integrating your branch office successfully with optimized printing solutions

Integrating your branch office successfully with optimized printing solutions

Gary Barton

Principal Architect, Receivers and Gateways Group, Citrix Systems

Ramzy Mansour

Manager, Tech Support EMEA, Citrix Systems

Conor Scolard

Technical Support Engineer, Tech Support EMEA, Citrix Systems

agenda
Agenda
  • Print pathways and data flows
  • Printer drivers and PDLs
  • Print optimization solutions
    • Project Laser
    • Project Phaser (Universal Print Server)
    • Branch Repeater
  • Multistream ICA and QOS
types of printers xendesktop and xenapp
Types of Printers – XenDesktop and XenApp
  • Local Printer (Host)
    • Locally defined TCP/IP port printer
  • Network Printer Connection
    • Traditional shared network printer
  • Redirected Client Printers
    • Printer redirected using ICASPL virtual channel protocol
    • Printer using bus-level USB redirection
local printers
Local printers

XenDesktop or XenApp Host

USB, LPT, or TCP port

PDF, XPS or Fax virtual printer

Endpoint

ICA

network printer connections
Network printer connections

XenDesktop or XenApp Host

Print server

SpoolSS RPC

USB, LPT, or TCP port

ICA

Endpoint

usb redirected client printers
USB redirected client printers

XenDesktop host

End point

USB port

ICA

redirected client printers icaspl
Redirected client printers (ICASPL)

XenDesktop or XenApp Host

USB, LPT, or TCP port

End point

ICA

USB, LPT, or TCP port

Print server

SpoolSS RPC

printing and wide area networks
Printing and wide area networks
  • Print devices generally live near end-points
    • Directly connected to the end-point… or at least on same local network
    • Print speed dramatically impacted by limited bandwidth and high latency
  • Print data can be extremely verbose
    • Screen rasters: 75-120 DPI
    • Print rasters: 600-1200 DPI
    • 100x expansion for same raster content
  • Thankfully, print data is…
    • Very compressible
    • Does not need real-time delivery
redirected client printers and wans
Redirected client printers and WANs
  • Print data WAN traversal occurs through the ICA tunnel
  • Advantages:
    • ICA reducer will compress data
    • Print data will be lower priority than interactive data within a session
    • ICA virtual channel bandwidth limit policies can limit BW consumption
  • Disadvantages:
    • USB redirection performs poorly when there is significant latency (ICA SPL will perform better)
    • Print data through ICA are harder to segregate from other traffic for QOS
common network print delivery protocols
Common network print delivery protocols
  • Most network ready print devices support at least one of the following:
    • JetDirect (raw TCP data dump, typically port 9100)
    • LPR/LPD (RFC 1179, typically port 515)
    • IPP (RFC 2910/2911 and others, typically port 631)
  • Common attributes:
    • All stream data fairly efficiently (not too chatty)
    • All are easily identified/prioritized by QOS hardware (e.g. independent TCP connections to well-known ports)
    • Not usually compressed unless using WAN accelerator
local tcp ip port printers
Local TCP/IP port printers?
  • Raw TCP print performance is reasonable
    • No data compression… but data streams well
  • Works fine for small XenApp deployments where printers are defined directly on servers
  • Can also work for XenDesktop users with admin access
    • Users must know where to find printers and how to construct them
  • For usability/manageability, most organizations prefer IT managed print servers
network printing and wans
Network printing and WANs
  • Protocol traversing the WAN depends upon where printer servers are deployed
  • Print server deployed in data center(s):
    • OK: WAN traversed by JetDirect, LPR, IPP, etc.
  • Print server in branch:
    • Client print path OK: WAN is traversed by ICASPL
    • Network print path  BAD: WAN is traversed by SpoolSS-RPC protocol
network printing and wans the wrong approach
Network printing and WANs - The wrong approach

ICA Session

Remote data center with XenDesktop or XenApp hosts

End point

Print data spooled directly to network print server

SpoolSS RPC protocol

Print Server

This configuration will perform poorly, especially with significant network latency

network printing and wans the better approach
Network printing and WANs - The better approach

XenDesktop or XenApp host

ICA Session

Remote data center with application hosts AND print servers

End point

SpoolSS RPC

JetDirect, LPR, IPP

Print Server

Better user experience, but no compression w/o WAN accelerator

print servers in the branch
Print servers in the branch?

