Presentation Transcript
fmi capabilities in robotics diagnostics and multi phase flow monitoring

FMI Capabilities inRobotics, Diagnostics, andMulti-Phase Flow Monitoring

Dr. Wayne S. Hill

whill@foster-miller.com

shipboard weapons loading the problem
Shipboard Weapons LoadingThe Problem !

The Navy Wants Double the Rate and Half the People

slide3

Shipboard Weapons LoaderThe Solution

  • 3000 lb Payload Capacity
  • Nine Degrees of Motion Freedom
  • Can Handle All Shipboard Weapons
  • Human Force Amplification With Gravity Compensation and Ship Motion-Induced Dynamic Error Compensation
  • Built-In Equipment Diagnostics
slide4

Auto-Galley and Smart Galley

  • Smart Galley
  • Allows full oversight and supervision of galley functions for both new and legacy ships
  • Meal planning, consumption monitoring, inventory control, food safety (HAACP) monitoring
  • Equipment diagnostics & prognostics
  • AutoGalley:
  • Integration of Modular Robotic Food Service System into Existing DDG-51 Galley
  • Adaptable to any ship platform
  • Automation concepts adaptable to a wide range of shipboard material handling needs
industrial robotics for plant automation
Industrial Robotics for Plant Automation
  • BoxHandler
  • Mobile Robot for Refrigerated Material Storage
  • Designed to eliminate hazardous, high injury jobs
  • Totally electric design (food storage, hydraulic fluids not permitted
  • Inventory tracking key part of system
  • Distributed control system with autonomous robotic operations
  • RoboPacker / AutoBoxer
  • Box Packing automation system
  • Manipulate a wide range of different size, weight, and shape products
  • Reduce packing personnel
  • Improve speed and quality of packing
  • Designed for use in difficult food plant cleaning environment (high pressure hot water)
robotics for inspection repair and hazardous duty
Robotics for Inspection, Repair and Hazardous Duty
  • TOMCAT: remotely operated robot arm
  • High voltage insulation maintenance tool
  • Tactile feedback loop
  • Keep personnel out of hazardous environment
pipe mouse
Pipe Mouse
  • Attributes
  • Semi-autonomous operation in a live gas main
  • Fault tolerant distributed control system
  • Multi-car design permits different sensors and tool payloads to be added depending on specific task at hand
  • Performance
  • Range – 2000 ft.
  • Negotiate all elbows, tees, valves and pipe orientation
  • Operate in operating pipe environment – gas or liquid
  • 8-hr per battery charge
  • Travel speed 5 to 10-ft/min
emals
EMALS
  • Electromagnetic Design
  • Motor Control
  • Health Monitoring
  • Prognostics
  • Operational Concept
  • System Software
  • Operator Control Stations
  • Modeling & Simulation
slide10

Advanced Arresting Gear (AAG)

  • Electromagnetic Design
  • Motor Control
  • Health Monitoring
  • Prognostics
  • Operational Concept
  • System Software
  • Operator Control Stations
  • Modeling & Simulation
fmi s dynamical instruments technology
FMI’s Dynamical Instruments Technology

Concept: Nonlinear portion of signals

can be a more sensitive indicator of a

problem than the harmonic or linear

portion.

Applications:

  • Aircraft flight control actuators
  • Electromechanical system diagnostics and prognostics
  • Helicopter vibration reduction
  • Mechanical equipment fault identification
  • Multi-phase flow sensing
    • Oil/water/gas
    • Gas-solid (coal/air)
  • Container security

Raw Helicopter Vibration Signal

prognostics for electric aircraft actuators
Prognostics for Electric Aircraft Actuators

Flight controller signals analyzed to determine EHV health

Clustering and Associated Command Window for Sine-Wave Command.

Frequency: 1/6 Hz Amplitude: 0.25”

Fault level (remaining life) of EHV Determined

slide15

Helicopter Active Vibration Reduction

Background

  • The Westland-Augusta EH-101 is the first production helicopter to use active vibration reduction.
  • Active Control of Structural Response (ACSR) is a quasi-linear vibration isolation system.
  • ACSR can only address the “average vibration” from previous rotor rotations, and cannot handle the chaotic variation of vibration.

Phase II SBIR Program

  • Investigate improved vibration control techniques based on Chaotic Control (nonlinear dynamics of structure)
  • Demonstrate control improvements on helicopter structural test stand using flight vibration data as input to structure

EH-101 has been licensed by Lockheed Martin to be the new Presidential helicopter.

Results: 80% reduction in vibration amplitude, close to the limit of controllability for the test aircraft. ACSR reduced vibration by 56%.

sensitive diagnostics for mechanical equipment
Sensitive Diagnostics for Mechanical Equipment

Fluid Film Bearing

Ventricular Assist Device

Dynamical Instrument Analysis

Spectral

Analysis

multi phase flow measurement
Multi-Phase Flow Measurement

Example: Ultrasonic

Thickness Measurement

Liquid Flow

Gas Flow

Raw

Data

Quality

water cut in oil water flows
Water Cut in Oil/Water Flows

Data Collected in

Laboratory Testing

With Mineral Oil

And Water Using

Swept-Frequency

Acoustic

Interferometry and

Dynamic Pressure
