knotty problems in date time parsing and formatting and time zones

Knotty problems in date/time parsing and formatting and time zones

Yoshito Umaoka

IBM Globalization Center of Competency

32nd Internationalization and Unicode Conference

  • Challenges for Implementing Date and Time UI
  • Understanding Time Zone Formatting Parsing
challenges for implementing date and time ui
Challenges for Implementing Date and Time UI
  • Two examples
    • Google Calendar
    • IBM Lotus Notes
  • Walking through various requirements for displaying date and time
  • Solutions provided by CLDR
  • Design/Implementation Tips
date format types
Date Format Types

Basic: July 27, 2008

Relative: Today

Basic: July 28, 2008

Relative: Tomorrow

Basic: August 3, 2008

Relative: August 3, 2008

Interval: July 27 - 28, 2008

Duration: 1 day

Interval: July 27 – August 3, 2008

Duration: 7 days

mini calendar
Mini Calendar
  • Month
    • Different form without date in some locales
    • Eg. Polish - lipiec (nominative) vs. lipca (genitive)
      • lipiec 2008
      • 28 lipca 2008
  • Day of week
    • Very short abbreviation
    • Not always the first letter of day of week name
    • Eg. Chinese: 星期日 ⇒ 日
  • The first day of week
    • Sunday is the first day of week in many regions, but it’s not true in some regions.
month day of week names in cldr
Month/Day of Week Names in CLDR
  • 3 different widths - wide / abbreviated / narrow
  • 2 context types – format / stand-alone

Month name example - January

Day of week name example - Sunday

date and time interval
Date and Time Interval
  • When displaying a date interval, duplicated date fields could be stripped off.
    • 3 possible patterns depending on combination of start date and end date
      • July 20–26, 2008
      • July 20 – August 1, 2008
      • July 20, 2008 – July 19, 2009
    • Different combination patterns in different locales
      • 20–26 July 2008
      • 20 July – 1 August 2008
      • 20 July 2008 – 19 July 2009
date time interval in cldr
Date/Time Interval in CLDR
  • Each <intervalFormatItem> is associated with as “skeleton” pattern and contains one or more patterns
  • A <greatestDifference> element contains a pattern which will be used when the greatest difference of two given dates matches its “id” attribute

<intervalFormatItem id="yMMMd">

<greatestDifference id="y">MMM d, yyyy – MMM d, yyyy</greatestDifference>

<greatestDifference id="M">MMM d – MMM d, yyyy</greatestDifference>

<greatestDifference id="d">MMM d–d, yyyy</greatestDifference>


other challenges
Other Challenges
  • Various combinations of date fields and widths
    • “Sat 7/26”
      • The UI requires to display short format including month, day of month and day of week, but not year
      • The pattern could be changed depending on the locale
        • “Sat 26/7” for en_GB
        • “7/26(土)” for ja_JP
  • Week number
    • Week number is commonly used in European countries
    • The way of calculating week numbers in a year may vary depending on local conventions
flexible date format support in cldr 1
Flexible Date Format Support in CLDR (1)
  • <availableFormats> contains various <dateFormatItem>
  • Each <dateFormatItem> has id attribute representing “skeleton”
  • “skeleton” contains only field information in a canonical order
  • A CLDR consumer provides a “skeleton” – When the matching “skeleton” is available in the locale, the associated pattern is returned. If not, closest match which contains all requested fields is returned.


<dateFormatItem id="MMMEd" draft="provisional">E d MMM</dateFormatItem>

<dateFormatItem id="MMMMd" draft="provisional">d MMMM</dateFormatItem>

<dateFormatItem id="MMdd" draft="provisional">dd/MM</dateFormatItem>

<dateFormatItem id="Md" draft="provisional">d/M</dateFormatItem>

<dateFormatItem id="yyMMM" draft="provisional">MMM yy</dateFormatItem>

<dateFormatItem id="yyyyMM" draft="provisional">MM/yyyy</dateFormatItem>

<dateFormatItem id="yyyyMMMM" draft="provisional">MMMM yyyy</dateFormatItem>


flexible date format support in cldr 2
Flexible Date Format Support in CLDR (2)
  • When any <dateFormatItem> element does not satisfy the matching criteria, use the rules defined by <appendItems> to append missing fields to one of the existing format.


