deploying windows server 2012 from bare metal server core minimal server interface and more

WSV309

Deploying Windows Server 2012: From Bare Metal, Server Core, Minimal Server Interface, and More

Andrew Mason

Principal Group Program Manager

Microsoft Corporation

agenda
Agenda
  • Deployment methods and what’s new in Windows Deployment Services (WDS)
  • Windows Server 2012 Installation Options
  • Minimal Server Interface
  • Minimizing disk space using Features on Demand
high touch image based setup
High Touch – Image Based Setup
  • Essentially the same as Windows Server 2008 R2 Setup
      • Existing scripts and deployment tools that you have for Windows Server 2008 R2 will work with Windows Server 2012
    • Provides a single unified process with which all customers can install Windows
      • Speed improvements
  • IBS Setup options
    • Upgrade: Keep files, settings, and applications
      • Custom: Install only
lite touch
Lite Touch
  • Microsoft Deployment Toolkit (MDT) 2012
    • Step 1: Obtain the Required Software
      • http://go.microsoft.com/fwlink/?LinkId=76620
    • Step 2: Prepare the MDT Environment
    • Step 3: Configure MDT to Create the Reference Computer
    • Step 4: Deploy Windows Server 2012 and Capture an Image of the Reference Server
    • Step 5: Configure MDT to Deploy Windows Server 2012 to the Target Server
    • Step 6: Deploy the Captured Image of the Reference Server to the Target Server
windows deployment services wds
Windows Deployment Services (WDS)
  • End-to-end solution for clean installations over the network using PXE boot
  • Why use WDS?
    • Reliable – in use since 2006
    • Proven – by external and internal customers
    • Scalable – can deploy over 300 machines at a time
    • Powerful – flexible and extensible
    • Simple – improved manageability
wds deployment process
WDS Deployment Process

Plan,

manage,

diagnose

Boot

with

PXE

Get

into

WinPE

Apply

full OS


Inject

drivers

First boot

and OOBE

Standalone mode

MMC improvements

WDS infrastructure to customize

Diagnosability enhancements

standalone mode
Standalone Mode
  • Standalone server
    • New server configuration option
    • Decoupled from Active Directory
  • Local data store
  • Works with management tools
    • MMC GUI snap-in and WDSUtil command line tool
mmc improvements
MMC Improvements
  • Device management now in the MMC
  • Client Unattend file generator
  • New server properties options
    • Max TFTP block size
    • UDP port policy
  • Image priority
  • Expected Deployment Results wizard
    • See the results of your choices before you deploy
    • Presents the deployment options for a certain device
    • Included in the MMC and also available from the command line
wds and metadata
WDS and Metadata
  • A new extension model for WDS
    • WDS infrastructure for custom deployments
    • Exposed in UI
    • Additional low-level metadata configuration using WDSUtil
  • Management possibilities with metadata
    • Generic device management
    • Device groups
    • Boot/install image filtering
diagnose your deployments
Diagnose Your Deployments
  • Server trace log updates
    • ETW-based logs
    • Support for /trace parameter
    • Setuperr.log/Setupact.log still available
  • Performance counters
    • Provides better understanding of what the server is “doing”
    • Added many for Windows 8 – now over 50
wds deployment process1
WDS Deployment Process

Plan,

manage,

diagnose

Boot

with

PXE

Get

into

WinPE

Apply

full OS


Inject

drivers

First boot

and OOBE

WDS Server is configured and ready

Server PXE boots

WDS Server responds with boot program

x86 UEFI support

IPv6 PXE support

x86 uefi and ipv6 pxe support
x86 UEFI and IPv6 PXE Support
  • UEFI 2.3.1 support
    • PXE extended to x86 UEFI architecture
    • Separate settings for BIOS and UEFI
  • IPv6 support for PXE
    • UEFI requires firmware support in UNDI and UEFI version (2.3.1 or later)
    • Requires stateful DHCPv6
    • IPv6 is also supported in TFTP, multicast, WDS client, and setup.exe
wds deployment process2
WDS Deployment Process

Plan,

manage,

diagnose

Boot

with

PXE

Get

into

WinPE

Apply

full OS


Inject

drivers

First boot

and OOBE

TFTP transfer of boot and OS loader

Variable-size transmission window

TFTP shared UDP port allocation

TFTP shared client buffer

tftp download enhancements
TFTP Download Enhancements
    • Dynamically determined variable-size transmission window
    • Tripled performance on Gb networks from ~8 MB to ~20-30 MB per second
    • Accommodates clients with “small” NIC buffers
  • Shared UDP port allocation
    • Improves scalability - Uses 16 ports by default
    • Adds performance counters
  • Shared client buffer
    • Detects clients downloading the same file
    • Uses shared in-memory buffer of the file for all clients
    • Reduces memory use and improves performance
    • Adds performance counters
wds deployment process3
WDS Deployment Process

