Presentation Transcript
Slide1 l.jpg

Microsoft Exchange 2000 Database RecoveryMike LeeSupport ProfessionalProduct Support ServicesMicrosoft Corporation


What we will cover l.jpg
What We Will Cover

  • Important differences between Exchange 5.5 and Exchange 2000

  • Fundamental principles of Exchange 2000 data preservation and recovery

  • Offline recovery

  • Highlights: SRS, KMS, Active Directory™, IIS metabase recovery


Differences l.jpg
Differences

  • Windows® 2000 global Active Directory replaces the Exchange 5.5 server-centric directory database.

  • Mailboxes are attributes, not objects.

  • Public folder and other permissions are granted through Windows ACLs, not Exchange DNs.


Differences4 l.jpg
Differences

  • Administrative Groups instead of Sites

  • Storage Groups (4 x 5 = 20 databases)

  • General purpose public folders

  • Database mounting

  • Streaming database


Fundamental principles l.jpg
Fundamental Principles

  • System-centric versus server-centric view.

  • A problem in Active Directory can bring down the Exchange system.

  • Exchange disaster recovery and Active Directory disaster recovery teams should be closely integrated.

  • An unrecoverable disaster to your Certification Authority or Active Directory will render KMS unusable.


Exchange data storage l.jpg
Exchange Data Storage

  • In Exchange 5.5, you can reconstruct an entire server from:

    • Database backups

    • A few registry settings (sometimes not even needed)

    • In transit queued messages


Exchange data storage 2 l.jpg
Exchange Data Storage (2)

  • In Exchange 2000, you may need all this to get your server going again (worst case):

    • Replacement hardware, installation disks, system configuration logs.

    • Full drive backups

    • System state backup (including metabase and system certificates)

    • Active Directory backup

    • Exchange database backups (IS, KMS, SRS)

    • Certification Authority backup

  • or . . . .


Exchange data storage 3 l.jpg
Exchange Data Storage (3)

  • If only the local server is involved in the disaster:

    • Run SETUP /disasterrecovery

    • Restore databases

  • SETUP /disasterrecovery reinstalls the server based on the configuration information in Active Directory.

  • If only the Exchange server is involved in the disaster, recovery is often simpler than in Exchange 5.5.


New backup capabilities and differences l.jpg
New Backup Capabilities and Differences

  • KMS and SRS databases can be backed up online.

  • No directory backups (AD is the directory).

  • Concurrent backup of different storage groups.


New restore capabilities and differences l.jpg
New Restore Capabilities and Differences

  • Services must be started, but databases not mounted to restore.

  • Restore in Progress registry key replaced with Restore.env file.

  • Hard recovery is manually triggered, not automatic. Select the Last Backup Set check box before restoring.

  • Restored log and patch files are restored to a Temp directory, not the running log directory.


Offline database recoveries l.jpg
Offline Database Recoveries

  • You can restore Exchange information store databases from one server to another server.

  • The usual reason for doing this is to recover a single mailbox after a user has inadvertently purged an important item.

  • It is also great recovery practice, because it is the same thing as having to recover after losing everything except the information store backups.


Recovery server setup in exchange 5 5 l.jpg
Recovery Server Setup in Exchange 5.5

  • Install Exchange on a separate server (but can be on the same network).

  • Use the same Organization and Site names as the production site, but don’t join the real site during setup.

  • Service Accounts do not have to match.


Recovery server setup in exchange 2000 l.jpg
Recovery Server Setup in Exchange 2000

  • Install a new Active Directory forest (but it can be on the same network).

  • Set up DNS (if necessary).

  • Install Exchange 2000, using the same Organization name as the production organization.


Information store recovery in exchange 5 5 l.jpg
Information Store Recovery in Exchange 5.5

  • Restore databases to the offline recovery server.

  • Run DS/IS consistency adjustor to populate the directory from the mailbox tables.

  • Use a client application, such as Outlook® or Exmerge to access mailbox data.


Information store recovery in exchange 2000 l.jpg
Information Store Recovery in Exchange 2000

  • Change the Administrative Group name to match the production Administrative Group

  • Change or add logical database and storage group names to match too.

  • Fix legacyExchangeDN values as necessary.

  • Restore databases.

  • Generate Active Directory user accounts and connect mailboxes to them.

  • Use a client application, such as Outlook or Exmerge to access mailbox data.


