    1. JDS – VB.NET Skill Session Fall 2004 Presented by YUHAO LIN

    2. TOPICS Visual Studio .NET VB.NET Code Structure VB.NET Language Basics Data Access in .NET

    3. What is .NET ? Microsoft® .NET (released 2001) is Microsoft’s new generation "software platform."  It's a language-neutral environment for writing programs Program in any language, run on one operating system Includes comprehensive class libraries that provide rich features

    4. What is VB.NET ? Visual Basic .NET Next generation of Visual Basic A programming language in the .NET framework Fully object-oriented

    5. Visual Studio .NET Available in Software Lab Latest version: 2003 Integrated Development Environment (IDE) for developing .NET applications

    6. Visual Studio .NET Create a new project Opening an existing project Open .sln file Solution Explorer (design vs code view) Properties Window Toolbox: many Controls Task List

    7. Visual Studio .NET Code view Comments #Regions: collapse Intellisense Run / compile Debug / step into Executable file Location: bin or obj subdirectory

    8. VB.NET Code Structure VB.NET Import statements Namespace Class Functions / Subs Properties Class variables

    9. VB.NET Code Structure VB.NET imports System.Data.OleDb namespace TestNamespace public class TestClass sub NewRecord() … end sub function GetRecord() as String … return strX end function End class end namespace

    10. VB.NET Language Case insensitive BUT, always be consistent !!!!! No semicolon to end statement One line per statement, & _ for multi-line statements: str1 = str2 &_ str1 = str2 & str3 str3 Very wordy, resembles English language Good for beginners

    11. Programming Review Car myCar = new Car(“Ford”, “Escort”) What did I do ??

    12. Common Data Types Integer Double Boolean String Array

    13. Data Conversion Convert.ToType(var); Ex: Convert.ToInt32(“45”) Convert.ToDateTime(“12/31/2000”) Ex: Dim j as integer Dim s as string = “16” If IsNumeric(s) Then ‘ check if s is a valid number J = Convert.ToInt32(s) ‘ convert s to 32-bit integer, assign to J End If

    14. Operators DESCRIPTION VB.NET Ex JAVA Ex String concatenation & str1 = str2 & str3 + str1 = str2 + str3 &= str1 &= str2 += str1 += str2 Addition += int1 += int2 += int1 += int2 Add 1 n/a int1 = int1 + 1 ++ int1++ Comparison >=, <= >=, <= Equality = If j = 1 == if (j == 1) Inequality Not If Not j = 1 ! if (j != 1) <> If j <> 1

    15. Methods

    16. Properties

    17. Loops Dim x as Integer = 0 Do While x < 5 x = x + 1 Loop

    18. Exception Handling Syntax: Try … Catch var as Exception … Finally … End Try

    19. Database Access ADO.NET (ActiveX Data Objects) The .NET way to work with data Disconnected Architecture 2 Data Providers: SQL Server: specific provider for SQL Server Import System.Data.SqlClient OLEDB: everything else, basically… Import System.Data.OleDb

    20. ADO.NET

    21. Data Access Components Connection string http://www.able-consulting.com/ADO_Conn.htm Connection object SQL statement Command Object & DataReader OR – Data Adapter & DataSet

    22. Connection String SQL Server Data Provider: "Network Library=DBMSSOCN;Data Source=111.11.111.111,3333;” & _ “Initial Catalog=epics;User Id=epics;Password=jds" OLEDB Data Provider (SQL Server): "Provider=sqloledb;" & _ "Data Source=111.11.111.111,3333;" & _ "Initial Catalog=epics;" & _ "User Id=epics;" & _ "Password=jds" OLEDB Data Provider (Access): "Provider=Microsoft.Jet.OLEDB.4.0;Data Source=T:\www\mdb\WebInt.mdb"

    23. DataSet vs DataReader DataReader Object to access data in a connected, forward-only, read-only fashion DataSet Data structure to store schema and data in a disconnected fashion Useful for editing data offline and later update to data source

    24. Database Connectivity Using SQL Server Data Provider and DataSet: Dim strConn as String = "Network Library=DBMSSOCN;Data Source=111.11.111.111,3333;” & _ “Initial Catalog=epics;User Id=epics;Password=jds” Dim oConn as new SqlConnection(strConn) Dim strSQL as String = “select * from NODE_PROFILE” Dim oAdapter as new SqlDataAdapter(strSql, oConn) Dim ds as new DataSet oAdapter.Fill(ds, “NODE_PROFILE”) ‘ now we have a DataSet with data from the NODE_PROFILE table Using OLEDB Data Provider and DataReader: Dim strConn as String = "Provider=sqloledb;" & "Data Source=111.11.111.111,3333;" & _ "Initial Catalog=epics;" & "User Id=epics;" & "Password=jds“ Dim oConn as new OleDbConnection(strConn) Dim strSQL as string = “select * from NODE_PROFILE” Dim oCommand as New OleDbCommand(strSql, oConn) Dim oReader As OleDbDataReader oReader = oCommand.ExecuteReader() ‘ now we have a DataReader with data from the NODE_PROFILE table

    25. ADO.NET in JDS.2GO ?? Not taking advantage of .NET data providers and data structures Using outdated technology: objects from ADODB class This semester: possibly transform all of JDS.2GO to ADO.NET-standard

    26. ADO.NET Hands-on Exercise!!!!!!!!!!! Task: build a simple VB.NET application with database connectivity to display the front-end. Based on existing C# code
