British Museum Library, London

Picture Courtesy: flickr


British Museum Library, London

Picture Courtesy: flickr

topic modeling
Topic Modeling
  • Methods for automatically organizing, understanding, searching and summarizing large electronic archives.
    • Uncover hidden topical patterns in collections.
    • Annotate documents according to topics.
    • Using annotations to organize, summarize and search.
topic modeling1
Topic Modeling

NIH Grants Topic Map 2011

NIH Map Viewer (

topic modeling applications
Topic Modeling Applications
  • Information retrieval.
  • Content-based image retrieval.
  • Bioinformatics
overview of this presentation
Overview of this Presentation
  • Latent Dirichlet allocation (LDA)
  • Approximate posterior inference
    • Gibbs sampling
  • Paper
    • Fast collapsed Gibbs sampling for LDA
latent dirichlet allocation

Latent Dirichlet Allocation

David Blei’s Talk

Machine Learning Summer School, Cambridge 2009

D. M. Blei, A. Y. Ng, and M. I. Jordan, "Latent dirichlet allocation," The Journal of Machine Learning Research, vol. 3, pp. 993-1022, 2003.

probabilistic model
Probabilistic Model
  • Generative probabilistic modeling
    • Treats data as observations
    • Contains hidden variables
    • Hidden variables reflect thematic structure of the collection.
  • Infer hidden structure using posterior inference
    • Discovering topics in the collection.
  • Placing new data into the estimated model
    • Situating new documents into the estimated topic structure.
posterior distribution
Posterior Distribution
  • Only documents are observable.
  • Infer underlying topic structure.
    • Topics that generated the documents.
    • For each document, distribution of topics.
    • For each word, which topic generated the word.
  • Algorithmic challenge: Finding the conditional distribution of all the latent variables, given the observation.
lda as graphical model
LDA as Graphical Model





posterior distribution1
Posterior Distribution
  • From a collection of documents W, infer
    • Per-word topic assignment zd,n
    • Per-document topic proportions d
    • Per-corpus topic distribution k
    • Use posterior expectation to perform different tasks.
posterior distribution2
Posterior Distribution
  • Evaluate P(z|W): posterior distribution over the assignment of words to topic.
  •  and  can be estimated.
computing p z w
Computing P(z|W)
  • Involves evaluating a probability distribution over a large discrete space.
  • Contribution of each zd,n depends on:
    • All z-n values.
    • NkWn-># of times word Wd,n has been assigned a topic k.
    • Nkd-># of times a word from document d has been assigned a topic k.
    • Sampling from the target distribution using MCMC.
approximate posterior inference gibbs sampling

Approximate posterior inference:Gibbs Sampling

C. M. Bishop and SpringerLink, Pattern recognition and machine learning vol. 4: Springer New York, 2006.

Iain Murray’s Talk

Machine Learning Summer School, Cambridge 2009

  • When exact inference is intractable.
  • Standard sampling techniques have limitation:
    • Cannot handle all kinds of distributions.
    • Cannot handle high dimensional data.
  • MCMC techniques do not have these limitations.
  • Markov chain:

For random variables x(1),…,x(M),

p(x(m+1)|x(1),…,x(m))=p(x(m+1)|x(m)) ; m{1,…M-1}

gibbs sampling
Gibbs Sampling
  • Target distribution: p(x) = p(x1,…,xM).
  • Choose the initial state of the Markov chain: {xi:i=1,…M}.
  • Replace xi by a value drawn from the distribution p(xi|x-i).
    • xi: ith component of Z
    • x-i: x1,…,xM but xi omitted.
  • This process is repeated for all the variables.
  • Repeat the whole cycle for however many samples are needed.
why gibbs sampling
Why Gibbs Sampling?
  • Compared to other MCMC techniques, Gibbs sampling is:
    • Easy to implement
    • Requires little memory
    • Competitive in speed and performance
gibbs sampling for lda
Gibbs Sampling for LDA
  • The full conditional distribution is:

Probability of Wd,n under topic k

Probability of topic k in document d

Z = k

gibbs sampling for lda1
Gibbs Sampling for LDA
  • Target distribution:
  • Initial state of Markov chain: {zn} will have value in {1,2,…,K}.
  • Chain run for a number of iterations.
  • In each iteration a new state is found by sampling {zn} from
gibbs sampling for lda2
Gibbs Sampling for LDA
  • Subsequent samples are taken after appropriate lag to ensure that their autocorrelation is low.
  • This is collapsed Gibbs sampling.
  • For single sample and  are calculated from z.
fast collapsed gibbs sampling for latent dirichlet allocation

Fast Collapsed Gibbs Sampling For Latent Dirichlet Allocation

Ian Porteous, David Newman, Alexander Ihler, Arthur Asuncion, Padhraic Smyth, Max Welling

University of California, Irvine

fastlda segments
FastLDA: Segments
  • Sequence of bounds on the Z: Z1,…, Zk
  • Z1  Z2  …  ZK = Z
  • Several slk…sKk segments for each topic.
  • 1st segment: conservative estimate on the probability of the topic given the upper bound Zk on the true normalization factor Z.
  • Subsequent segments: corrections for the missing probability mass for a topic given the improved bound.
upper bounds for z
Upper Bounds for Z
  • Find a sequence of improving bounds on the normalization constant.
  • Z defined in terms of component vectors.
  • Holder’s inequality to construct initial upper bound.
  • Bound intelligently improved for each topic.
fast lda algorithm
Fast LDA Algorithm
  • Algorithm:
    • Sort topics in decreasing order of Nkd
    • u ~ Uniform[0,1]
    • For topics in order:
      • Calculate length of segments.
      • For each next topic, Zk is improved.
      • When sum of segments > u:
        • Return topic and return.
  • Complexity:
    • Not more than O(K log K) for any operation.
  • Four large datasets:
    • NIPS full papers
    • Enron emails
    • NY Times news articles
    • PubMed abstracts
    •  = 0.01 and  = 2/K
    • Computations run on workstations with:
      • Dual Xeon 3.0Ghz processors
      • Code compiled by gcc version 3.4.

Speedup : 5-8 times

  • Speedup relatively insensitive to number of documents in the corpus.
  • Large Dirichlet parameter smooths the distribution of the topics within a document.
  • FastLDA needs to visit and compute more topics before drawing a sample.
  • Other domains.
  • Other sampling techniques.
  • Other distributions other than Dirichlet.
  • Parallel computation.
    • Newman et al. “Scalable parallel topic models”.
  • Deciding on the value of K.
  • Choices of bounds.
  • Reason behind choosing these datasets.
  • Are the values mentioned in the paper magic numbers?
  • Why were the words having count <10 discarded?
  • Assigning weights to words.
dirichlet distribution
Dirichlet Distribution
  • The Dirichlet distribution is an exponential family distribution over the simplex, i.e., positive vectors that sum to one.
  • The Dirichlet is conjugate to the multinomial. Given a multinomial observation, the posterior distribution of  is a Dirichlet.