Setting up dns on a recovery server l.jpg
Setting Up DNS on a Recovery Server

  • Install DNS from the Windows 2000 CD.

  • Run IPCONFIG /ALL and write down your current DNS server and your own IP address.

  • In your Network and Dial-up Connection properties, change your DNS server to your own IP address.


Setting up dns on a recovery server 2 l.jpg
Setting Up DNS on a Recovery Server (2)

  • Run the DNS management console (Dnsmgmt.msc)

  • Configure a standard primary forward lookup zone for your domain. The zone name should be the same as your recovery server domain name.

  • On the zone’s properties, set Allow Dynamic Updates to Yes.

  • On the server properties in Dnsmgmt, configure your previous DNS server as a forwarder.


Setting up dns on a recovery server 3 l.jpg
Setting Up DNS on a Recovery Server (3)

  • Run IPCONFIG /ALL to be sure changes have taken effect.

  • Cycle the Netlogon service to speed up registry of the SRV records.

  • Inspect the forward lookup zone to be sure SRV records have actually been registered.


Changing the administrative group name l.jpg
Changing the Administrative Group Name

  • Switch the recovery server to Native mode, on the properties of the organization object.

  • Right-click the Administrative Group object, and click Rename.

  • Remember—this doesn’t change the legacyExchangeDN!


The legacyexchangedn l.jpg
The legacyExchangeDN

  • Maps Active Directory objects to corresponding Exchange 5.5 objects.

  • Looks like:

    /o=Organization/ou=Site/cn=Recipients…

  • Never changes after it is set, even if you change the Administrative Group or Organization names.

  • Databases cannot start unless legacyExchangeDN values are correct.


Legacyexchangedn value generation l.jpg
legacyExchangeDN Value Generation

  • Install new Exchange 2000 organization, legacyExchangeDN is:

    /o=Organization/ou=First Administrative Group

  • Upgrade Exchange 5.5 organization, legacyExchangeDN is:

    /o=Organization/ou=5.5 Site Name

  • Install recovery server, legacyExchangeDN is:

    /o=Organization/ou=First Administrative Group


Legacyexchangedn mismatches l.jpg
legacyExchangeDN Mismatches

  • If restoring a database from an upgraded organization to a recovery server.

  • If restoring a database from a second Administrative Group in a “pure” Exchange 2000 organization.

  • Recovery server legacyExchangeDN value will always be /ou=First Administrative Group, no matter what the “real” legacyExchangeDN is.

  • If legacyExchangeDNs do not match, databases will not start.


Getting around the legacyexchangedn problem l.jpg
Getting Around the legacyExchangeDN Problem

  • Install a second recovery server with the correct naming.

  • Install Exchange 5.5 on the recovery server with the correct naming, and then upgrade.

  • Change the legacyExchangeDN values to the correct naming.


What is the legacyexchangedn stem in your organization l.jpg
What Is the legacyExchangeDN Stem in Your Organization?

  • In your production organization, run this command:

    LDIFDE –f CON –d "CN=Headquarters,

    CN=Administrative Groups,CN=Corp1,

    CN=Microsoft Exchange,CN=Services,

    CN=Configuration,DC=mycorp,DC=com"

    –l legacyExchangeDN –p Base


What is the legacyexchangedn stem in your organization 2 l.jpg
What Is the legacyExchangeDN Stem in your Organization? (2)

  • You will get output that looks like this:

    dn: CN=Headquarters,CN=Administrative Groups,CN=Corp1,CN=Microsoft Exchange, CN=Services,CN=Configuration,dc=mycorp,dc=com

    changetype: add

    legacyExchangeDN: /O=Microsoft/OU=Headquarters


Fixing the legacyexchangedn l.jpg
Fixing the legacyExchangeDN

  • On the recovery server, run this command:

    ldifde -f e:\legacy.ldf -p subtree

    -l legacyexchangedn -d "CN=Microsoft Exchange,

    CN=Services,CN=Configuration,DC=mycorp,DC=com"

    -r "(legacyexchangedn=*First*)"


Fixing the legacyexchangedn 2 l.jpg
Fixing the legacyExchangeDN (2)

Output from the previous command will be in the

file Legacy.ldf, and each record will look like

this:

dn: distinguished name of the object

changetype: add

legacyExchangeDN: current value

<blank line>


Fixing the legacyexchangedn 3 l.jpg
Fixing the legacyExchangeDN (3)

  • You must rework each record so that it can be imported.

