Presentation Transcript
slide1
Meningitis:

The role of climate for prediction

Andy Morse Ph.D.

Department of Geography

University of Liverpool

A.P.Morse@liv.ac.uk

Mark Cresswell Ph.D

EGS

Manchester Metropolitan University

1 0 background
1.0 Background

Meningococcal Meningitis

  • Bacterial meningitis (Neisseria meningitidis) causes epidemics
  • 12 serotypes are know only 4 cause epidemics A, B, C and W135
  • Group A generally causes epidemics in Africa although cases due to serogroups C, X and W135 are found.
  • B and C are more common in the U.K.
  • Vaccines exist for A, C, X, Y and W135
1 1 background
1.1 Background

Meningococcal Meningitis

  • Transmitted person to person (sneezing, coughing, kissing) (military recruits, students)
  • Average period of incubation 4 days ( 2 to 10days)
  • Estimated 10 to 25% carry the bacterial but can increase in epidemics
  • U.K. matter of education and seeking treatment
1 2 background
1.2 Background

Meningococcal Meningitis in Africa

  • Meningitis epidemic disease, highly seasonal - later half dry season
  • Epidemics every 5 to 10 years – kills young adults as well as children
  • Climatic connections are ‘not proven’ - low humidity (vapour pressure) and dust important factors
  • Epidemics cease with the onset of the rains

Figure from Cheesbrough,JS, Morse AP, Green SDR. Meningococcal meningitis

and carriage in western Zaire: a hypoendemic zone related to climate?

Epidemiology and Infection 1995: 114; 75-92

1 3 background
1.3 Background

West African Climate

  • Area dominated by seasonal rains produced by a monsoonal system
  • Strong latitudinal gradient in ‘wetness’ and thus climates and vegetation
  • Monsoon system is complex and not well understood
  • Leads to large interannual climate
1 4 background
1.4 Background

West Africa Atlas

1 5 background
1.5 Background

West African Climate

  • Monsoon System and AMMA experiments
1 6 background
1.6 Background

West African Climate

NDVI February

NDVI August

From MARA eshaw website http://www.mara.org.za/eshaw.htm

1 7 background
1.7 Background

Look at Hutchinson rainfall climate maps in unit folder

West African Climate

Animation from University of Liverpool Understanding Epidemics Website

http://www.liv.ac.uk/geography/research_projects/epidemics/MAL_intro.htm

Data from CLIVAR VACS Africa Climate Atlas at University of Oxford

1 10 background
1.10 Background

Epidemic Cycles

  • Many infectious diseases, in the tropics, have a strong seasonal cycle related to the seasonal climatic cycles
  • Climatically anomalous years can lead to epidemics
  • Time between trigger threshold to epidemic peak often too short to take effective intervention – need for skilful and timely seasonal climate forecast

Vaccine

Effect

Threshold

2 0 linking climate to disease
2.0 Linking climate to disease

Spatial Distribution Meningitis Epidemics 1841-1999 (n = c.425) 1

Example for meningitis in Africa

  • Extensive literature search was undertaken to identify reported epidemics
  • Published and grey literature were consulted

1 Molesworth A.M., Thomson M.C., Connor S.J., Cresswell M.P., Morse A.P., Shears P., Hart C.A., Cuevas L.E. (2002) Where is the Meningitis Belt?, Transactions of the Royal Society of Hygiene and Tropical Medicine, 96, 242-249.

2 1 linking climate to disease
2.1 Linking climate to disease

Example for meningitis in Africa

  • Statistical Model to produce a map of risk
  • Epidemiological data and climatic and environmental variables
  • Risk factors:
  • Land cover type and seasonal absolute humidity profile
  • Seasonal dust profile, Population density, Soil type
  • Significant but not included

in final model

  • Human factors not included

Molesworth, A.M., Cuevas,L.E., Connor, S.J., Morse A.P., Thomson, M.C. (2003). Environmental risk and meningitis epidemics in Africa, Emerging Infectious Diseases, 9 (10), 1287-1293.

2 2 linking climate to disease
2.2 Linking climate to disease

Example for meningitis in Africa

  • Cluster analysis to define areas with common seasonal cycle
  • Absolute humidity values
  • Used to produce

risk map shown above

Molesworth, A.M., Cuevas,L.E., Connor, S.J., Morse A.P., Thomson, M.C. (2003). Environmental risk and meningitis epidemics in Africa, Emerging Infectious Diseases, 9 (10), 1287-1293.

