Presentation Transcript


Slide1 l.jpg

Virtualization: Doing it right the first time to avoid costly repeat attempts.

Software Licensing, Storage Options, Power and Cooling and Management


Slide2 l.jpg

vSphere 4 Product Licensing

Essentials includes support and Essentials Plus requires support.


Slide3 l.jpg

vSphere 4 Product Licensing

Support is required and sold separately.

vSphere 4 Acceleration Kits/Promotions


Microsoft os licensing l.jpg

Microsoft OS Licensing

  • Operating Systems will need to be licensed

  • Microsoft O/S


Storage l.jpg

Storage

  • Shared Storage Pools

  • Centralized Management

  • Cost and Simplicity


Storage protocols l.jpg

Storage Protocols

What will it be with your VMware environment?

  • FC (Fibre Channel)

  • FCoE (Fibre Channel over Ethernet)

  • iSCSI

  • NAS (NFS)

    The answer is based on your environment and or application requirements.

    http://www.vmware.com/resources/techresources/


Slide7 l.jpg

VMware Useful Resources

  • Product Information - http://www.vmware.com/products

  • Events - http://www.vmware.com/events

  • White Papers - http://www.vmware.com/solutions/whitepapers.html

  • Compatibility Guides - http://www.vmware.com/resources/guides.html

  • TCO Calculator - http://www.vmware.com/calculator

  • Success Stories - http://www.vmware.com/customers/

  • SMB Portal- http://www.vmware.com/smb

  • Product Downloads - http://www.vmware.com/download/

  • Solution Tracks Online - http://www.solutiontracks.com


Slide8 l.jpg

  • MicroAge Presents

  • Nexsan

  • Storage Strategies for

  • VMware

Zophar Sante

Nexsan VP Product Marketing

Mike Cirrincione

Nexsan Sales Manager

8


Slide9 l.jpg

Agenda for Today

  • New Storage Technology

  • For Aligning VMware

  • Server Cost Reduction Strategies

  • with

  • Storage Cost Reduction Strategies

  • Reducing Storage Power

  • Reducing Storage Space

  • Reducing Storage Hardware

  • Reducing Storage Management

  • Storage Architectures for VMware

  • Single ESX Server

  • Multiple ESX Servers / VMotion

  • Multiple ESX Servers / VMotion / Disaster Recovery

9


New technology to reduce storage power l.jpg

New Technology to Reduce Storage POWER

Old MAID

Reduces application performance for energy savings

“On-or-off” approach to energy savings

Usually only supported on SATA drives

Minutes to spin up components to respond to IO requests

Slow response confines use to just a few applications

AutoMAID

Benefits of MAID without the limitations!

Energy savings with application performance “Green with Speed”

Supported on SAS and SATA drives

Three levels of energy savings

Level 1, up to 20%

Level 2, up to 40% (SATA only)

Level 3, up to 60%

Fast response to 1st I/O requests

Level 1, sub-second

Level 2, less than 15 seconds

Level 3, less than 30 seconds

Fast and flexible response broadens use to include a wide range of applications

10


Slide11 l.jpg

Using LEGACY technology compared to NEW technology

$.15 Kilowatt hour cost

3 year period

84TB

Results - 60% less expense (includes CAPEX , OPEX)

The results when you use New Technology to Reduce Storage POWER

11


New technology to reduce storage space l.jpg

New Technology to Reduce Storage SPACE

Drives are installed back to back to reduce vibration

  • Density

  • Single 4U chassis

  • Up to 84TB

  • 21TB per U

  • SAS and SATA

  • 4 FC ports

  • 4 iSCSI ports

  • Performance

  • 4 RAID Engines per chassis

  • 4 GB cache per chassis

  • 1100MBs and 40,000 IOPs

Drive bottom

Drive bottom

New 4X Enterprise RAID Engines Per Chassis

Cooling channel reduce drive heat.

12


Slide13 l.jpg

The results when you use New technology to Reduce Storage SPACE

  • Using LEGACY technology compared to NEW technology

    • $100 per. U per. month

    • 3 year period

    • FC Ports cost $300 each

    • 84TB SATA (25TB of SAS)

  • Results - 62% less expense (OPEX) – 85% less expensive (Infrastructure CAPEX)