ICA Session

Print data delivered through ICASPL virtual channel

Host

End point

Today: Use client print path (with UPD)

Future: Use Universal Print Server

Print Server

compression technology
Compression Technology
  • Most data compression technologies employ same bag of tricks
    • Shared dictionaries
      • Examples: LZW, gzip, ICA Reducer
      • Algorithms differ in how they build and share dictionaries
    • Variable bit length encoding
      • Fewer bits used to encode more frequently occurring tokens
      • Example: Huffman coding
ica reducer
ICA Reducer
  • Citrix patented general purpose data compression algorithm applied to data flowing through ICA
  • Algorithm uses variable sized history buffer for dictionary string matching coupled with Huffman coding of unmatched data
  • Each ICA session employs at least two reducers
    • Server  Client (512K History)
    • Client  Server (512K History)
    • Since Citrix Presentation Server 4, ICAPSL can negotiate a private reducer instance with up to 16MB history
ica reducer performance
ICA reducer performance
  • Typical compression of 75-90% on arbitrary data
    • Expect between 4-to-1 and 10-to-1 compression depending on input
    • Even better when entire print jobs fit within reducer history (16MB)
      • Printing same print job usually sends only a handful of bytes
  • Reducer efficiency for very large print jobs (hundreds of megabytes)
    • Typically 65-75%
    • Not too bad…

…but 25% of 400 MB is still 100MB !

lan wan spooling demo takeaways
LAN/WAN Spooling Demo - Takeaways
  • LAN – All technologies work well
  • ICA or TCP port printing work well on WAN
    • Observed experience on 1.5mbps, 150 ms WAN:
      • ICA: 11s to printer on, 33s pg1, 45s pg2, subsequent pages at printer speed
      • TCP: 10s to printer on, 33s pg1, 57s pg2, can’t keep printer busy
    • Only ICA compresses data 5-to-1 (or better) compression
    • Only ICA provides for bandwidth limits
  • SpoolSS-RPC not suitable for traversing WAN
    • Experience: 0:42/1:29/1:44
    • Excessive delays mapping printers, displaying preferences U/I, etc.
traditional drivers and pdls
Traditional Drivers and PDLs
  • Majority of drivers emit PCL3/4/5, PCL6 (PCLXL), or Postscript
    • But many others PDLs in use
  • Postscript and PCL dialects are fairly efficient
    • Wide range of graphics primitives
    • All have facilities for efficient bitmap and font encoding
  • Verbosity: PostScript > PCL3/4/5 > PCL6
    • After compression, all are roughly equal
  • Other PDLs:
    • Size of print jobs can vary significantly
    • Beware of “host-based” drivers – may be all raster output
optimizing output of traditional drivers
Optimizing output of traditional drivers
  • Selected print quality usually has an impact on print file size
    • Most print drivers select highest possible quality by default
    • Suggestion: Use printer settings overrides to dial down quality
    • Available for Session Printers and Driver Mapping & Compatibility policies
  • Color/monochrome setting may have significant effect
    • Can be overridden by same policies as above
  • TrueType font settings can have measurable effect on print file size
    • Print as bitmap  increase file size
    • Substitute device font  reduces file size, but you may not like the results
    • Download as soft font is usually the best choice
universal printing
Universal Printing
  • Reduces administrative burden to maintain a working set of printer drivers in your XenDesktop or XenApp images
    • Drivers are still needed on print servers and Windows clients.
    • No additional drivers are needed on application hosts when using UPD
  • Citrix provides full-featured universal printing for Windows end-points
    • EMF and XPS print file formats
    • Access to printer/device specific features
    • Network print data optimizations (Project Laser)
  • Legacy PCL/Postscript UPDs available for Mac/Linux/Java clients
  • Engineering team is actively developing Universal Print Server
    • Will bring same UPD capabilities network print path
universal printing solutions from partners
Universal printing solutions from partners

