Puzzle Parking is an automated system designed just like a puzzle to park and retrieve cars. It features combination pallets that enable horizontal and vertical movement of parking spots, and can be easily configured and customised to any property.<br>Wohr Parking Systems is a leading puzzle car parking manufacturer India with a range of puzzle parking models to choose from. One of the most popular models is the u000bCombilift 551.
E N D
COMBILIFT 551PUZZLE PARKING SYSTEM BY WOHR PARKING SYSTEMS Add Title
ABOUT PUZZLE PARKING • Puzzle Parking is an automated system designed just like a puzzle to park and retrieve cars. It features combination pallets that enable horizontal and vertical movement of parking spots, and can be easily configured and customised to any property. • Wohr Parking Systems is a leading puzzle car parking manufacturer India with a range of puzzle parking models to choose from. One of the most popular models is the Combilift 551.
ABOUT COMBILIFT 551 • • A semi-automatic, space-saving parking system • Provides convenient parking in the tightest of spaces by stacking vehicles and moving them closer together • Independent parking in 2 levels above each other without pit• By lifting and sliding the platforms, you get direct access to all parking places at the entrance level. ‘Independent’ means it is possible to load and unload a vehicle individually without the need for taking out the other cars underneath.• A driving lane in front of the full width of the automated parking system is required to access all parking spaces• Entrance-level platforms move laterally and upper-level platforms move vertically, with always one platform less at the entrance level• To collect a car parked on the upper level, the platforms at the entrance level will first move to one side to provide an empty space into which the required platform is lowered• This puzzle lift parking system offers three special advantages - No excavation is required so it can even be fitted in the upper levels of a garage - Operation costs of this system are low - It takes hardly a minute to park and retrieve vehicles from this automated car parking system
COMBILIFT 551 HIGHLIGHTS • • Platform width up to 270 cm• Platform load 2,000 kg and 2,600 kg• Variable arrangement of 2 - 10 grids beside one another• Combination of stacking and moving cars closer together• Independent parking in 2 levels above each other• Multi size options corresponding to car heights, car widths and platform loadings• Easy operation and parking comfort• High level of operating and functional safety (TÜV tested, CE compliant)• Low-wear, proven hydraulic systems• Combination of visitor places and permanent parkers possible• Can be installed indoor and outdoor
THE SAFETY ASPECT • Safe use of the automated parking system is a priority. The standard Combilift system is operated using an RFID-chip operating device. • The semi-automatic Combilift combines clever parking with visual refinements and safety features. • In order to meet its customers’ individual requirements, Wohr offers a variety of sliding doors in steel or aluminum for the Combilift. • Wohr doesn’t just focus on an appealing design, but also on the functionality of the sliding doors. For instance, materials and processing techniques that maximize the life of the sliding doors and the safe parking of vehicles are used. Generally, the doors are operated manually. However, automated doors are also available.
OTHER COMBILIFT SYSTEMS • Wohr’s range of Combilift puzzle parking systems also includes: • COMBILIFT 542 • - An independent parking system in 2 levels above each other with a pit • - Suitable for when headroom is restricted • - Always has one platform less at the entrance level. When requesting a lower-level platform, the upper-level platforms will move laterally until there is an empty space into which the appropriate platform is raised.
OTHER COMBILIFT SYSTEMS • COMBILIFT 543 • - The most compact, space saving Combilift for independent parking on 3 levels above each other. • - The entry is always at the middle level • - The user selects his place via operating panel • - Low-wear hydraulic systems ensure smooth and safe movement of vehicles.
OTHER COMBILIFT SYSTEMS • COMBILIFT 552 • - Offers independent parking in 2 levels above each other and 2-3 rows behind each other. • - Can be arranged in 2 rows behind each other • - A smart combination is to put in Combilift 551 or Combilift 543 system behind Combilift 552. Empty space in the first row will be positioned in such a way that it is possible to drive through to reach the selected space, located in the rear row.
CONCLUSION • Contact Wohr to find out more about the Combilift 551 and their other car parking systems in India. • Wohr is the industry leader with the most extensive range of car parking systems, and proven expertise built up over 60+ years and thousands of installations worldwide. • Wohr’s portfolio of multi-level car parking systems includes stacked parking systems, puzzle parking systems, underground parking systems, pit parking systems, automatic tower parking systems and a variety of automatic car parking systems. • Just tell Wohr your requirements (and challenges, if any) and trust them to come up with the optimal solution for your car parking needs.
