

  • One sided error.

  • Two sided error.


Rp class randomized polynomial

RP Class( randomized polynomial )

  • Bounded polynomial time in the worst case.

  • If the answer is Yes; Pr[ return Yes] > ½.

  • If the answer is No; Pr[ return Yes] = 0.

  • ½ is not actually important.


Pp class probabilistic polynomial

PP Class( probabilistic polynomial )

  • Bounded polynomial time in worst case.

  • If the answer is Yes; Pr[ return Yes] > ½.

  • If the answer is No; Pr[ return Yes] < ½.

  • Unfortunately the definition is weak because the distance to ½ is important but is not considered.


Routing problem

Routing Problem

  • There are n computers.

  • Each computer has a packet.

  • Each packet has a destination D(i).

  • Packets can not follow the same edge simultaneously.

  • An oblivious algorithm is required.


Routing problem1

Routing Problem

  • For any deterministic oblivious algorithm on a network of N nodes each of outdegree d, there is an instance of permutation routing requiring (N/d) ½.


Routing problem2

Routing Problem

  • Pick random intermediate destination.

  • Packet i first travels to the intermediate destination and then to the final destination.

  • With probability at least 1-(1/N), every packet reaches its destination in 14n of fewer steps in Qn.

  • The expected number of steps is 15n.


Maximum satisfiability

Maximum Satisfiability

  • You have m clauses and n boolean variables.

  • Each clause contains some of variables or some of complements.

  • A clause is satisfied if at least one of it’s variables are satisfied.

  • We want to set the variables such that the number of satisfied clauses is maximized.


Example for maximum sat

Example for Maximum Sat

  • There are 3 variables A, B and C.

  • M1 = (A) or (B)

  • M2 = (A) or (not B) or (not C)

  • M3 = (C)

  • M4 = (B) or (not C)

  • M5 = (not C)


Example of maximum sat

Example of Maximum Sat

  • Set A = True

  • Set B = True

  • Set C = False

  • Four of the clauses are satisfied.


Maximum sat

Maximum Sat

  • This problem is a famous problem which has no polynomial time algorithm yet. It’s NP-hard.


Maximum sat1

Maximum Sat

  • For any set of m clauses, there is truth assignment for the variables that satisfies at least m/2 clauses.


Maximum sat2

Maximum Sat

  • Let Zi =1 if the i-th clause is satisfied and 0 otherwise.

  • Set the variables in a random way.

  • The probability of a clause with k variables to be true is 1- (1/(2k)) >= ½.

  • So E[Z1]+…+E[Zm] >= ½.

  • Thus there exist at least one assignment such that Z1+…+Zm >= ½.


Maximum sat algorithm

Maximum Sat algorithm

  • This problem is NP-hard so we seek for approximation algorithms.

  • We have an algorithm that produces an answer which is at least ½ of the best answer.

  • If all clauses have at least 2 literals then we have an algorithm that produces an answer which is at least ¾ of the best one.


Maximum sat algorithm1

Maximum Sat algorithm

  • We want to maximize Z1+…+Zm.

  • We have some inequalities:

  • ∑ yi (if Xi is in Zj and is uncomplemented)

  • ∑ (1-yi) (if Xi is in Zj and is complemented).

  • This inequality must be hold:

  • ∑ yi + ∑ (1-yi) >= Zj

  • This problem could be solved using integer linear programming.

  • We have to use linear programming.


Maximum sat3

Maximum Sat

  • Solve the problem using linear programming.

  • You get a real number for each yi or zi.

  • Assign Xi true with the probability yi.

  • The expected number of clauses that are satisfied is (1- 1/e) of the best answer.


Maximum sat algorithm2

Maximum Sat algorithm

  • Using both algorithms and choosing the better answer gives us an answer which is at least ¾ of the best answer!!! Which is better than ½ and 1- 1/e.


2 sat

2-Sat

  • Every clause has at most 2 literals.

  • We want to check if all clauses can be satisfied.

  • It has polynomial algorithm.

  • Assign random values to the variables.

  • If all clauses are satisfied we are finished.

  • If there is an unsatisfied clause, the value of one of it’s literals is different from the best answer.

  • Change the value of one of the variables in this clause. You may make a good change or bad one.


2 sat1

2-Sat

  • You are walking on a path.

  • If you are on 0 you go to 1.

  • If you are on i you go to i+1 or i-1 with equal probability.

  • The expected number of steps to reach the end of the path is O(n2).

  • So the given algorithm is O(n3).


Graph connectivity

Graph Connectivity

  • You want to check if two vertices u and v are in the same connected component.

  • Start a random walk from v.

  • Have a random walk of length 2n3.

  • If you haven’t visited u, the probability of u to be in this component is less than ½.

  • By repeating this algorithm, you can make the probability of failure arbitrarily small.


Graph connectivity1

Graph Connectivity

  • Running time of algorithm is O(n3).

  • Required space is O(logn).


Diameter of a point set

Diameter of a Point Set

  • You want to find the diameter of set of n points in the space.

  • Suppose I(x) is the convex body formed by the intersection of n sphere centered at n points with radius x.

  • F(p) is distance between p and the point in the set that is farthest from p.