More complete universal printing solutions are available today from our partners

1st class solutions available from ThinPrint, Tricerat, and UniPrint

All support network print path today

All feature optimized print data and delivery protocols

Many options for thin-clients with embedded support for these products

citrix universal printer driver emf
Citrix Universal Printer driver (EMF)
  • EMF can be substantially more verbose than other PDLs
    • EMF is device independent. Other PDLs can optimize for device limits.
    • EMF was designed for fast spooling… not compact storage
      • Recording (journal) of application GDI/DDI calls
      • Spool file size depends on how an application presents content
      • Example: Adobe Reader renders everything itself and presents hi-res raster strips to GDI
  • EMF compresses extremely well
    • General purpose data compression  75-85% compression
    • With recent Laser improvements  as much as 99% compression
citrix xps universal printer driver xps
Citrix XPS Universal Printer driver (XPS)
  • XPS format is more compact than EMF
    • Spool file container is ZIP compressed
    • Embedded images are encoded as PNG or JPEG
    • Repeated images are included only once per print job
  • Windows XPS consumer does not handle interleaved XPS
    • Must download entire XPS package to client before printing can begin
  • Project Laser now gives EMF advantage of XPS packaging plus page-by-page streaming
project laser33
Project Laser
  • Improvements designed to improve print speed
    • Especially with lots of embedded and repeated rasters
    • PowerPoint, Adobe Reader, Photo printers, GIS apps, etc
  • How  Apply print domain specific compression before general purpose data compression
    • Lossy and lossless image compression
    • Cached object protocol for large objects (images and fonts)
  • Shipped in Q4 last year
    • XenDesktop 5 – Built in
    • XenApp 6 - Printing Optimization Pack
slide34

hen in the Course of human events it becomes necessary for one people to dissolve the political bands which have connected them with another and to assume among the powers of the earth, the separate and equal station to which the and organizing its powers in such form, as to them shall seem most likely to effect their Safety and Happiness. Prudence, indeed, will dictate that Governments long established should not be changed for light and transient causes; and accordingly all experience hath shewn that mankind are more disposed to suffer, while evils are sufferable than to right themselves by abolishing the forms to which they are accustomed. But when a long train of abuses and usurpations, pursuing invariably the same Object evinces a design to reduce them under absolute Despotism, it is their right, it is their duty, to throw off such Government, and to provide new Guards for their future security. — Such has been the patient sufferance of these Colonies; and such is now the necessity which constrains them to alter their former Systems of Government. The history of the present King of Great Britain is a history of repeated injuries and usurpations, all having in direct object the establishment of an absolute Tyranny over these States. To prove this, let Facts be submitted to a candid world.

He has refused his Assent to Laws, the most wholesome and necessary for the public good.

He has forbidden his Governors to pass Laws of immediate and pressing importance, unless suspended in their operation till his Assent should be obtained; and when so suspended, he has utterly neglected to attend to them.

He has refused to pass other Laws for the accommodation of large districts of people, unless those people would relinquish the right of Representation in the Legislature, a right inestimable to them and formidable to tyrants only.

— John Hancock

hen in the Course of human events it becomes necessary for one people to dissolve the political bands which have connected them with another and to assume among the powers of the earth, the separate and equal station to which the and organizing its powers in such form, as to them shall seem most likely to effect their Safety and Happiness. Prudence, indeed, will dictate that Governments long established should not be changed for light and transient causes; and accordingly all experience hath shewn that mankind are more disposed to suffer, while evils are sufferable than to right themselves by abolishing the forms to which they are accustomed. But when a long train of abuses and usurpations, pursuing invariably the same Object evinces a design to reduce them under absolute Despotism, it is their right, it is their duty, to throw off such Government, and to provide new Guards for their future security. — Such has been the patient sufferance of these Colonies; and such is now the necessity which constrains them to alter their former Systems of Government. The history of the present King of Great Britain is a history of repeated injuries and usurpations, all having in direct object the establishment of an absolute Tyranny over these States. To prove this, let Facts be submitted to a candid world.

He has refused his Assent to Laws, the most wholesome and necessary for the public good.

He has forbidden his Governors to pass Laws of immediate and pressing importance, unless suspended in their operation till his Assent should be obtained; and when so suspended, he has utterly neglected to attend to them.

He has refused to pass other Laws for the accommodation of large districts of people, unless those people would relinquish the right of Representation in the Legislature, a right inestimable to them and formidable to tyrants only.

— John Hancock

XenDesktop VDA or XenApp Server

Endpoint Device

hen in the Course of human events it becomes necessary for one people to dissolve the political bands which have connected them with another and to that Governments long established should not be changed for light and transient causes; and accordingly all experience hath shewn that mankind are more disposed to suffer, while evils are sufferable than to right themselves by abolishing the forms to which they are accustomed. But when a long train of abuses and usurpations, pursuing invariably the same Object evinces a design to reduce them under absolute Despotism, it is their right, it is their duty, to throw off such Government, and to provide new Guards for their future security. — Such has been the patient sufferance of these Colonies; and such is now the necessity which constrains them to alter their former Systems of Government. The history of the present King of Great Britain is a history of repeated injuries and usurpations, all having in direct object the establishment of an absolute Tyranny over these States. To prove this, let Facts be submitted to a candid world.