<appendItem request="Day">{0} ({2}: {1})</appendItem>

<appendItem request="Day-Of-Week">{0} {1}</appendItem>

<appendItem request="Era">{0} {1}</appendItem>

<appendItem request="Hour">{0} ({2}: {1})</appendItem>

<appendItem request="Minute">{0} ({2}: {1})</appendItem>

<appendItem request="Month">{0} ({2}: {1})</appendItem>

<appendItem request="Quarter">{0} ({2}: {1})</appendItem>

<appendItem request="Second">{0} ({2}: {1})</appendItem>

<appendItem request="Timezone">{0} {1}</appendItem>

<appendItem request="Week">{0} ({2}: {1})</appendItem>

<appendItem request="Year">{0} {1}</appendItem>


week data in cldr
Week Data in CLDR
  • <weekData>
    • minDays: minimum days in the first week
    • firstDay: first day in a week
    • weekendStart/weekendEnd: start/end day of weekend


<minDays count="1" territories="001" />

<minDays count="4" territories="AT BE CA CH DE DK FI FR IT LI LT LU MC MT NL NO SE SK" />

<minDays count="4" territories="CD" draft="true" />

<firstDay day="mon" territories="001" />

<firstDay day="fri" territories="MV" />

<firstDay day="sat" territories="AE AF BH DJ DZ EG ER ET IQ IR JO KE KW LB LY MA OM QA SA SD SO TN YE" />

<firstDay day="sun" territories="AS AU AZ BW CA CN FO GE GL GU HK IE IL IS JM JP KG KR LA MH MN MO MP


<firstDay day="sun" territories="ET MW NG TJ" draft="true" />

<firstDay day="sun" territories="GB" draft="true" alt="variant" references="Shorter Oxford Dictionary (5th edition, 2002)"/>

<firstDay day="thu" territories="SY" />

<weekendStart day="sat" territories="001"/>

<weekendStart day="fri" territories="EG IL SY"/>

<weekendStart day="sun" territories="IN"/>

<weekendStart day="thu" territories="AE BH DZ IQ JO KW LB LY MA OM QA SA SD TN YE AF IR"/>

<weekendEnd day="sun" territories="001"/>

<weekendEnd day="fri" territories="AE BH DZ IQ JO KW LB LY MA OM QA SA SD TN YE AF IR"/>

<weekendEnd day="sat" territories="EG IL SY"/>


design implementation tips
Design/Implementation Tips
  • Keep internal date/time representation locale-independent
    • Localized format may vary depending on implementation
    • Use standard format such as ISO8601 for data exchange
  • Do not hardcode format patterns in your source code
  • Do not put format patterns in resource bundles with other localizable messages!
    • Locale support is more than UI translation
    • Translation vendors are usually not able to handle regional variants
    • You should be able to find solutions in CLDR/ICU – if no available, file bugs to request new features
  • Avoid date/time data entry by text
    • Formatting date/time is complicated, so is parsing
    • Use UI widget to eliminate ambiguous data entry
  • Understand regional conventions of calendar system
    • Rules for calculating some calendar fields may vary
  • Be prepared to support non-Gregorian calendar systems
    • For example,
      • Buddhist calendar is the most preferred calendar system in Thai
      • Japanese calendar support may be required depending on target sectors
understanding time zone formatting and parsing
Understanding Time Zone Formatting and Parsing
  • CLDR’s approach for supporting time zone formatting
  • Choosing a right time zone format type for your needs
  • Tips for processing date/time with time zone

