Presentation Transcript
local medicine manufacture
Local medicine manufacture


  • Political side: different levels of local medicine manufacture may exist – the country should choose its best
  • Regulatory side: regulation and control of local medicine manufacture


local drug manufacture 1
Local drug manufacture, 1

WHO: different levels may exist

  • a) most advanced: research and development of new APIs Active Pharmaceutical Ingredientsalso manufacture of APIs + dosage-form production

isolation of herbal principles

  • b) less advanced: manufacture of established APIs + intermediates, + their dosage-forms


local drug manufacture 2
Local drug manufacture, 2

(Different levels)

  • c) only finished products (every kind of dosage-forms, including sterile) from purchased APIs and excipients
  • d) only some simpler finished products (dosage forms simpledifficult:e.g. solution/ointmenttabletssterilevaccines)
  • e) the least advanced manufacture: only (re)packaging of purchased bulk finished products


to make the right choice
To make the right choice…

…is a political issue! Principles:

  • Meeting the local needs should be the first
  • Organising lower level, but working manufacture is better than aiming higher level that can not operate
  • But drug export, if possible, ensures profit and power…


achieving this political will
Achieving this political will…

…needs various means depending on the situation!

  • Is the pharma industry public or private?
    • Public (Government owned/subsidized): direct interference and decision-making
    • Private: only indirect measures (taxes, drug reimbursement system, etc.)
    • PPP (public-private-partnership): in between


if public
If public
  • The regulation is easier – the state „orders”
  • Different levels
    • Factories belong to Ministry of Health (MoH) or Ministry of Industry, under their supervision, ministerial decisions on what is produced
    • State-owned industry (as a rule, organised into a Trust), the Sates specifies (kinds and quantities) of medicines to be provided
    • Factories are individual profit-centers, the State only nominates management and receives part of the profit


if private
If private
  • Fully domestic?
  • Bought/shared by multis? between these two:„Domestic” but it is on the share-market
  • How to regulate them?

By legislation, taxation? Local management? More direct ways?

Profit remains – repatrioted? (remains in the country or taken away by the foreign owner?)


which level does meet the local needs 1 api manufacture
Which level does meet the local needs? 1. API manufacture

Not an aim in itself! To decide:

  • are there chemical/biological traditions, is expertise available?
  • study of international market for raw materials for local API manufacture (are they available?)
  • or better rely on API import?


established apis manufactured
Established APIs manufactured
  • What is the standard?
  • Does the country have its own Pharmacopoeia?
  • Or regional or well-known (e.g. USP, BP) Pharmacopoeias accepted or WHO International Pharmacopoeia?
  • Is there a policy which quality to manufacture?


is there a policy which quality to manufacture
„Is there a policy which quality to manufacture?”
  • Certainmanufacturersapply more thanone standard
  • After a batch is manufactured, the QC analyseswilldecidewhich standard (e.g. whichPharmacopoeia) has beenmet
  • This is a wrongapproach!


which level does meet the local needs 2 finished drug product manufacture
Which level does meet the local needs?2. Finished drug product manufacture
  • Human resources + supporting infrastructure (water and energy supplies) available?
  • Ingredients purchased - price vs. quality offeredoften products meeting the requirements of only outdated Pharmacopoeias offered


which level does meet the local needs 2 finished drug product manufacture1
Which level does meet the local needs?2. Finished drug product manufacture
  • Complete self-reliance (i.e. local manufacture of every medicine needed) should not be an aim! No country in 100%.
    • Thus, local manufacture + import
  • Aiming also export? But is there a market? Quality could be provided?
  • But local medicine manufacture creates new jobs, decreases prices...


right local manufacture and standards are extremely important
Right local manufacture and standards are extremely important!

The sad mebendazole tablet story!

It happened a few years ago



Mebendazol is an agent used to kill different worms (e.g. pinworms) that infected the human organism

  • The infection rate is high in countries with limited hygienic conditions, e.g. soma parts of Africa
  • UN organizations decided to finance free of charge mebendazole-medication to children in some African countries



The WHO International Pharmaceopoeia had a monograph for mebendazole syrup only

  • The decision was
    • To prefer tablet dosage-form (to avoid distributing „water” to countryside)
    • Sucking tablet, for longer action
    • To find a local manufacturer (to avoid long-distance distibution)
  • Local producer was found. It was ready to develop mebendazole sucking tablets



But it could produce only big tablets

  • Decision: for the tablets would disintegrate after the mebendazole was dissolved and „sucked-out”, no problem

Until now, everything does seem to be logcal, does not?

