2007 group meeting global climate and air pollution gcap

2007 Group Meeting Global Climate and Air Pollution (GCAP)

at

Harvard University

Nicky Lam and Joshua Fu

University of Tennessee

October 12, 2007

gcap update ut team
GCAP UpdateUT Team
  • Find best MM5 schemes for GISS data
    • Sensitivity analysis
    • Best scenario for whole domain
    • Best scenario for Northeastern States, Southeastern States, Central States, & West States
  • Preliminary run using Barry Lynn suggested base on the Best MM5 schemes in Northeastern States and other schemes combinations
  • CMAQ runs for 2001 and 2050
slide3

GISS/MM5 Downscale Modeling

Highlighted scenario are the preliminary runs

slide4

Case 24 (Kain-Fritsch 2, Eta, Reisner 2, RRTM) has closer temperature compared to others

  • Similar wind speed were found on all cases
  • Similar wind direction were found on all cases
noted noah lsm is not available due to lack of soil layers
Noted: Noah LSM is not available due to lack of soil layers

May need to discuss with Loretta to reprocessing the output from GEOS-Chem

mm5 scheme evaluation
MM5 Scheme Evaluation
  • Case 24 is used in all preliminary simulation.
  • This setting was suggested by Barry Lynn claimed to be the best scenario for Northeastern States
mm5 setting
MM5 Setting
  • LAMBERT CONFORMAL
  • NO COARSE DOMAIN EXPANSION
  • TRUE LATITUDE 1 (degree) => 33 degrees
  • TRUE LATITUDE 2 (degree) => 45 degrees
  • Time increment between analysis times (s)=> 3 hrs data
  • Top pressure used in analysis, model lid (Pa) => 10000.00
  • No FDDA
  • Number of half-sigma layers => 34 layers
  • Simulation duration for each run => 6 days with 12 hrs spinoff
  • Simulation time step => 90 seconds
slide8

MM5 Sigma Level => from INTERPF

Noted: MCIP extracts the highlighted sigma level for CMAQ

current case study
Current Case Study
  • 2001 meteorology with 2001 emission
  • 2050 meteorology with 2001 emission
    • Find the effect that contributed from the change of GISS meteorology
  • Time period: June 1 to October 1 (Ozone season)
slide11
CMAQ
  • 14 layers (from the previous sigma levels)
  • ICON and BCON from GEOS-Chem from 3 hrs to one hour average
  • GISS meteorological Inputs
  • Input emission is compatible with 2001 EPA emission
cmaq comparison

CMAQ comparison

2001 GISS data

2050 GISS data

maximum o 3
Maximum O3

At the same location

avg no x avg vocs
Avg NOx & Avg VOCs

NOx limited Area, no big diff.

More VOCs, but less O3, Main effect => T

pm 2 5 dcv
PM2.5 & DCV

7.2 m

7.2 m

391 m

391 m

slide28

Visual Range Parameters:

Deciview (dv) :

dV = 10 ln (b / 0.01),

b [km-1] : extinction coeff.

Koschmieder Visual Range :

Vr = 3.91 / b [km]

dV Vr [km] b [km-1]

60 1.0 4.0

40 7.2 0.55

20 53 0.07

10 144 0.03

0 391 0.01

so 2 total sulfur dep
SO2 & Total Sulfur Dep.

very minimal Effect

slide31

Comparison between 2050 and 2001 (2050 – 2001)

Average Temp. & Average O3 Conc.
