Presentation Transcript
pricing charging billing experiments using the h 323 gateway

Pricing, Charging, & Billing Experiments Using the H.323 Gateway

Jimmy Shih, Anthony Joseph, Randy Katz

the iceberg testbed

Indoor/Outdoor Coverage

Paging Base Station

Controller

Proxy

Proxy

1900 MHz GSM Cellular Base Station

Data Converter

Local Area Network

1800 MHz GSM Cellular Base Station

Proxy

H.323 Gateway

Public Switched Telephone Network

Outdoor Coverage

Indoor Coverage

The ICEBERG Testbed
the h 323 testbed

Public Switched Telephone Network

Local Area Network

The H.323 Testbed
  • Provide a web interface.
  • Integrate with the IMAP email service.
  • Web server (H.323 proxy using the upgraded Lucent Elemedia H.323 protocol stack).
  • Relational database.
  • Upgraded Motorola Vanguard H.323 gateway.
  • Primary Rate ISDN line (24 simultaneous voice calls), 100 Mbits Ethernet.

Web Server (H.323 Proxy)

Motorola Vanguard H.323 Gateway

Relational Database

Primary Rate ISDN Line

100 Mbits Ethernet

experiment 1 congestion pricing
Experiment 1: Congestion Pricing
  • Design Features:
    • Provide real-time pricing & billing information.
    • Allow callers and callees to split the call costs.
    • Provide all the control functions through both the phones and the computers.
experiment 1 congestion pricing1
Experiment 1: Congestion Pricing
  • 500 users using the gateway to make and receive telephone calls.
  • Capacity limited to 24 simultaneous voice connections.
  • First come first service with fat rate per minute leads to high utilization, but poor availability.
  • Congestion pricing with price per minute depending on the network load can lead to high utilization and good availability.
    • Price per minute can depend on the call duration.
    • Price per minute can depend on the amount of usage in a time period.
experiment 2 multiple service providers

510 Area Code Service Provider

415 Area Code Service Provider

650 Area Code Service Provider

Logical Picture

Physical Picture

PSTN

H.323 Gateway

415 ACSP

650 ACSP

510 ACSP

Internet

650 Area Code

415 Area Code

510 Area Code

Experiment 2: Multiple Service Providers
  • Logically: one service provider responsible for calls in each area code.
  • Physically: emulate multiple service providers in our H.323 gateway.
experiment 2 multiple service providers1
Experiment 2: Multiple Service Providers
  • Provide one integrated bill across multiple service providers.
  • Perform settlements between service providers.
  • Using a Clearing House to find the best path across multiple service providers.
  • Allow the best path to change depending on the network conditions.
  • See if prices can solve congestion across multiple service providers.
  • See if prices can perform load balancing across the network.
  • Provide mechanisms to deal with network stability issues.
experiment 3 multicast services
Experiment 3: Multicast Services
  • Provide multiple party calls.
    • Handles membership changes.
    • Handles different link prices in the multicast tree.
    • Allow members to negotiate how to split the cost.
experiment 4 reliable datagram services
Experiment 4: Reliable Datagram Services
  • Provide voice message delivery service.
    • Sending reliable datagram across multiple service providers.
    • Allow senders & receivers to negotiate on who should pay.