time zone implementations
Time Zone Implementations
  • The tz database (a.k.a Olson database)
    • 568 zones (436 unique zones / 132 aliases) (2008d)
    • Support historic time transitions since late 19th century
    • At least 1 zone per country/region
    • Time zone abbreviations for display (3 or 4 letter ASCII alphabet), such as “EST”, “JST”…
    • Used by *nix systems (Solaris, Linux, AIX, Mac OS X…) and Java
  • MS Windows time zone
    • 84 zones (Windows Vista), some are obsolete
    • Support historic rules (2005 and beyond) in Vista/2008 Server (Dynamic DST)
    • A zone is shared by multiple cities/countries
    • Time zone display names including the standard offset and common name or exemplar cities, such as “(GMT-05:00) Eastern Time (US & Canada)”, “(GMT+09:00) Osaka, Sapporo, Tokyo”…
time zone format types in cldr 1
Time Zone Format Types in CLDR (1)
  • Generic location format
    • Designed for populating choice lists for time zones
    • Uniquely mapped to “canonical” zone IDs
    • Examples
      • Europe/Rome ⇔ Italy Time [en]
      • America/New_York ⇔ United States (New York) Time [en]
      • America/New_York ⇔ Hora de Estados Unidos (New York) [es]
  • Generic non-location format
    • Designed for recurring events, meetings, or anywhere people do not want to be overly specific
    • Two widths – long/short
    • Examples
      • America/New_York ⇒ ET [en/short]
      • America/New_York ⇒ Eastern Time [en/long]
      • America/Montreal ⇒ Eastern Time [en/long]
time zone format types in cldr 2
Time Zone Format Types in CLDR (2)
  • Generic partial location format
    • A variant of generic non-location format – used as a fallback name when the generic non-location format is not specific enough
    • Two widths – long/short
    • Examples
      • America/Mexico_City ⇒ Hora central (Ciudad de México) [es_US/short/Mar 9 – April 6, 2008]
      • America/Chicago ⇒ Hora central (Chicago) [es_MX/short/Mar 9 – April 6, 2008]
  • Specific (non-location) format
    • Designed to distinguish between standard time and daylight time
    • Two widths – long/short
    • Examples
      • America/New_York ⇒ EST [en/short/standard time]
      • America/New_York ⇒ EDT [en/short/daylight time]
      • America/New_York ⇒ Eastern Standard Time [en/long/standard time]
      • America/Montreal ⇒ Eastern Standard Time [en/long/standard time]
time zone format types in cldr 3
Time Zone Format Types in CLDR (3)
  • Localized GMT format
    • Designed for representing the offset from GMT
    • Local decimal digits are used
    • Examples
      • America/New_York ⇒ GMT-05:00 [en/standard time]
      • America/New_York ⇒ GMT-04:00 [en/daylight time]
      • America/New_York ⇒ Гриинуич-0500 [bg/standard time]
  • RFC 822 format
    • Locale in-sensitive “fixed” format representing the offset from GMT defined by RFC 822
    • ASCII decimal digits are always used
    • Examples
      • America/New_York ⇒ -0500 [standard time]
      • America/New_York ⇒ -0400 [daylight time]
cldr metazone
CLDR Metazone
  • A metazone is an grouping of one or more internal zones that share common non-location display names
    • Following zones are currently associated with a metazone “America_Eastern” (CLDR 1.6.1)America/Nassau, America/Resolute, America/Coral_Harbour, America/Thunder_Bay, America/Nipigon, America/Toronto, America/Montreal, America/Iqaluit, America/Pangnirtung, America/Port-au-Prince, America/Jamaica, America/Cayman, America/Panama, America/Grand_Turk, America/Indiana/Vincennes, America/Indiana/Petersburg, America/Indiana/Marengo, America/Indiana/Winamac, America/Indianapolis, America/Louisville, America/Indiana/Vevay, America/Kentucky/Monticello, America/Detroit, America/New_York
  • Each metazone has a set of localizable names
    • Following names are used for metazone “America_Eastern” (CLDR 1.6.1)
time zone short abbreviation problem
Time Zone Short Abbreviation Problem
  • 2 to 4 letter ASCII alphabets abbreviations are used for short names, such as ET, EST, PDT…
  • The extent to which time zone abbreviations are understood varies heavily by region
    • For example, how many people recognize EAT (East Africa Time) in US?
  • CLDR’s solution - a boolean value associated with a zone/metazone “commonlyUsed” to enable/disable short abbreviations
    • Metazone “Africa_Eastern” has a short standard name “EAT” for English locales
    • For metazone “Africa_Eastern”
      • commonlyUsed = true in en_ZA [English (South Africa)]
      • commonlyUsed = false in en_US [English (United States)]
ambiguous time with generic format
Ambiguous Time with Generic format
  • Daylight ⇒ Standard transition
    • Sunday, November 2, 2008 01:30:00 Pacific Time?
    • Valid, happens twice
    • Generic format cannot distinguish between 1:30 PST and 1:30 PDT
  • Standard ⇒ Daylight transition
    • Sunday, March 9, 2008 02:30:00 Pacific Time?
    • Invalid!
    • 30 minutes 1 second after 01:59:59? or 30 minutes before 03:00:00?
tips for processing date time with time zone
Tips for Processing Date/Time with Time Zone
  • For serializing future date/time data in text format, use RFC 822 format with zone ID
    • Time zone rules could be changed
    • GMT offset information along with zone ID is sufficient to fix up data
  • The result of java.util.Date#toString() might be ambiguous
    • “CST” is used for both “America/Chicago” and “Asia/Shanghai” in Java
    • CLDR does not use a same name for multiple time/meta zone
  • Many zones in tz database use LMT (Local Mean Time) as initial offset
    • LMT is calculated from the longitude and the GMT offset has a fraction of minute
    • ISO8601 / RFC822 / Java GMT format does not have second field, so it may not roundtrip
  • Minimize the dependencies on Windows time zone in multi-platform applications
    • Some windows time zones are not well maintained
    • No historic time zone rule support before Vista/2008 server
    • Mapping between Windows time zones and the tz database is 1-to-n
  • Unicode CLDR project -
  • ICU Project -
  • tz database -
