  1. SMT Programming Software Towards Industry 4.0 & IoT

  2. Are you always willing to stay with those issues? Quality defects, reliability issue, process headache, business risk Design Equipment programming 1 4 • No thermal consideration, small annual ring small, silkscreen error, Silkscreen incomplete, … • >30% PCB design comes with problem. • Wrong polarity, location offset, inline fine-tune, … • Lower test coverage, lower utilization, … 2 5 Manufacturing NPI cycle • Short, open, tombstone, cold sold, Void, … • >60% defects could be found prior to build • Frequent prototyping, high cost • Long cycle, impact time to market, … 3 6 Post sales Process design • Difficult to transfer knowledge • No effective tool to continually improve process capability • … • sold joint crack, sold joint peeloff, … • Repair rate for consumer product: 5%~37% in initials 3 years IPC research: 80% defects could be found and resolve during NPI stage.

  3. Company introduction • Founded on Jan of 2005, headquarter in China/Shanghai; • Dedicates to intelligent NPI software to accelerate design to manufacturing; • Fully in-house development, owns copyrights and patents; • Product installed >20 countries and regions worldwide; • Strategy partnership with equipment and EDA provider: Keysight/ViTrox/TRI/Fuji/Panasonic/Altium… >10 years dedication on NPI technology brings up the world-class product.

  4. Core product: Intelligent NPI software for PCBA • Reduce design & mfg cycle: 30%-70% • Reduce quality defects: 30%+ • Increase reliability: 30%+ • Increase design and mfg efficiency: 40%+ • Reduce design and mfg cost: 20% + Intelligent DFx analysis DFM Expert & DRC+ Process Eng., Industry Eng. Debug tech, others… PCB layout Eng., process Eng. NPI Eng. Testing Eng. SMT programmer Document Expert SMT Expert/ Accelerator Other NPI sw Test Expert Fast placement programming, support Fuji, Panasonic, ASM, Juki, Yamaha… Board troubleshooting, Gerber conversion, assembly drawing, NPI team collaboration DFT/Testability, ICT/FP/AXI/AOI programming Work instruction document preparation * NPI:New Product Introduction