Plan,

manage,

diagnose

Boot

with

PXE

Get

into

WinPE

Apply

full OS


Inject

drivers

First boot

and OOBE

In-place WIM multicast apply

Multicast performance improved

VHDX apply

WDS is running in WinPE

Apply of image begins

in place wim multicast apply
In-place WIM Multicast Apply
  • What it does
    • Eliminates download of the WIM before applying to the local disk
    • Allows the WIM to be decompressed on-the-fly as received over the network
  • Why it’s good
    • Faster process that uses a smaller disk footprint
  • What’s needed to use it?
    • Minimum of 2 GB RAM
multicast performance improved
Multicast Performance Improved
  • Smaller block size by default
    • Eliminates fragmentation
  • Higher MC transmission rate on Gb network
    • New congestion control algorithm
    • More concurrent operations on both the server and client sides
vhdx apply
VHDX Apply
  • What it does
    • Applies VHDX file directly to disk using sector-based deployment
    • Multiple-partition deployment for OS & recovery partition in single image
    • Must use VHDX format, not VHD
  • WDS does not create the VHDX
  • Available for
    • WDSMCast.exe and WDSClient.exe
windows server 2012 deployment options
Windows Server 2012 Deployment Options
  • Server Core
    • The default deployment option
    • RSAT for remote GUI management
    • PowerShell support achieves critical mass with 2300+ cmdlets
    • More roles and features available
  • Server with a GUI
    • Equivalent of full Server in Windows Server 2008 R2
    • Provided for backwards compatibility
windows server 2012 configuration levels
Windows Server 2012 Configuration Levels
  • Classic “Full Server”
  • Full Metro-style GUI shell
  • Install Desktop Experience to run Metro-style apps

Server with a GUI

Minimal Server Interface

  • NEWFull Server without Server Graphical Shell
  • No Explorer, Internet Explorer or associated files
  • MMC, Server Manager, and a subset of Control Panel applets are still installed
  • Provides many of the benefits of Server Core for those applications or users that haven’t yet made the transition

Server Core

  • Server Core
  • NEWCan move between Server Core and Full Server by simply installing or uninstalling components
transitioning between server core and server
Transitioning between Server Core and Server
  • Server Manager
    • Remote only to go from Server Core to Server
  • PowerShell
transitioning with server manager ps cmdlets
Transitioning with Server Manager: PS cmdlets
  • Full Server to Server Core
  • Server Core to Full Server
  • POWERSHELL
  • Uninstall-WindowsFeatureServer-Gui-Mgmt-Infra -Restart

Single reboot required to restart all services

  • POWERSHELL
  • Install-WindowsFeatureServer-Gui-Mgmt-Infra,Server-Gui-Shell -Restart

