hybrid search schemes for unstructured peer to peer networks random walks in peer to peer networks

“Hybrid Search Schemes for Unstructured Peer-to-Peer Networks”“Random Walks in Peer-to-Peer Networks”

Christos Gkantsidis, Milena Mihail, Amin Saberi

Presented by Paul Bogdan

February 28th, 2007

slide2

“Hybrid Search Schemes for Unstructured Peer-to-Peer Networks”

Christos Gkantsidis, Milena Mihail, Amin Saberi

outline
Outline
  • Random Graph Models
  • Flooding and Normalization
  • Random Walks and Replication
  • Generalized Search Schemes
  • Experimental evaluation
motivation
Motivation
  • Flooding + small time-to-live (TTL) performs well in regular graphs
      • Performance metric: number of exchanged messages/distinct response
      • Its performance decreases: when TTL increases or for irregular networks
  • Random Walk performs better than flooding
      • scalability, granularity
  • Hybrid + Generalized search schemes:
      • Random Walks with lookahead, Random Walks with 1-step replication
contribution
Contribution
  • Random walks (RW) with shallow flooding offer good performance (analytic justification)

R1: In a random graph model with O(n) nodes of constant degree and

O(n1/2) nodes of degree O(n1/2) the expected time to discover Ω(n) is O(n1/2).

R2: Random Walks with look-ahead 1 or 1-step replication perform better

when there is discrepancy on the degrees of the underlying topology.

  • Normalized Flooding (NF) solution

R3: NF achieves comparable performance to flooding in regular graphs.

R4: NF with 1-step replication achieves performance comparable to RW

with 1-step replication.

R5: Local information of the network (nodes degree) offers global benefit.

  • Generalized Search Schemes
random graph models
Random Graph Models
  • Random Regular Graphs – Gn,d

Gn,d represents a graph with n nodes and each node is of degree d.

Gn,d has a sum of degree D = nd .

  • Random Graphs with super-nodes - Gn,d,α,β

Given α and βconstants, Gn,d,α,βdenotes a graphs with αn1/2 of degreeβn1/2 (i.e. large vertices) and the remaining nodes of degree d (i.e. small vertices).

Gn,d,α,βhas a sum of degree D = (αβ+d)n.

flooding and normalization
Flooding and Normalization
  • Theorem 3.1.: Let us consider Gn,drandom regular graph, flooding scenario from node v with time-to-live τ, S – the number of distinct nodes queried by flooding with |S| ≤ |V| / 2

Claims:

(1)

(2)

(3)

slide8
(1)
  • Proof:
slide9
(2)
  • Proof:
slide11
(3)
  • Proof:
flooding and normalization1
Theorem 3.2.: Let Gn,d,α,β be a random graph with supernodes and a flooding scenario from node v of degree d with time-to-live τ.

Claim: For some τ = O(log log n), the number of distinct responses isΩ(n).

Proof:

Consider flooding with τ = c logd-1(log n)+1 and vertices visited with TTL τ-1.

Assumption: this set (of visited nodes) doesn’t contain a large degree vertex.

From d-regular graphs we know that this set contains at least (d - 1)τ-1 edges.

The probability that no vertex in Γ(Sτ-1(v)) is bounded by (d/(d+αβ))(d - 1)^(τ-1) = (d/(d+αβ))clog n so within the first O(loglog n) steps we see a large vertex.

Flooding and Normalization
flooding and normalization2
Flooding and Normalization
  • Theorem 3.3. : Let Gn,d,α,β be a random graph with supernodes, a normalized

flooding scenario from node v with TTL . Then the number of distinct

responses is Ω((d - 1)τ-1) and the number of messages per response is O(1).

Proof:

From Theorem 3.1. the number of minigroups seen is (d - 1)τ-1

The expected number of small vertices is Q = (d *(d - 1)τ-1)/(d+αβ)

LetXi, i = 1,…,N be random variables with P[ Xi=1]=pi and P[Xi=0]=1-pi

Using the above Chernoff bound the probability that less than Q/2 are seen is

vanishingly small.

random walks and replication
Random Walks and Replication
  • Random Walk with Look-Ahead:
      • a random walk with shallow flooding on each step of the walk
      • RW with lookahead 1 visits Ω(n) nodes with response O(n^(1/2))
  • Theorem 4.2.: Let Gn,d,α,β be a random graph with supernodes and consider a

random walk from a node v. Then, in 1-step replication scenario, the expected

number of messages and response time to obtain distinct

responses is

slide15
Theorem 4.3.: Let Gn,d,α,β be a random graph with supernodes and consider

Normalized flooding from v with TTL τ≈ (log n)/(2*log(d-1)). Then, in 1-step

replication scenario, the number of distinct responses is at least

and the number of messages is at most

Proof:

The number of minigroups seen is(d - 1)τ– 1 and using the Chernoff bounds

there will be minigroups corresponding to large vertices.

generalized search schemes
Generalized Search Schemes
  • Searching procedure:
      • A node of degreedinitiates a search based on a budgetk

budget = number of messages that are propageted in the network

      • Among its d neighbors the node picks certain quantities k1,k2,…,kd such that k1 + k2 + … + kd = k
      • For every neighbor i the master node forwards the message with budget ki (forki = 0 the message is not transmitted)
      • Each neighbor i reduces the budget by 1 unit and repeat the process until the budget is greater than 0
      • Every node that receives the message for the second yime from another neighbor forwards the message with the corresponding budget
      • Random Walks + Flooding
experimental evaluation
Experimental Evaluation
  • Methodology
    • Performance Metrics
      • Median and Mean number of distinct peers discovered (hits)
      • Minimum, Maximum, Standard Deviation of the number of hits
      • Number of messages
      • Granularity of number of messages
      • Response time
    • Topologies
      • Random d-Regular Graphs
      • Power Law Graphs
      • Bimodal topologies
      • Clustered topologies
normalized flooding nf
Normalized Flooding (NF)
  • Mean number of unique peers discovered as a function of the initial TTL
  • NF and Standard Flooding behave similarly in Regular Graphs
  • NF controls the number of messages and provides higher efficiency
normalized flooding nf1
Normalized Flooding (NF)
  • The number of unique peers increases exponentially with TTL in NF case
  • The number of peers increases faster than exponentially with TTL in topologies with high degrees
random walk with lookahead rwla
Random Walk with LookAhead (RWLA)
  • RWLA performance is similar to long RW without lookahead (in terms of unique peers discovered)
  • RWLA response time is much smaller compared to standard RW
edge criticality searching with weights
Edge Criticality & Searching with weights
  • Generalized Searching performs similarly to Standard Flooding in regular graphs
  • Generalized Searching behaves similarly to Standard Flooding in other topologies if normalized edge criticality is used.
conclusions
Conclusions
  • Normalized Flooding (NF) could substitute the Standard Flooding in irregular graphs
  • RW with 1-step replication performs better than RW and NF in irregular graphs
  • Open for improvements:
      • Generalized schemes (analytic investigation)
      • Quantifying Directional flooding
random walks in peer to peer p2p networks

“Random Walks in Peer-to-Peer (P2P) Networks”

Christos Gkantsidis, Milena Mihail, Amin Saberi

outline1
Outline
  • Motivation
  • Statistical Estimation and Random Walks (RW)
  • Searching
      • Methodology and Topologies importance
  • Construction and Summary
motivation1
Motivation
  • Random Walks (RW) were proposed for constructing searching and topology maintenance protocols in P2P networks
      • RW improve searching performance as compared to flooding (Cao et al., 2002)
      • A RW approach to constructing and maintaining unstructured topologies provides good connectivity properties (i.e. constant degree, constant expansion)
  • Claim: RW approach is a good candidate
      • to simulate uniform sampling
      • the number of simulation steps required can be as low as the number of samples in independent uniform sampling
  • Searching and Overlay Topology Construction
      • RW searching performs better than flooding for the same number of messages and for cluster and slow dynamic topologies
      • Construction of P2P networks by random walks
statistical estimation random walks
Statistical Estimation & Random Walks
  • Coupon collection and Chernoff bounds
      • n - type of coupons & each time one is drawn (uniformly distributed)
      • Tn - time by which we extracted coupons belonging to all n types
      • Tαn - time by which we encountered αn distinct types, 0 < α < 1
      • X1,…,Xk independent Bernoulli trials, P[Xi=1]=piand P[Xi=0]=1-pi
      • p -probability that a random drawn object has a particular property
      • the probability that the property is found in substantially fewer draws than its frequency in the search space and the quality of the estimator X/k are bounded by
statistical estimation random walks1
Statistical Estimation & Random Walks
  • Random Walks (RW), Convergence and Cover Time
      • G = (V,E) undirected graph, |V| = n, and di- degree of vertex I
      • Aij -adjacency matrix, P -transition matrix which satisfies
      • f: V→{0,1} which satisfies
      • Convergence rate metric - the rate at which the RW approaches the stationary distribution
      • Cover time metric - the time by which all nodes were visited
      • Trajectory sample average - the rate at which the value of f averaged over successive vertices of the RW trajectory approaches p
statistical estimation random walks2
Statistical Estimation & Random Walks
  • Convergence rate is related to the second eigenvalue of P

(1)

      • yt – the vertex that the RW visited at time t
  • Cover time

(2)

  • Trajectory sample average

(3)