He has refused his Assent to Laws, the most wholesome and necessary for the public good.

He has forbidden his Governors to pass Laws of immediate and pressing importance, unless suspended in their operation till his Assent should be obtained; and when so suspended, he has utterly neglected to attend to them.

He has refused to pass other Laws for the accommodation of large districts of people, unless those people would relinquish the right of Representation in the Legislature, a right inestimable to them and formidable to tyrants only.

— John Hancock

hen in the Course of human events it becomes necessary for one people to dissolve the political bands which have connected them with another and to that Governments long established should not be changed for light and transient causes; and accordingly all experience hath shewn that mankind are more disposed to suffer, while evils are sufferable than to right themselves by abolishing the forms to which they are accustomed. But when a long train of abuses and usurpations, pursuing invariably the same Object evinces a design to reduce them under absolute Despotism, it is their right, it is their duty, to throw off such Government, and to provide new Guards for their future security. — Such has been the patient sufferance of these Colonies; and such is now the necessity which constrains them to alter their former Systems of Government. The history of the present King of Great Britain is a history of repeated injuries and usurpations, all having in direct object the establishment of an absolute Tyranny over these States. To prove this, let Facts be submitted to a candid world.

He has refused his Assent to Laws, the most wholesome and necessary for the public good.

He has forbidden his Governors to pass Laws of immediate and pressing importance, unless suspended in their operation till his Assent should be obtained; and when so suspended, he has utterly neglected to attend to them.

He has refused to pass other Laws for the accommodation of large districts of people, unless those people would relinquish the right of Representation in the Legislature, a right inestimable to them and formidable to tyrants only.

— John Hancock

SSL 001000111010101 SSL 001000111010101 SSL 001000111010101 SSL 0010

laser takeaways
Laser - Takeaways
  • EMF used by Citrix UPD can be verbose
    • Device independent format
    • Recording of application drawing requests
  • Project Laser optimizes UPD EMF
    • Graphical content reduced by as much as 90%
    • Redundant graphics objects removed
    • Observed experience (1.5 mbps, 150 msec):
      • 10s to printer on, 30s pg1, 42pg2, subsequent pages at printer speed
project phaser universal print server43
Project Phaser - Universal Print Server

Goal: Extend universal printing capabilities to network printing scenarios

  • Network print server solution providing
    • Ability to use Citrix universal printing regardless of client capabilities
    • Efficient, open, and firewall friendly protocols
    • Optimized print traffic flows (host  print server)
  • Removes need for printer drivers on the XA/XD hosts!
  • Significant WAN performance improvements
    • Less sensitive to latency than printing using SPOOLSS-RPC protocol
    • Greater print speed and less bandwidth consumption (Laser optimizations)
phaser elements
Phaser Elements
  • Protocols
    • UP-WS: Web service protocol for non-streaming protocol elements
      • SOAP based application protocol over HTTP/HTTPS
    • UPP: Universal Printer Port protocol
      • Compressed print streams tunneled to via CGP over TCP
    • UPClient package
      • Adds network printing capability to XenDesktop or XenApp hosts
    • UPServer package
      • Add on package installed on a Windows print server
print server architecture
Print Server Architecture

UPServer

Spooler

UP-WS

S

DK

Print Provider

Network Print Service

SOAP over HTTP(S)

UP Web Service

RPC

CGP/SSL

TCP

Print Data

(XPS/EMF)

UPS Configuration

UPD

Driver

WINSPOOL.DRV

Driver

Drivers

App

VQ1

VQ2

PQ2

PQ1

Spooler

Driver

Driver

Driver

Driver

UPClient

StdNetwork Port Monitor

UPS Virtual

Port Monitor

Rendered Print Data

upserver component services
UPServer Component Services
    • UP Web Service
      • Non-privileged network web service
      • Hosted in XTE
        • Apache 2.2 derivative with Citrix specific protocol modules (CGP, Authentication, etc)
        • Same platform used by Secure Gateway, Session Reliability, and SSLRelay
  • Network Print Service
    • Executes with Spooler Admin rights only… but is otherwise non-privileged
    • Provides all the typical remote Windows printer operations, plus…
      • Printer settings & capabilities interrogation methods used by UPDs
      • Rendering EMF or XPS input stream  device ready output stream
ups deployment
UPS Deployment