NEWCan install multiple features with one command by separating with commas

minimal server interface
Minimal Server Interface
  • It’s a Server with a GUI…
    • …but without Windows Explorer and Internet Explorer
    • Provides some of the benefits of Server Core for those products or admins that can’t fully make the transition to Server Core
  • Enables administrators and developers to begin shifting to support headless servers
    • Remove dependencies on Shell and Internet Explorer
    • Enable full remote management
    • Higher availability
converting to and from server graphical shell
Converting to and from Server Graphical Shell
  • Server Manager
  • Uninstall Server Graphical Shell:
  • Install Server Graphical Shell:
  • Server Core to Minimal Server Interface
  • POWERSHELL
  • Uninstall-WindowsFeatureServer-Gui-Shell-Restart
  • POWERSHELL
  • Install-WindowsFeatureServer-Gui-Shell-Restart
  • POWERSHELL
  • Install-WindowsFeatureServer-Gui-Mgmt-Infra-Restart
limitations of the minimal server interface 1 2
Limitations of the Minimal Server Interface (1/2)
  • Common Dialog box is functional (except networking)
  • Any UI with dependencies on items implemented as Shell Namespace Extensions will not work
    • Certain CPLs are namespace extensions, e.g. Networking
  • Internet Explorer is not available when Server Graphical Shell is uninstalled
    • Links in UI won’t work
    • Help isn’t available – calls to HTML Help API will return NULL!
limitations of the minimal server interface 2 2
Limitations of the Minimal Server Interface (2/2)
  • Some file associations and protocol handlers are not available
    • http://
    • file://
    • *.chm
  • Some DLL files not installed
    • Check for dependencies or delay loads might fail!
      • DUMPBIN (Windows SDK)
      • Dependency Walker (http://www.dependencywalker.com, freeware)
    • Test your applications on the Minimal Server Interface!
detecting the state of server graphical shell
Detecting the state of Server Graphical Shell
  • Using the Registry
    • HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows NT\CurrentVersion\Server\ServerLevels
  • WMI
    • Win32_ServerFeature class can be used to determine installed roles and features
    • http://msdn.microsoft.com/en-us/windows/cc280268
      • Server-Gui-Shell has an ID of 99
      • Server-Gui-Mgmt-Infra has an ID of 478
reducing on disk footprint
Reducing on Disk Footprint
  • All Roles and Features are copied to the Windows Side by Side store (\windows\winsxs) during Setup
    • Uses disk space to store roles and features that may never be installed
  • Windows Server 2012 now has Features on Demand
    • Allows an administrator to remove unneeded roles and features
    • Files for removed roles and features are deleted from the Side by Side store
    • Can be used to minimize VHD footprint
    • http://technet.microsoft.com/en-us/library/jj127275
server core installation option
Server Core Installation Option
  • Server Core installation option is created using Features on Demand
    • Unsupported Roles and Features are removed from \windows\winsxs to maintain minimal footprint
    • Show as Removed in PowerShell
    • Show as Payload Removed in Dism.exe
removing roles and features
Removing Roles and Features
  • Files for <FeatureName> will be deleted from the \windows\winsxs folder
  • Must use PowerShell, remove is not available in Server Manager
  • POWERSHELL
  • Uninstall-WindowsFeature <FeatureName> -Remove
sources for removed roles and features
Sources for Removed Roles and Features
  • Reinstallation Sources
    • Windows Update
      • If server has Internet access, it can use WU
    • Use the WIM directly
    • Mount WIM
      • Can mount the install WIM
    • Running Server’s \windows\winsxs folder
  • Location can be specified via Group Policy:
    • Computer Configuration > Administrative Templates > System > “Specify settings for optional component installation and component repair”
mounting the wim
Mounting the WIM
  • Create a folder to mount the WIM in:
  • Determine the index of Server with a GUI:
  • Mount the WIM:
  • Install role or feature:
  • CMD
  • mkdirc:\mountdir
  • CMD
  • Dism /get-wiminfo /wimfile:<drive>:sources\install.wim
  • CMD
  • dism /mount-wim /WimFile:<drive>:\sources\install.wim /Index:<#_from_step_2> /MountDir:c:\mountdir /readonly
  • POWERSHELL with mounted WIM
  • Install-WindowsFeatureServer-Gui-Mgmt-Infra,Server-Gui-Shell –Restart –Source c:\mountdir\windows\winsxs
using the wim directly
Using the WIM Directly
  • Determine the index of Server with a GUI:
  • Install role or feature specifying a source of WIM:<path>:<#_from_step_1>
  • CMD
  • Dism /get-wiminfo /wimfile:<drive>:sources\install.wim
  • POWERSHELL
  • Install-WindowsFeatureServer-Gui-Mgmt-Infra,Server-Gui-Shell –Restart –Source wim:<drive>:\sources\install.wim:4
reinstalling roles and features
Reinstalling Roles and Features
  • Server Manager
  • PowerShell
  • POWERSHELL
  • Install-WindowsFeature<FeatureName> -Source <Source>
server core installation option to server
Server Core Installation Option to Server
  • If Server Core was installed using Setup converting to Server requires a source
    • With a mounted WIM
    • Using the WIM directly
  • POWERSHELL with mounted WIM
  • Install-WindowsFeatureServer-Gui-Mgmt-Infra,Server-Gui-Shell –Restart –Source c:\mountdir\windows\winsxs
  • POWERSHELL
  • Install-WindowsFeatureServer-Gui-Mgmt-Infra,Server-Gui-Shell –Restart –Source wim:d:\sources\install.wim:4
net 3 5 and features on demand
.NET 3.5 and Features on Demand
  • Not included in the Windows Server 2012 image
  • Application Compatibility shim will prompt to install if running an application that requires .NET 3.5
  • Installation sources
    • Windows Update
    • Install media \sources\sxs
  • Whitepaper on .NET 3.5 in Windows Server 2012
    • http://technet.microsoft.com/en-us/library/hh831809#BKMK_FoD
    • http://msdn.microsoft.com/library/windows/hardware/hh975396
      • Covers Client and Server
sia wsv and vir track resources
SIA, WSV, and VIR Track Resources

Talk to our Experts at the TLC

#TEWSV309

Hands-On Labs

DOWNLOAD Windows Server 2012 Release Candidate

microsoft.com/windowsserver

DOWNLOAD Microsoft System Center 2012 Evaluation

microsoft.com/systemcenter

resources
Resources

Learning

TechNet

  • Connect. Share. Discuss.
  • Microsoft Certification & Training Resources

http://europe.msteched.com

www.microsoft.com/learning

  • Resources for IT Professionals
  • Resources for Developers
  • http://microsoft.com/technet

http://microsoft.com/msdn

submit your evals online
Evaluations

Submit your evals online

http://europe.msteched.com/sessions

slide44

© 2012 Microsoft Corporation. All rights reserved. Microsoft, Windows, Windows Vista and other product names are or may be registered trademarks and/or trademarks in the U.S. and/or other countries.

The information herein is for informational purposes only and represents the current view of Microsoft Corporation as of the date of this presentation. Because Microsoft must respond to changing market conditions, it should not be interpreted to be a commitment on the part of Microsoft, and Microsoft cannot guarantee the accuracy of any information provided after the date of this presentation. MICROSOFT MAKES NO WARRANTIES, EXPRESS, IMPLIED OR STATUTORY, AS TO THE INFORMATION IN THIS PRESENTATION.
