Presentation Transcript


Marathon everrun ft ha technology overview l.jpg

Marathon everRun FT & HATechnology Overview

José Juan DíazSystems Engineer Div. Virtualización Albora Soluciones


Agenda l.jpg

Agenda

  • Availability Definitions

  • Marathon Technologies Overview

  • everRun FT & HA Architecture

  • everRun VM

  • Availability examples everRun VM


Availability definitions l.jpg

Availability Definitions


The application availability spectrum l.jpg

The Application Availability Spectrum

AL4: Continuous Availability - System Fault Tolerance

No user interruption – 99.999% Availability – 5.25 minutes

AL4

AL3: High Availability – Traditional Clustering

User interruption – 99.99% - 52.5 minutes

AL3

AL2: Recovery - Data Replication & Back Up

User interruption – 99.9% - 8.76 hours

AL2

AL1: Reliability – Hot swappable components

All service stops – 99% - 87.6 hours

AL1

AL0: Unprotected Servers

All service stops

AL0

Source: IDC


Typical use cases l.jpg

Typical use cases

Building Security/Access Control, Process Control

AL4

Email, CRM, Database, Financial Systems

AL3

AL2

Critical File Servers, DNS, Webservers

AL1

Non critical systems, test and development,

network server applications

AL0


Marathon technologies company overview l.jpg

Marathon TechnologiesCompany Overview


Marathon technologies l.jpg

Marathon Technologies

  • Founded 1993

  • Worldwide headquarters in Littleton MA

  • 15 years delivering proven availability solutions built on fault-tolerant capabilities

  • 13 US Patents

  • Award winning technology

  • Over 2000 customers worldwide

  • Over 300 partners worldwide


Marathon everrun proven in over 2000 mission critical environments l.jpg

Marathon everRunProven in over 2000 Mission Critical Environments

Financial

Media

Airlines/Airports

Government

Manufacturing

$1 Billion Hedge Fund

Logan

Pharmaceutical

Technology

Telecom

Resorts/Casinos

Energy


Marathon partnerships l.jpg

Marathon Partnerships

  • 100% channel model

    • Over 300 Distributors, Integrators & VARs

  • Microsoft High Potential ISV Program

  • Citrix XenServer Technology Partner

    • Preferred 3rd party HA vendor

    • XenServer HA co-development & integration

  • Server & Storage Hardware Manufacturers

    • HP, IBM, Fujitsu, etc

      • Qualified Hardware List for most popular H/W

  • ISV Support in Gaming, Healthcare, Process Control, etc


Marathon citrix strategic partnership l.jpg

Marathon & Citrix Strategic Partnership

Marathon named “Preferred High Availability Provider”

XenServer 5.0 HA “Powered by Marathon” co-development

Development agreement in place for tighter integration of products

Unique selectable availability levels and fault-tolerant protection for virtual machines

All everRun products Citrix Ready certified

“Marathon has a superb plug-in complementary product for XenServer that delivers fault tolerant computing for the mass market” – Simon Crosby, CTO, Citrix Virtualization and Management Division


Slide11 l.jpg

Comprehensive SolutionsAutomated Application Availability

Protection for mission critical

applications

Protection for stand alone

Infrastructure applications

Protection for your Citrix

XenServer environment

SQL

Exchange

Exchange

SCADA

Oracle

Available, Affordable, Automated – Application Availability


Marathon everrun ft y ha l.jpg

Marathon EverRUN FT y HA

EverRUN FT: “Aplicaciones donde el cliente no puede tener perdida de servicio en entornos físicos.

Requiere máquinas exactamente iguales.

Máximo 1 CPU por máquina.

EverRUN HA: “Alta Disponibilidad para aplicaciones en entorno físico”.

Ventajas con respecto al Cluster MS: necesita 2003 Enterprise y Storage Compartido, con EverRun MS Estándar y Storage Local.


Comprehensive solutions automated application availability l.jpg

Comprehensive SolutionsAutomated Application Availability

  • How do everRun FT & HA work?

    • Patented architecture creates a single virtual server with a fault-tolerant I/O subsystem using two mirrored physical servers

    • ComputeThru® failures vs. traditional failover approaches

    • Intelligent Policy Management – automated vs. scripted


Slide14 l.jpg

everRun® VMWhy respond to failure?PREVENT IT.José Juan Díaz.Systems Engineer Div. Virtualización Albora Soluciones


Slide15 l.jpg

everRun VMUnique Architecture – VM Fault-Tolerance in Software

  • Installs directly onto a pair of Citrix XenServer hosts

    • Thin software layer between hypervisor and VM environment

  • Auto-creates and maintains identical PVM on alternate host

    • “Active” VM is paired with a “Ready” VM

    • Assured recovery if Active VM host fails

  • PVM’s I/O resources are transparently paired

    • Aggregated across both XenServer hosts

    • Fully redundant networking & storage

    • “ComputeThru” device failures

  • Availability Manager attaches to each PVM

    • Mini Linux VM, manages I/O redirection

    • Automated error detection, fault handling


Flexibility to dial in availability by vm l.jpg

Flexibility to “Dial-in” Availability by VM

  • Simple “click-through” operation to protect VM’s

  • Future product releases will allow different protection levels for each VM

  • Choose appropriate level of availability per application


Citrix xenserver and everrun vm l.jpg

Citrix XenServer and everRun VM

Level 3 - everRun VM System-Level FT (1H ’09)

AL4

Level 2 - everRun VM Component-Level FT

(Available now)

AL3

AL2

Level 1 – Citrix XenServer 5.0 HA

(everRun VM Basic Failover)

AL1

Citrix XenServer Enterprise

AL0


Everrun vm key benefits summary l.jpg

everRun VM - Key Benefits Summary

  • Available

    • Zero downtime due to subsystem failures

    • Patented “ComputeThru” technology ensures transparent fail-out of devices

    • No complex failover management or testing

    • No false failovers

    • Mirrored storage for zero data loss

  • Affordable

    • Allows consolidation of multiple business-critical applications

    • Priced for broad adoption

    • No shared-disk subsystem or SAN required

  • Automated

    • Easy to install, operate and maintain

    • “Point and click” operation

    • Automated fault handling and policy management

    • Active redundancy provides assured recovery on host failure

    • No scripting or custom coding

Protection for your Citrix

XenServer environment

SQL

Exchange

Oracle


Availability examples l.jpg

Availability Examples


Noticias de este enero 2009 l.jpg

Noticias de este Enero 2009.

  • Microsoft and Marathon Technologies Expand Relationship to Provide Fault Tolerant Computing to More Businesses

    http://www.microsoft.com/presspass/press/2009/jan09/01-09MarathonPR.mspx

    MICROSOFT CHOSES MARATHON’S FAULT-TOLERANCE AND HIGH AVAILABILITY FOR WINDOWS 2008 AND HYPER-V
