単純梁の反力可視化模型Ⅱの製作

山田研究室

石坂 緑


2889807

VB=1kN(1000N)


2889807

VB=-1kN(-1000N)


2889807

∑Y=VA+VB-0.5+1.0+0.5-1.0=0

∑MA=-1.0×0.11-0.5×0.22+1.0×0.33-0.33VB=0

VB=0.11/0.33=0.333….kN

VA=-0.333….kN


2889807

SPECIALTHANKS

構造研究室の先生方 構造研究室の研究生のみんな