XenApp/XenDesktop Farm

Print Server

plus UPServer

UP-WS over HTTPS

UP-WS

SpoolSS-RPC

Print Data (XPS/EMF)

ICA

TCP

Tunneled via CGP/SSL

Compressed print data

TCP

ICA

project phaser status
Project Phaser Status
  • HDX printing team’s #1 priority since Laser release
  • Phaser Community Tech Preview Announcement
    • Tech preview test iteration scheduled to finish Nov 1.
    • Look for CTP bits on MyCitrix website first week of November!
  • Phaser Tech Preview components:
    • Print client add-on for XenDesktop 5.5 and XenApp 6.5 hosts
    • Minor hotfix updates for print components of XenDesktop 5.5 and XenApp 6.5
    • Add-on package for Windows print server for Windows Server 2008 x86
    • Updated GPMX policy console to support UPS policies
  • GA Target: 1H12, based on beta feedback
phaser takeaways
Phaser - Takeaways
  • Enables UPD usage for network printing
  • Works with any endpoint type
  • Brings Laser performance to network printing
  • Observed experience (1.5mbps, 150ms):
    • 11s to printer on, 33s pg1, 45s pg2, subsequent pages at printer speed
  • Community Tech Preview first week of November
branch repeater compression
Branch Repeater compression
  • Similar compression techniques to ICA reducer & Laser… but accomplished on a much grander scale
  • Instead of having a few megabytes of cache and shared history, Branch Repeater can have hundreds of gigabytes
  • Two big advantages:
    • Larger cache history  potentially more efficient compression
    • Shared state  New user sessions immediately benefit from history of other sessions
branch repeater with ica

WAN Optimization

Branch Repeater with ICA
  • When branch repeater detects an ICA connection, it silently adds a capability during initial ICA handshake
  • When this capability is detected by XenApp or XenDesktop, host software adjusts by:
    • Switching certain algorithms to use shareable handles
    • Switching off ICA reducer
  • Allows BR device to focus on finding cache hits instead of wasting CPU expanding compressed data
  • No ICA reducer does mean substantially more data flowing between host and Branch Repeater device
branch repeater and print data
Branch repeater and print data
  • General purpose compression results
    • Comparable to ICA reducer first time it sees print data
    • Improves over time due larger compression histories
    • Expect anywhere from 5-to-1 to 10-to-1 compression
  • Laser image compression is complementary.
    • Repeater doesn’t care if images are JPEG, PNG, or BMP when caching
    • Branch Repeater will soon be able to parse Laser cache protocol
    • Helps identify large cacheable objects without having to search

Works with non-ICA print streams and provides compelling QOS features !!!

qos prioritization challenges of ica
QOS prioritization challenges of ICA

ICA multiplexes multiple channels into single TCP connection

With a session, Winstation driver maintains four priority bands

Single pipe ICA does not make it easy to reorder packets and implement QOS prioritization

To address this, Project Alsace and IronCove have added Multi-stream ICA

multi stream ica true hdx network qos
Multi-Stream ICA (True HDX Network QoS)

CitrixReceiver for Windows

XA WS08 R2or

XenDesktop

Windows 7

Router

ICA Real Time

ICA Real Time

ICA Interactive

ICA Interactive

ICA Bulk

ICA Bulk

ICA Background

ICA Background

ICA UDP Audio *

ICA UDP/RTP Audio *

HTTPServer

HTTP

HTTP

* UDP/RTP Audio initially only in VDI FlexCast model (XenDesktop)

single multi stream ica virtual channel priorities
Single & Multi-Stream ICA Virtual Channel Priorities
  • Custom virtual channels created by partners and customers will default to Interactive priority
  • Customers/priority of their custom virtual channels and set registry appropriately.
branch repeater capri release
Branch Repeater (Capri release)
  • More flexible QoS support
    • More priority levels
    • “Zero configuration” QoS for all traffic
    • Multiple TCP streams over single port (1494)
    • Application discovery and classification
  • Rate control and protection capabilities
  • Caching of client-fetched Flash videos
  • Improved cross-session compression for printing
branch repeater takeaways
Branch Repeater - Takeaways
  • Accelerates ICA usage including print data
  • Excellent compression of TCP print data
    • Compression improves over time
    • Benefits shared by all users
  • Provides QOS solution
    • Multi-stream ICA and out-of-band print data