  • 42TB in 9 U

    42TB in 4 U

    13


    New technology to reduce hardware components l.jpg

    New Technology to Reduce Hardware Components

    • The Results when you use NewTechnology to Reduce Hardware Components

    • 65% fewer components

    • Less space

    • Less power

    • Fewer points of failure

    • Few things to worry about

    14


    New technology to reduce storage management l.jpg

    New Technology to Reduce Storage Management

    • The Results when you use NewTechnology to Reduce Management

    • 1 thing to manage NOT 3 things to manage

    • Less effort to scale

    • Less to worry about

    15


    Slide16 l.jpg

    New Storage Technology for

    A Single ESX Server

    • SAS (Speed) and SATA (Capacity)

    • 3TB to 200TB

    • Dual / Redundant FC / iSCSI connections

    • Active / Active Data Paths

      • Host Port Redundancy

      • Network connection Redundancy

      • Storage controller Redundancy

    • 3TB to 200TB

    Single ESX Server

    Guests

    ESX Virtual Server Host

    16


    Slide17 l.jpg

    New Storage Technology for

    Single Site - Multiple ESX Servers with VMotion

    Guests

    Guests

    VMotion

    ESX Virtual Server Host

    ESX Virtual Server Host

    • Server Redundancy

    • SAS (Speed) and SATA (Capacity)

    • 3TB to 200TB

    • Dual / Redundant FC / iSCSI connections

    • Active / Active Data Paths

      • Host Port Redundancy

      • Network connection Redundancy

      • Storage controller Redundancy

    • 3TB to 200TB

    17


    Slide18 l.jpg

    New Storage Technology for

    Multi-Site ESX Servers / VMotion / Disaster Recovery

    Site B

    Site A

    Guests

    Guests

    VMotion

    ESX Virtual Server Host

    ESX Virtual Server Host

    • Server Redundancy, Data Redundancy, Storage Redundancy, Site Redundancy

    • 5 Nines = 99.999 HA

    • SAS (Speed) and SATA (Capacity)

    • 3TB to 1000TB

    18


    Slide19 l.jpg

    Here is some additional Nexsan information available from MicroAge

    • 8 white papers

    • 5 - 10 minute briefing papers

    • Value Calculator

    19


    Slide20 l.jpg

    Conclusion

    • New Storage Technology

    • For Aligning VMware

    • Server Cost Reduction Strategies

    • with

    • Storage Cost Reduction Strategies

    • Reducing Storage Power – 60%

    • Reducing Storage Space– 62%

    • Reducing Storage Hardware – 65%

    • Reducing Storage Management – 66%

    • Storage Architectures for VMware

    • Single ESX - YES

    • Multiple ESX / Vmotion YES

    • Multiple ESX / VMotion / Disaster Recovery YES

    • Contact MicroAgeto Learn More

    20


    Slide21 l.jpg

    Nexsan

    • Who are We

    • Nexsan was founded in 1999

    • Over 24,000 storage systems sold into over 60 countries

    • We ship nearly 6000TB per month

    • What do we Do

    • Provide data storage solutions

    • SMB to Large Enterprise

    • All server environments

    21


    Slide22 l.jpg

    Here are some Nexsan Customers

    Confidential

    22


    Common mistake l.jpg

    Common Mistake

    Failure to adjust your power and cooling for your new infrastructure may result in decreased efficiency


    Defining data center infrastructure efficiency l.jpg

    Data center

    infrastructure

    efficiency

    =

    IT load power

    Total data center input power

    Defining Data Center Infrastructure Efficiency

    DCiE

    The percent of your input power that gets to the IT loads

    The rest goes to power, cooling, and lighting equipment


    Slide26 l.jpg

    The cooling system uses the most energy in the data center

    Data Center Physical Infrastructure

    IT

    COOLING system

    POWER system


    Slide27 l.jpg

    Go to latest online version of this tool

    Click to resume presentation mode

    Go

    Done


    Slide28 l.jpg

    POWER USE

    EFFICIENCY

    Always goes down, UNLESS power/cooling is downsized to match load

    UnusedCOOLINGcapacity

    UnusedPOWERcapacity

    Always goes down with virtualization

    Unused rack space

    Servers

    DCiE

    29%

    BEFOREvirtualization

    LOW

    Due to losses from excess capacity

    Non-scalable UPS

    ROOM cooling

    Power useDOWN

    DCiE

    16%

    LOWER

    AFTERvirtualization

    Due to consolidated servers

    Due to losses from GREATER excess capacity

    Non-scalable UPS

    ROOM cooling

    Power usedown MORE

    DCiE

    63%

    PLUSright-sized power and cooling

    HIGHER

    Due to RIGHT-SIZED power/cooling

    Due to RIGHT-SIZEDpower/cooling

    Scalable ROW cooling

    Scalable UPS

    Right-sizing improves power use AND efficiency