Diameter of a point set1

Diameter of a Point Set

  • Consider I(x) when x=F(p).

  • For any q in S, if q is in I(x) then F(q)<F(p).

  • And if q is not in I(x) then F(p)<F(q).


Diameter of a point set2

Diameter of a Point Set

  • Pick a point p in s at random. Computer F(p). [O(n)]

  • Set x=F(p). Compute I(x). [O(n logn)]

  • Find the points outside I(x). Call this set T. [O(n logn)]

  • If T is empty return x as the answer, else continue on T.


Diameter of a point set3

Diameter of a Point Set

  • The running time of algorithm above is O(n log n).

  • In each step, all points that have smaller F(x) than the chosen point are removed.


All pairs shortest paths

All-Pairs Shortest Paths

  • Let G(V,E) be an undirected, connected graph with V={1,…,n} and |E|=m.

  • The adjacency matrix A is an n  n 0-1 matrix with Aij=Aji=1 if and only if the edge (i,j) is present in E.

  • We are going to compute matrix D which Dij equals the length of a shortest path from vertex i to vertex j.


All pairs distances

All-Pairs Distances

  • Z A2

  • Compute matrix A’ such that A’ij=1 if and only if i ≠ j and (Aij=1 or Zij>0)

  • If A’ij=1 for all i ≠ j then return D = 2A’-A.

  • Recursively compute the APD matrix D’ for the graph G’ with adjacency matrix A’.

  • S AD’

  • Return matrix D with Dij=2D’ij if Sij≥D’ijZii , otherwise Dij=2D’ij-1.


Randomized algorithms

APSP

  • The APD algorithm computes the distance matrix for an n-vertex graph in time O(MM(n)log(n)) using integer matrix multiplication algorithm.

  • Matrix multiplication algorithm running in time O(n2.376).


Boolean product witness matrix

Boolean Product Witness Matrix

  • Suppose A and B are nn boolean matrices and P=AB is their product under Boolean matrix multiplication.

  • A witness for Pij is an index k  {1,…,n} such that Aik=Akj=1. Observe that Pij=1 if and only if it has some witness k.


Randomized algorithms

BPWM

  • W -AB

  • 2. for t=0,…, log(n) do

  • 2.1. r 2t

  • 2.2. Repeat 3.77log(n) times

    • 2.2.1. Choose random R  {1,…,n} with |R|=r .

    • 2.2.2. Compute AR and BR .

    • 2.2.3. Z ARBR .

    • 2.2.4. for all (i,j) do

      • if Wij < 0 and Zij is witness then Wij Zij

  • 3. for all (i,j) do

    • if Wij < 0 then find witness Wij by brute force.


Randomized algorithms

BPWM

  • The BPWM algorithm is a Las Vegas algorithm for the BPWM problem with expected running time O(MM(n)log2(n)).

  • The probability that no witness is found for Pij before the end of Step 2 is at most

  • (1-1/2e)3.77log(n) 1/n.


Determining shortest path

Determining Shortest Path

  • A successor matrix S for an n-vertex graph G is an n  n matrix such that Sij is the index of a neighbor of vertex i that lies on a shortest path from i to j.


Randomized algorithms

APSP

  • Compute the distance matrix D=APD(A).

  • for s={0,1,2} do

    • Compute 0-1 matrix Dkj(s)=1 if and only if Dkj+1 = s (mod 3)

    • Compute the witness matrix W(s)=BPWM(A,D(s)).

  • Compute successor matrix S for G.


Randomized algorithms

APSP

  • Algorithm APSP computes the successor matrix for an n-vertex graph G in expected time O(MM(n)log2(n)).


Algorithm contract

Algorithm contract

  • H G

  • While H has more than 2 vertices do

    • Choose an edge (x,y) uniformly at random from the edges in H.

    • F F  {(x,y)}.

    • H H / (x,y).

  • (C,V/C) the sets of vertices corresponding to the two meta-vertices in H=G/F.


Fastcut

FastCut

  • n |v|

  • if n  6 then compute min-cut of G by brute-force enumeration else

    • t 1+n/2

    • Using Algorithm Contract, perform two independent contraction sequences to obtain graphs H1 and H2 each with t vertices.

    • Recursively compute min-cuts in each of H1 and H2.

    • Return the smaller of the two min-cuts.


Fastcut1

Fastcut

  • Algorithm Fastcut succeeds in finding a min-cut with probability (1/log(n)).

  • Algorithm Fastcut runs in O(n2log(n)) time and uses O(n2) space.


Randomized algorithms

MST

  • Finding MST in a graph with n vertices and m edges has a Las Vegas algorithm which has the expected running time O(n+m).

  • But We don’t have enough time to Explain it !!!


Research problems

Research problems

  • Devise an algorithm for the all-pairs shortest paths problem that does not use matrix multiplication and runs in time O(n3-) for a positive constant .

  • Devise an algorithm for computing the diameter of an unweighted graph that does not use matrix multiplication and runs in time O(n3-) for a positive constant .


Research problems1

Research problems

  • Devise a Las Vegas or a deterministic algorithm for min-cuts with running time close to O(n2).

  • Is there a randomized algorithm for min-cuts with expected running time close to O(m)?


Randomized algorithms

Have a nice randomized life