  • However, mebendazol has various crystal modifications! The metastabil modification can be dissolved from tablets, the stable form can not!
  • The metastable form is manufactured, but, if moisture is present, it is transformed to the stable modification!



This previous information was not taken into consideration/known by the decision-makers

  • Locally manufactured sucking tablets were packed in a non-water-resistant material
  • Mebendazole transformed to its stable crystal form, the tablets were sucked by children in vein. They got tired of sucking and swallowed the big tablet
  • Six children suffocated and died before the issue was identified!



Everybody was benevolent, but

  • The overall knowledge in the product was lacking
  • The product development and control were not done according to international standards
  • Six children were killed by a drug product distributed free of charge by UN bodies!

(end of the story)


if mostly import
If mostly import
    • done by the Government? Or
    • encouraged (or forced) by the Government?
  • Bulk purchasing? (Cheaper!)
    • If API is imported, bulk purchasing may ensure quality-safety-efficacy, but more acceptable price, then the API can be sold to private or „distributed” to public factories
    • If finished products imported in bulk, a local re-packaging factory is needed


even import of finished drug products
Even import of finished drug products…
  • …needs some preparedness!
  • It is very dangerous to buy drugs if you have no local quality control facilities:
    • Counterfeit (fake) products
    • Low-quality or adulterated APIs
  • For countries that have no local control facilities the WHO offered a solution


who certification scheme for products moving in international commerce
WHO Certification Scheme for products moving in international commerce

for medicinal products:

  • certified by the exporting authority to the importing one, when the latter has limited possibilities to control:
    • it has been registered in the country of origin
    • it is subject of GMP inspection
    • possibility of attaching approved information material


who certification scheme for apis
WHO Certification Scheme for APIs
  • info about API manufacturer
  • against brokers who
    • sell everything by repackaging and relabelling as if it were newly produced
    • providing no information on, e.g. potentially harmful solvent residues
  • EU: either own manufacture or Drug Master File or European Pharmacopoeia Certificate of Suitability


Most advanced (EU) requirements for data on API manufacture when submitting applications for medicinal product marketing authorisation
  • The product manufacturer is also the API manufacturer: submits also API manufacture basic data
  • The product manufacturer is different from the API manufacturer:
    • the latter has European Pharmacopoeia Certificate of Suitability
    • the product manufacturer requests the API manufacturer to send the basic API manufacturing data („Drug Master File”) to the authority where the marketing authorisation request for the medicinal product has been submitted


european pharmacopoeia ep certificate of suitability
European Pharmacopoeia (EP) Certificate of Suitability

The API manufacturer initiates it

  • by sending the synthesis route and basic data together with normal impurity (intermediers + decomposition products) samples to the European Department of Quality of Medicines (EDQM)
  • EDQM checks whether the EP monograph methods are suitable to detect/quantify impurities
  • If yes, the Certificate (referred to as Certificat of European Pharmacopoeia, CEP) issued, specific to the given API (manufacturer, synthesis)


purchase of drug and excipient substances only from reliable sources
Purchase of drug (and excipient) substances only from reliable sources
  • is extremely important!
  • As indicated by the „Glycerol story”
  • In the 1960s years, in Haiti, about 50 children died
  • Although the reason was identified, still there are children deaths in the developing World, every year!
  • Why?


glycerol is used as cheap sweetening agent in cough syrups for children
Glycerol is used as cheap sweetening agent in cough syrups for children
  • The cheapest „drug quality” glycerol can be purchased from brokers (who buy it, re-labels and sells. Often „technical quality” glycerol is purchased and re-labeled as „pharmacopoeial”)
  • However, diethylene glycol (toxic!) has the trade name „Glycol”


you already see what happens
You already see, what happens
  • Brokers, by mistake, purchase also GLYCOL, mix it to GLYCEROL and sell it as glycerol
  • Poor country manufacturers do not have access to GLC analyses for every purchased batch, use them as purchased = toxic symptoms and deaths – in vein!


regulation of local medicine manufacture
Regulation of local medicine manufacture

The three regulatory issues

  • Is manufacturing authorisation needed? By whom? (MoH, Min.of Industry…)
  • If so, are minimum standards issued (GMP)? (If yes: which GMP?)
  • Inspected? By whom?


manufacturing authorisation 1
Manufacturing authorisation 1
  • In the majority of the countries, drug manufacture needs prior authorisation
  • By whom?
    • Ministry of Health
    • Drug Regulatory Authority (if independent from the MoH)
    • Other Ministry (Industry)
    • ?
manufacturing authorisation 2
Manufacturing authorisation 2

