1. Overland Pass Pipeline
2. About Overland Pass Pipeline Approximately a 750-mile transmission pipeline
Originates in Opal, WY and ends at Conway, KS
Traverses 23 counties in 3 states
90% of route follows existing utility corridors
Transports natural gas liquids (NGLs)
3.
4. Blacks Fork
5. About Overland Pass Pipeline Approximate $450 million capital investment
14 and 16-inch diameter pipe (varies)
Made of high-strength steel
Buried minimum of 36” below ground
Maximum operating pressure 1,440 psig (Prior to start up pipe is tested to 1800 psig)
Pipe capacity range 90,000-150,000 barrels per day
6. Local Economic Impacts
7. Pump Stations 3 pump stations used to move NGLs
Two in Wyoming - for startup
One in Kansas - for maximum capacity
This project is more efficient because gravity helps move the product (meaning fewer pump stations required)
8. Green River
9. There are two NGL Hubs in the U.S. where mixed NGL Products are fractionated, or separated into individual components Mont Belvieu, Texas
Conway, Kansas (includes multiple areas)
Bushton, Kansas
Hutchison, Kansas
Mitchell, Kansas
Conway, Kansas
11. Medicine Bow
12. Anticipated Project Schedule Current
Ongoing environmental/cultural surveys
Submit major permit applications
Summer 2007
Target date to receive regulatory approval
Begin construction
Winter 2007-08
Pipeline in service
13. Regulatory Bureau of Land Management (BLM) is lead federal agency managing the regulatory process, they will consult additional federal and state agencies along the pipeline route
This project is undertaking the completion of an Environmental Impact Statement (EIS) which will fall under the federal NEPA and 106 guidelines
14. More information about the project is available at www.overlandpass.com
www.oneok.com
(877) 683-7277
Latest updates about the project
Video of the construction process
Links to educational documents about the Natural Gas Industry
15. Regulatory Contact Information BLM project manager for this project is:
Tom Hurshman (970) 240-5345
2465 S. Townsend Ave., Montrose, CO 81401