  • Use Word or a plain text editor that supports across line break find and replace.


Fixing the legacyexchangedn 4 l.jpg
Fixing the legacyExchangeDN (4)

  • Find/ou=First Administrative Groupand replace with:/ou=right administrative group name


Fixing the legacyexchangedn 5 l.jpg
Fixing the legacyExchangeDN (5)

  • Find<line break><line break>and replace with:<line break><dash><line break><line break>

  • Hint: In Word, search for ^p^p and replace with ^p-^p^p


Fixing the legacyexchangedn 6 l.jpg
Fixing the legacyExchangeDN (6)

  • Find:Changetype: add<linebreak>and replace with:Changetype: modify<linebreak>replace: legacyExchangeDN<linebreak>


Fixing the legacyexchangedn 7 l.jpg
Fixing the legacyExchangeDN (7)

  • If editing the file in Microsoft Word, don’t forget to save it as plain text.

  • After editing, each record in the file should look like this:

    dn: distinguished name of the object to be modified

    changetype: modify

    replace: legacyExchangeDN

    legacyExchangeDN: new value

    -

    <blank line>


Fixing the legacyexchangedn 8 l.jpg
Fixing the legacyExchangeDN (8)

  • Import the modified Legacy.ldf file using this command:

    ldifde –i –f legacy.ldf

  • Investigate any import errors: all modifications must succeed!


Restoring databases l.jpg
Restoring Databases

  • Restart all Exchange services. Existing databases will fail to mount if the legacyExchangeDN has been changed.

  • Before restoring databases from your production system, you must select the check box for “This database can be overwritten by a restore” on each database’s properties.


Accessing mailboxes l.jpg
Accessing Mailboxes

  • Create an Active Directory account for each mailbox you wish to open.

  • In Exchange System Manager (ESM) console, right-click the Mailboxes object and run the Cleanup Agent.

  • Right-click a mailbox with an X next to it, and click Reconnect.

  • Access the mailbox contents with a client application or save contents to a .pst file with Exmerge.


Srs and kms database recovery l.jpg
SRS and KMS Database Recovery

  • Semi-running mode.

  • Similar to Information Store recovery.

  • Must also select the “Last Backup Set” check box to run hard recovery.


Srs recovery if the srs database is lost l.jpg
SRS Recovery If the SRS Database Is Lost

  • Install another Exchange 2000 server in the site/administrative group or go to another Exchange 2000 server in the same admin group.

  • Run ESM from the console of the new server.

  • In Tools, right-click Site Replication Services, and install an SRS on the new server.

  • Delete the original SRS.

  • Re-create the original SRS (if needed).

  • Delete the other SRS, and then remove the other server (if needed).


Iis metabase recovery l.jpg
IIS Metabase Recovery

  • Metabase contains virtual server and other Exchange protocol configuration information.

  • Most of the information in the metabase is duplicated in Active Directory, and is re-created automatically during /disasterrecovery setup.

  • Exception: NNTP information.


Iis metabase recovery 2 l.jpg
IIS Metabase Recovery (2)

  • The metabase can’t be transported to a different server and recovered.

  • If security/certificate information for the server installation is lost, the metabase can’t be restored.

  • Back up the metabase along with system state information on the server.

  • Additional backups of just the metabase file can be made in the IIS Administrator console.


Active directory recovery l.jpg
Active Directory Recovery

  • Each domain controller in a given domain serves as a real-time backup of the others.

  • Have three domain controllers per domain for disaster recovery redundancy.

  • It may be easier to rebuild a single domain controller than to restore it.

  • Coordinate with Active Directory administrators on disaster recovery plans.

  • Make sure Exchange disaster recovery administrators have appropriate AD permissions.


Kms recovery requirements l.jpg
KMS Recovery Requirements

  • Must have .P12 file backup of the root certificate for the Certification Authorities, and know the password to the file.

  • Must have KMS database backup.

  • Must know KMS database startup password.

  • Must know KMS administrator passwords.

  • Must have access to AD accounts for KMS administrators.


Kms best practices l.jpg
KMS Best Practices

  • Before deploying KMS, think very hard about your Public Key Infrastructure (PKI) requirements. Backing out and doing it over is very difficult.

  • Make sure that your administrative framework for PKI and KMS can survive changes in personnel, and that backups are very secure.

  • Have thorough and expert knowledge of PKI before deploying KMS. Never just wing it.



ad
