风扇自动控制接口定义

风扇自动控制接口定义. 2013.11.27. 接口定义. Pin1 ： FAN_PWM ( 风扇控制 ) Pin2 ： GND ( 地 ) Pin3 ： GND ( 地 ) Pin4 ： NC ( 没有信号连接 ) Pin5 ： Key ( 防呆 ) Pin6 ： NC( 没有信号连接 ). 俯视图. 主板 CPU 4Pin FAN 的定义. Pin1 ： GND ( 地 ) Pin2 ： 12V ( 电源 ) Pin3 ： FAN_TACH ( 转速侦测 ) Pin4 ： FAN_PWM ( 风扇控制 ). 俯视图.

yazid
Download Presentation

风扇自动控制接口定义

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. 风扇自动控制接口定义 2013.11.27

  2. 接口定义 Pin1：FAN_PWM (风扇控制) Pin2：GND (地) Pin3：GND (地) Pin4：NC (没有信号连接) Pin5：Key (防呆) Pin6： NC(没有信号连接) 俯视图

  3. 主板CPU 4Pin FAN的定义 Pin1：GND (地) Pin2：12V (电源) Pin3：FAN_TACH (转速侦测) Pin4：FAN_PWM (风扇控制) 俯视图

  4. 主板CPU FAN和小板接口的连接

  5. 风扇调速说明 5pin接口空出，即关闭风扇调速功能，风扇全速运转； 线将风扇控制板端的pin1和主板fan connector的pin4连接，风扇控制板端的pin2和主板fan connector的pin1连接，即可开启风扇转速自动调节功能。
