Presentation Transcript

  1. Tissues of The Body Part 1 Start

  2. TABLE OF CONTENTS Epithelial Tissue Connective Tissue Tissues of the Body Part 1

  3. EPITHELIAL TISSUE Simple Squamous Epithelium 100x 400x 1000x Simple Columnar Epithelium 40x 100x 400x Simple Cuboidal Epithelium 40x 100x 400x Pseudostratified Ciliated Columnar Epithelium 100x 400x 1000x Tissues of the Body Part 1

  4. Simple Squamous Epithelial Tissue 100x Tissues of the Body Part 1

  5. Simple Squamous Epithelial Tissue 400x cells Tissues of the Body Part 1

  6. Simple Squamous Epithelial Tissue 1000x nucleus organelles nucleolus plasma membrane cytoplasm Tissues of the Body Part 1

  7. Simple Columnar Epithelial Tissue 40x Tissues of the Body Part 1

  8. Simple Columnar Epithelial Tissue 100x epithelial cells Lumen lumen connective tissue Tissues of the Body Part 1

  9. Simple Columnar Epithelial Tissue 400x cilia goblet cell cytoplasm nucleus cells basement membrane connective tissue Tissues of the Body Part 1

  10. Simple Cuboidal Epithelial Tissue 40x Tissues of the Body Part 1

  11. Simple Cuboidal Epithelial Tissue 100x simple cuboidal epithelial tissue lumen Tissues of the Body Part 1

  12. Simple Cuboidal Epithelial Tissue 400x cytoplasm lumen nucleus connective tissue cell basement membrane Tissues of the Body Part 1

  13. Pseudostratified Ciliated ColumnarEpithelial Tissue 100x epithelial tissue connective tissue Tissues of the Body Part 1

  14. Pseudostratified Ciliated Columnar Epithelial Tissue 400x cilia goblet cells lumen connective tissue epithelial cells cuboidal epithelial cells Tissues of the Body Part 1

  15. Pseudostratified Ciliated Columnar Epithelial Tissue 1000x lumen cilia goblet cell nucleus epithelial cells basement membrane basal cell Tissues of the Body Part 1

  16. CONNECTIVE TISSUE Adipose Tissue 40x 100x 400x Hyaline Cartilage Tissue 40x 100x 400x Elastic Cartilage Tissue 40x 100x 400x Bone Tissue 40x 100x 400x Tissues of the Body Part 1

  17. Adipose Tissue 40x blood vessel adipocytes Tissues of the Body Part 1

  18. Adipose Tissue 100x adipocyte blood vessel Tissues of the Body Part 1

  19. Adipose Tissue 400x fat globule blood vessel nucleus cytoplasm Tissues of the Body Part 1

  20. Hyaline Cartilage Tissue 40x columnar epithelial tissue hyaline cartilage tissue Tissues of the Body Part 1

  21. Hyaline Cartilage Tissue 100x chondrocytes intercellular matrix Tissues of the Body Part 1

  22. Hyaline Cartilage Tissue 400x empty lacuna cell in lacuna lacuna chondrocyte intercellular matrix nucleus Tissues of the Body Part 1

  23. Elastic Cartilage Tissue 40x elastic cartilage tissue perichondrium adipose tissue Tissues of the Body Part 1

  24. Elastic Cartilage Tissue 100x elastic cartilage tissue perichondrium Tissues of the Body Part 1

  25. Elastic Cartilage Tissue 400x chondrocytes lacuna elastic fibers nucleus intercellular matrix Tissues of the Body Part 1

  26. Bone Tissue 40x Haversian systems Tissues of the Body Part 1

  27. Bone Tissue 100x osteocytes central (Haversian) canal intercellular matrix Tissues of the Body Part 1

  28. Bone Tissue 400x osteocyte lacuna central (Haversian) canal lamella canaliculi Tissues of the Body Part 1