(1) :[ 11], (2) :[ 12, 13] , (3) :[ 3, 4, 5, 6]

statistical estimation random walks3
Statistical Estimation & Random Walks
  • Second Eigenvalue, Expansion and Conductance
      • S subset of V, C(S) cutset of V (i.e. edges with one point in S and the other one in V\S), vol(S) (i.e. the sum of degrees of vertices in S)
      • Expansion
      • Conductance
      • Known bound

[ 11, 14, 15, 16, 17, 18, 19]

searching
Searching
  • Performance metrics for Flooding and RW
      • average number of distinct copies of an item located in the search
      • number of messages used by the searching algorithm
  • RW performs better than flooding if
      • multiple search requests for the same item with slow-changing topology
      • peer clustering ( see [20, 21, 22, 23, 24, 25] for details)
  • Searching analysis
      • Methodology
      • Flat topologies with Uniformly Distributed Content
      • Topologies with Peer Clustering
      • Re-issuing the Same Query
      • Real topologies
searching methodology
Searching - Methodology
  • Performance Metrics
      • mean of the number of distinct copies (i.e. Mean)
      • discrepancy around the mean (i.e. Std) and the failure probability
  • Cost
      • number of messages or queries performed during search
  • Peer-to-peer topologies ( ≈ 1 million nodes)
      • Flat regular expanders, Two tier topologies with clustering, Power law graphs, Samples from real topologies
  • Dynamic topologies
      • rewiring
  • Content placement
      • Content clustering affects the performance of searching
searching flat topologies
Searching – Flat Topologies
  • Experiment:
      • one request in a network of 500K peers
      • Mean hits,Minimum # of hits and Std are similar for Flooding and RW
      • the entire distribution of hits is similar for Flooding and RW
searching topologies with peer clustering
Searching -Topologies with Peer Clustering
  • Cluster topology consists of
      • 5 flat regular graphs of size 40K; from each one pick randomly 1000 nodes to construct another flat regular graph
  • Number of hits for RW is more concentrated around the mean compared to Flooding
searching reissuing the same query
Searching - Reissuing the Same Query
  • Experiment setup – repeat 4 times the below procedure
      • each peer sends a request and waits for response
      • between requests 2% of the links are rewired
      • each peer initiates a new searching
  • RW have better performance than Flooding
      • Mean Hits and Failure Probability
searching reissuing the same query1
Searching - Reissuing the Same Query
  • Performance of successive searches depends
      • on the number of topology changes considered between consecutive searches
  • Performance of Flooding increases as the rate of topological changes increases
  • RW Performance remains the same for small variations
searching real topologies
Searching – Real Topologies
  • The number of hits for RW is more concentrated around the mean than in Flooding
  • P2P have good expansion properties
construction
Construction
  • P2P network construction concerns with:
      • peers arrive and leave the network dynamically
      • strong and weak decentralization
      • low network overhead per addition or deletion
baseline construction of expander graphs
Baseline Construction of Expander Graphs
  • ABASE (undirected graph) consists of:
      • n vertices where each one chooses randomly d vertices
      • total number of edges = nd and expected vertex degree = 2d
  • Theorem 4.1. Let G(V,E) a graph constructed by ABASE.

Then, G is an expander with high probability and for positive

constant α < 1

baseline construction of expander graphs with constant overhead in random bits
Baseline Construction of Expander Graphs with Constant Overhead in Random Bits
  • A’BASE constructionalgorithm:
      • start a RW at a random vertex on H (constant degree expander graph)
      • when ABASE needs a random number this is taken from the RW on H
  • Theorem 4.2. Let G(V,E) a graph constructed by A’BASE.

There are positive constants α, 0 < β < 0.5 such that any

subset S of at least β|V| and at most 0.5|V| has cutset

expansionαalmost surely.

distributed construction of expanders with constant overhead on network resources
Distributed Construction of Expanders with Constant Overhead on Network Resources
  • A’H – construction
      • d daemons , one for each Hamilton cycle
      • a new arriving node, it contacts the daemon associated with the i-th Hamilton cycle
      • it attaches after c number of steps between the peer that currently hosts daemon iand one of its neighbors in the cycle i
distributed construction of expanders with constant overhead on network resources1
Distributed Construction of Expanders with Constant Overhead on Network Resources
  • A’M – construction
      • d daemons , one for each Hamilton cycle
      • the arrival of a new arriving node consists of two X and Y nodes; X and Y contact the central server to discover the location of the d daemons
      • X becomes the neighbor of daemon i and Y the neighbor of the initial daemon’s neighbor
summary
Summary
  • For Searching
      • Random Walks (RW) are superior to Flooding
  • For Construction
      • RW add new peers with constant overhead
  • Open Problems
      • Strong Decentralized Construction algorithm
      • Can we handle better deletions and expansions of small sets?
      • How the P2P network parameters (e.g. capacities) affect the performance of RW?