If authorisation needed,

  • Are there exemptions? (E.g. drug compounding in pharmacies, as a rule, not „manufacture”; local „herbalists other kinds of traditional medicine?)
  • What does it cover? („General drug manufacturing authorisation” - this does not exist in most of the cases, or according to dosage-forms, or sterile – non-sterile, or which other principle?)
manufacturing authorisation 3
Manufacturing authorisation 3

If authorisation needed,

  • What are the prerequisites? In most of the cases: Good Manufacturing Prcatices (GMP, see later)
  • If so, which GMP?
    • ICH-based as in the developed World (ICH: see later)
    • the WHO GMP
    • local GMP?
  • International Conference on Harmonisation
  • Participants:
    • USA, Japan, European Union
    • both Drug Regulatory Authority and Pharma Industry
  • Development of common rules, guidelines, methodology, etc. for drug registration/authorisation
  • Definitely and admittedly to meet the needs of the msot developed countries (e.g., in the guide for drug stability studies no „hot and humid” conditions, that do not apply in these ICH countries)
gmp 1
GMP, 1
  • It is a quality assurance system dedicated to drug manufacture
  • API chapter and Drug Product Chapter
  • Both: basic principles, personnel (incl. hygiene), premises and equipment, documentation, production, quality control, contract production and analysis, complaint handling and recall, self-inspection parts + Annexes (e.g. sterile production, process validation, manufacture of medicinal gases, etc.)
gmp 2
GMP, 2
  • The ICH GMP and the WHO GMP differ only
  • in the order of the chapters
  • the ICH one contains more annexes
    • for the ICH one is intended for the most developed countries, the WHO one for less developed (e.g. no medicinal gas or radiomedicine manufacture expected

„Local” GMPs can be regional (such as ASEAN GMP) or national. As a rule, they follow WHO GMP, sometimes its less updated versions

manufacturing authorisation 4
Manufacturing authorisation, 4
  • Are authorised manufacturers subjected to regular GMP inspections? (=on-the-spot visit and checking of personal and other – see GMP chapters – requirements)
  • Inspectors are governmental officials, belonging to (MoH, Min. of Ind., DRA, etc.)
  • Issues:
    • Where inspectors were trained in GMP?
    • Are there conditions (e.g. education, industrial experience, regular training)?
manufacture and drug compounding
Manufacture and drug compounding
  • A crucial issue: are the industrial mdrug manufacture and large-scale drug compounding in bigger pharmacies (that also sell some compounded drugs to other pharmacies) separated?
  • If so, how is the borderline set?
drug procurement1
Drug procurement

The total of activities resulting in the availibility of medicines in a country: purchasing and distribution

This term is used mostly in developing countries when the State is directly involved in the medicine supply for the interest of the inhabitants


drug procurement2
Drug procurement
  • Public or private sector prevails the medicine supply? (If the latter, as a rule drug wholesalers or „importers” or others?)
  • Public sector: the MoH itself or (semi)autonomous State Procurement Agencies?
  • If public sector in the procurement: systematic tendering needed


procurement important
Procurement, important
  • Import: WHO Certification Scheme (assurance of registration in the country of origin + GMP surveillance)
  • Info on product inter-changeability („what can I buy instead of it, if not available”?)


interchangeability substitution etc
Interchangeability, substitution, etc.
  • The correct information is crucial
  • Used in various meanings
  • It should always be clarified!


interchangeability substitution etc 1
Interchangeability, substitution, etc. 1
  • Same API, same strength, similar dosage-form (e.g. tablets and capsules), bioequivalence proven

interchangeable, theoretically substitution without problems.

But: ready-made and reconstituted syrups…


interchangeability substitution etc 2
Interchangeability, substitution, etc. 2
  • Same API, same strength, similar dosage-form (e.g. tablets and capsules), bioequivalence not known

is the liberation crucial (i.e. the rate-limiting step in the organism)? Individual action (e.g. pain-killer vs. steady-state – absorption in mouth or stomach or only from small intestine?


interchangeability substitution etc 3
Interchangeability, substitution, etc. 3
  • Same API, different strength, similar dosage-form (e.g. tablets and capsules)…

e.g. double strength – can it be broken to two equal parts? Not for capsules…


interchangeability substitution etc 4
Interchangeability, substitution, etc. 4
  • Different API, same therapeutic group…

e.g. ACE inhibitors – selectivity – patient’s reaction may be different…


interchangeability substitution etc 5
Interchangeability, substitution, etc. 5
  • Different API, different therapeutic groups, similar therapeutic application…

e.g. antihypertensives: duiretics – ACE inhibitors – Ca-channel inhibitors – beta-blockers – alpha-blockers…

Questionable, but may be a must in some Third World countries


procurement premises
Procurement, premises
  • Warehouses needed to store the medicines (controlled temperature, cold rooms…)
  • If central storage: distribution means (trucks, cars – more frequently to the countryside – suitable roads?)
  • If regional storage: suitable regional warehouses


procurement process
Procurement, process
  • Estimates (quarterly/annually)

But no “planned economy!”Lead-time

  • Based on health status, morbidity, past period, etc.
  • Buying Public: aggregation of national needs
  • large quantitites but climate, warehousing, shelf-life
  • in bulk and re-package but stability, liability


if possible avoid brokers
If possible, avoid brokers!

