Presentation Transcript
what is gis database
What is GIS database?

Clicking on a building, the detailed information are shown in the pop-up table

Records (formed by rows and columns)

Descriptive information about the geographical features

A spatial feature consists of a unique record in the database; each distinct feature is defined by unique ID

Source: www.onemap.sg

working with tables data type
Working with Tables – Data Type
  • Field & Data Type
  • Different fields will store different kind of values
  • Choice of field type to match with type of data

Text/String

Date

Double

Text/String

Short

Hyperlink

geospatial data textual geometry
Geospatial data (textual & geometry)
  • Attribute Data
  • Spatial Data
  • GIS manages both spatial & attribute data

e.g. Building

Spatial

Attributes

geo brain tickler 6
Geo-Brain Tickler 6:

Which is the common field you can link table 1 and table 2?

Table 1

BranchRef

StaffNum

Postcode

Manager

Table 2

Branch Locations

***Multiple tables can be linked together based on their common keys. Table 1 and table 2 both consists of field named BranchRef. After linking/joining both tables, you would be able to find out which staffs managed by respective branch manager when clicking on the branch location on the map.

Ans: BranchRef

geo brain tickler 7
Geo-Brain Tickler 7:

1 table

3 tables

2 tables

None of the above answers

***It is not possible to store different geometries within a table. In this scenario, buildings layer has its own table, so as other layers.

Ans: 3 tables

How many tables you need to design if you have 3 layers (i.e Building footprints , Roads, Landlots) represented in different form of geometries?

chapter five vector analysis

Chapter Five: Vector Analysis

Proximity Analysis, Route Planning

data analysis vector data
Data Analysis – Vector Data

In reality, we deal with geographical features everyday. Right at the moment you wake up in the morning, you start to plan your schedule of the day. You might think of going from location A to B, then from B to C to D; what mode of transportation you will use to reach the destinations; what is the estimated duration to reach the destination and so on... GIS helps you to answer these sort of questions more efficiently and visually.

  • To answer the geographical-related questions, you can utilise GIS to analyse either single geographical layer or multiple layers. Firstly, you need to understand the Spatial Relationships formed within geographical layers.
spatial relationship
Spatial Relationship

You can store many geographical layers within GIS system; different thematic layers; both vector and raster data.

Each geographical layer has a unique relationship formed with other layers.

Example: Roads connects from east to west, shopping mall 1 locates next to post office, buildings are located within particular town boundary etc.

How GIS maps geographical entities in real world?

Source: www.esri.com

slide11

Satellite Imagery

Transportation Data

Health Data

Demographic Data

Business Data

Property Data

Weather Data

Terrain Data

You can integrate many

thematic data into GIS

Geographical Information System (GIS)

you can use gis to
You can use GIS to:
  • Find the high density area of residential housing
  • Locate potential area to set up new childcare centre
  • How accessible the public transportation system in that specific area (i.e MRT, bus)
one of the most basic questions asked of a gis is what s near what
One of the most basic questions asked of a GIS is "what's near what?"

How close is this well to a landfill?

Do any roads pass within 1,000 meters of a stream?

What is the distance between two locations?

What is the nearest or farthest feature from something?

What is the distance between each feature in a layer and the features in another layer?

What is the shortest street network route from some location to another?

How many childcare centres that are located within 1 km from my flat?

Where are the clinics, hospitals, polyclinics or 24 hrs emergency clinics from my house?

Where is the nearest shopping malls from my office?

proximity analysis buffer
Proximity Analysis (Buffer)

Source: www.onemap.sg

School Query service

  • Create a circular region around the selected point for proximity analysis
  • Search within feature or search nearby feature
  • Select feature from another layer

Find buildings near to selected primary school

Find schools near to a selected building

route planning using gis
Route Planning Using GIS

http://www.esri.com/~/media/Files/Pdfs/library/newsletters/transportation-gis-trends/summer-2012.pdf

For more reading:

Transportation professionals the world over have discovered and embraced GIS as an important tool in managing, planning, evaluating, and maintaining transportation systems.

examples road network analysis
Examples: Road Network Analysis

What is the quickest way to get from Point A to point B?

Which ambulances or patrol cars can respond quickest to an incident?

What market areas does a business cover?

What are live or historical traffic conditions like, and how do they affect my network analysis result?

Source: www.esri.com

geo brain tickler 8
Geo-Brain Tickler 8:

Can you get your route planned via OneMap (www.onemap.sg)? Which service on OneMap you will be using if you would like to find out the list of service bus passes through particular roads?

Answer: BusRoute Explorer

geo brain tickler 9
Geo-Brain Tickler 9:

Answer: Get Directions

(*you can choose mode of transportation: drive, bus or combination of Bus & MRT)

A tourist would like to plan his/her daily tour visiting Singapore places of interest via public transportation mode, which service on OneMap you would suggest he/she to refer to?

geo brain tickler 10
Geo-Brain Tickler 10:

Using OneMap, generate the cheapest route of taking bus from Esplanade to Asian Civilisations Museum. *set 500 m for allowable walking distance.

Q1: How much is the cheapest bus fare?

Q2: Few solutions are proposed, which solution provides the cheapest and the fastest route to reach Asian Civilisations Museum?

geo brain tickler 10 answer
Geo-Brain Tickler 10: Answer

Q1: How much is the cheapest bus fare?

S$0.73

Q2: Few solutions are proposed, which solution provides the cheapest and the fastest route to reach Asian Civilisations Museum?

Solution 1: Total travel and wait/walk time = appx 13 minutes