2 4 linking climate to disease
2.4 Linking climate to disease

Values to give an absolute humidity of about 10 gm-3

2 6 linking climate to disease
2.6 Linking climate to disease

Example for meningitis in Africa

  • Disease is complex and dry air and dust are not the only factors
  • Many human ones – immunity, nutrition and co-infection
  • However the environmental variables may lead to the population becoming more susceptible
  • The environmental variables may be predictable months in advance.
3 0 potential of seasonal forecasting
3.0 Potential of Seasonal Forecasting

Background and applications

  • Probabilistic forecasts are made routinely
  • Statistical models – more established – more regionally and single variable orientated – cannot work outside their training data – can work well e.g. spring SST to summer rains (West Africa)
  • Dynamic models – Ensemble Prediction Systems – experimental also operational too
  • Loaded dice example – loading and hence predictability changes with time and location
3 1 potential of seasonal forecasting
3.1 Potential of Seasonal Forecasting

Dynamic EPS products

  • Typical Products

from ECMWF

3 2 potential of seasonal forecasting
3.2 Potential of Seasonal Forecasting

Dynamic EPS products

  • Typical Products

from ECMWF

Probabilistic Seasonal

2 to 4 month lead time

3 3 potential of seasonal forecasting
3.3 Potential of Seasonal Forecasting

Combined products

International Research Institute for Climate Prediction (IRI),

Columbia University, New York

Seasonal Forecast 2 to 4 month lead time

3 4 potential of seasonal forecasting
3.4 Potential of Seasonal Forecasting

Dynamic EPS – issues for users and producers

  • Tailored verification
  • Verification of user parameters
  • Scale – downscaling
  • Bias correction
  • Weighting
  • Application model and method development – run with EPS
  • Product derived time scale cut off – medium, monthly, seasonal and beyond
  • Interdisciplinary nature of research
  • Taking of academic risk
3 5 potential of seasonal forecasting
3.5 Potential of Seasonal Forecasting

Product Verification

yellow through red - increasing predictive skillwhite through dark blue - little or no better than guesswork

Units = Gerrity skill score

Met. Office Seasonal Forecast Precip. AMJ

2 to 4 month lead time

3 8 potential of seasonal forecasting
3.8 Potential of Seasonal Forecasting

Liverpool Malaria Model – LMM

  • Dynamic model
  • Daily time step
  • Driven by temperature and precipitation
  • Observations, reanalysis, ensemble prediction systems
  • Developed within a probabilistic forecasting system – DEMETER
  • Continuing in EMSEMBLES
  • Model details Hoshen, M.B.and Morse, A.P. (2004) A weather-driven model of malaria transmission, Malaria Journal, 3:32 (6th September 2004) doi:10.1186/1475-2875-3-32 (14 pages)
  • Applied in an EPS in Morse, A.P., Doblas-Reyes, F., Hoshen, M.B., Hagedorn, R. and Palmer, T.N.(2005). A forecast quality assessment of an end-to-end probabilistic multi-model seasonal forecast system using a malaria model, Tellus A, 57 (3), 464-475
4 0 summary
4.0 Summary

The Forecasting Triangle

Providers

Users

Dissemination

Feedback

Forecasts

Demand

Training + Product Guidance and Development

Developers

with users and providers

4 1 summary
4.1 Summary
  • Probabilistic (and deterministic) forecasts are routinely produced operationally leads times days to seasons
  • This potential resource is under utilised by application user communities-

gaps in knowledge and awareness

issues with forecast skill and guidance in products

lack of user application know how and appropriate user application models

4 3 summary
4.3 Summary

Current and recent research projects

  • DEMETER EU FP5

ENSEMBLES EU FP6

Addressing development and application of ensemble prediction systems

  • AMMA-EU FP6,

AMMA-UK NERC,

West African monsoon observations, modelling impacts

5 0 conclusions
5.0 Conclusions

Infectious diseases must be modelled to allow use within emerging long range forecast technologies.

Much has been done to bridge gaps between forecaster and health user but still many gaps

Work is on going and a new ‘epimeteorology’ community is emerging

websites
Websites
  • WHO meningitis site http://www.who.int/mediacentre/factsheets/fs141/en/
  • Meningitis Research Foundation http://www.meningitis.org/
  • EU and NERC funded AMMA improve ability to predict the West African Monsoon and its impacts on intra-seasonal to decadal timescales. http://www.amma-eu.org/ and http://amma.mediasfrance.org/
  • EU funded ENSEMBLES probabilistic forecasts of climate variability and climate change over timescales of seasons to centuries and the application and potential impacts of these predictions. http://www.ensembles-eu.org/
  • Washington, R., Harrison, M, Conway, D., Black, E., Challinor, A., Grimes, D., Jones, R., Morse, A. and Todd, M (2004). African Climate Report - A report commissioned by the UK Government to review African climate science, policy and options for action, DFID/DEFRA, London, December 2004, pp45 http://www.defra.gov.uk/environment/climatechange/ccafrica-study/