Broker: (mostly international) company purchasing cheap medicines (mostly APIs, sometimes also products) „on the world market” (the manufacturer, as a rule, not known), analyses until a Pharmacopoeia found that the delivery complies with, then re-packaging, re-labeling and offered for sale as „newly manufactured” according to this Pharmacopoeia


special procurement donations
Special procurement: donations
  • WHO guidelines: >6 months to expiry date, known and needed by the recipient country
  • Regulatory authority and pharmaceutical expertise involved
  • Otherwise: only export of environmental/waste problems from donor countries


  • Info: what are the drugs that are really needed in the acceptor country vs. drugs that not needed in donor country…
  • Not those collected back from patients

or to be wasted!


distribution wholesaling
  • Only authorised wholesalers? By whom? GMP? Inspections?
  • Storage conditions also during transport
  • Interim storage (airport, freeports), even cold chains for vaccines


storage conditions also during transport
Storage conditions also during transport
  • „TempTags” in the deliveries (devices registering temperature) – the requirement is contained in the contract with transport companies?
  • Is it specified who will be in charge of checking TempTags?


standard for drug manufacture
Standard for drug manufacture

Also for drug wholesaling (some parts)

Good Manufacturing Practice (GMP)

  • General Principles
  • Special Annexes (sterile production, medicinal gases, clinical trial samples, etc.)


our recent special probleme counterfeit drugs
Our recent special probleme: counterfeit drugs
  • = intentional falsification for profit
  • WHO: up to 50% in some Third World countries!


counterfeit drugs types 1
Counterfeit drugs, types 1
  • Good quality, mislabelled using a manufacturer’s name and brand, well-known in the region
  • The same with bad quality: ingredients with more impurities, less stable, API outside (mostly below) the limits


counterfeit drugs types 2
Counterfeit drugs, types 2
  • Bad quality: much less API 50% to 10% (some API contained to be identified by spot tests or basic tests)
  • No API at all! Life-threatening e.g. antibiotics, vaccines, antimalaria medicines


counterfeit drugs types 3
Counterfeit drugs, types 3

Interesting to note:

  • developing countries: basic (mostly life-saving!) drugs
  • developed countries: life-style drugs (e.g. sildenafil)



counterfeit drugs and the supply chain 1
Counterfeit drugs and the supply chain, 1

Different vulnerability!

  • Drugs pharmacy-only, pharmacy owned by pharmacists, mostly drugs sold in pharmacies, drugs bought from licensed wholesalers


counterfeit drugs and the supply chain 2
Counterfeit drugs and the supply chain, 2
  • Drugs pharmacy-only, pharmacy owned by pharmacists, not only drugs sold in pharmacies, products bought from different sources
  • Drugs pharmacy-only, pharmacy owned by laymen/chains, not only drugs sold in pharmacies, products bought from different sources


counterfeit drugs and the supply chain 3
Counterfeit drugs and the supply chain, 3
  • Drugs sold in ordinary shops, fuel-stations, even markets
  • Distant and Internet-selling…


complexity of the supply chain
Complexity of the supply chain




wholesale distributor

complexity of the supply chain1
Complexity of the supply chain

international transport Co


product manufacturer

API manufacturer


international transport Co


global wholesaler

central warehous

drug manufacture procurement and wholesale distribution
Drug manufacture, procurement and wholesale distribution
  • Manufacture
    • Discuss the different levels of local manufacture. Self-reliance?Export?
    • State-owned or public factories versus regulation of the private pharma industry
    • Is authorisation needed? By whom? GMP and inspection
    • Importance of WHO Certification Scheme
  • Procurement
    • Definition
    • Possibilities of private or public procurement
    • Semi-autonomous Procurment Agencies, tendering
    • The interchangeability issue
    • How to make procurement estimates?
    • WHO rules on donations
  • Wholesale distribution
    • Authorisation?
    • Storage and transport
    • Final and interim storage
    • The counterfeit issue
