  1. Nutzung des CPSM-API Josef Knon Systemprogrammierer, Systemadministrator Tel.: +49/171/8216082 email: josef@knon-online.de Josef Knon - Systemprogrammierer

  2. CPSM-Werkzeug auf ISPF-Oberfläche: • Operating • AV • Anwendungsentwicklung • Systemtechnik Josef Knon - Systemprogrammierer

  3. Aktivierung des API für REXX • Beschrieben im CICS/TS Installation Guide • Chapter 30, „Installing the REXX function package“ • EYU9AR01, EYU9AR01 und Alias IRXFLOC aus der SEYUAUTH müssen in eine authorisierte Library (Achtung! IRXFLOC existiert bereits in der SYS1.LINKLIB!) • MVS Linklist oder STEPLIB Josef Knon - Systemprogrammierer

  4. CPSM - Samples • befinden sich in der SEYUCLIB in den Membern • EYU#API1 • EYU#API2 • EYU#API3 Josef Knon - Systemprogrammierer

  5. CPSM - REXX-Sample INIT und CONNECT • Say 'Initializing API...' XX = EYUINIT() If XX <> 0 Then Signal UNEXPECTED Say 'Establishing connection...' XX = EYUAPI('CONNECT' , 'CONTEXT('W_CONTEXT')' , 'SCOPE('W_SCOPE')' , 'VERSION(‚W_Version‘)' , 'THREAD(W_THREAD)' , 'RESPONSE(W_RESPONSE)' , 'REASON(W_REASON)') If XX <> 0 Then Signal UNEXPECTED If W_RESPONSE <> EYURESP(OK) Then Signal NO_CONNECT Josef Knon - Systemprogrammierer

  6. CPSM -REXX-Sample GET OBJECT • Say 'Get the PROGRAM resource table...' W_CRITERIA = 'NOT (PROGRAM=DFH* OR PROGRAM=EYU* OR PROGRAM=IBM*).' W_CRITERIALEN = 'LENGTH'(W_CRITERIA) XX = EYUAPI('GET OBJECT(PROGRAM)' , 'CRITERIA(W_CRITERIA)' , 'LENGTH('W_CRITERIALEN')' , 'COUNT(W_RECCNT)' , 'RESULT(W_RESULT)' , 'THREAD(W_THREAD)' , 'RESPONSE(W_RESPONSE)' , 'REASON(W_REASON)') If XX <> 0 Then Signal UNEXPECTED If W_RESPONSE <> EYURESP(OK) Then Signal NO_GET Josef Knon - Systemprogrammierer

  7. REXX-Sample QUERY OBJECT • XX = EYUAPI('QUERY OBJECT(PROGRAM) THREAD(W_THREAD)', 'RESULT(W_RESULT) DATALENGTH(W_INTO_OBJECTLEN)', 'RESPONSE(W_RESPONSE) REASON(W_REASON)') If XX <> 0 Then Signal UNEXPECTED If W_RESPONSE <> EYURESP(OK) Then Signal NO_QUERY Josef Knon - Systemprogrammierer

  8. CPSM-REXX-Sample FETCH und TPARSE Do III = 1 To W_RECCNT • XX = EYUAPI('FETCH INTO(W_INTO_OBJECT)' , 'LENGTH(W_INTO_OBJECTLEN)' , 'RESULT(W_RESULT)' , 'THREAD(W_THREAD)' , 'RESPONSE(W_RESPONSE)' , 'REASON(W_REASON)') If XX <> 0 Then Signal UNEXPECTED If W_RESPONSE <> EYURESP(OK) Then Signal NO_FETCH • XX = EYUAPI('TPARSE OBJECT(PROGRAM)' , 'PREFIX(PGM)' , 'STATUS(W_RESPONSE)' , 'VAR(W_INTO_OBJECT.1)' , 'THREAD(W_THREAD)') If W_RESPONSE <> 'OK' Then Signal UNEXPECTED W_TEXT = PGM_PROGRAM W_TEXT = 'OVERLAY'(PGM_LANGUAGE,W_TEXT,10) W_TEXT = 'OVERLAY'(PGM_STATUS,W_TEXT,23) W_TEXT = 'OVERLAY'(PGM_CEDFSTATUS,W_TEXT,36) Say W_TEXT End III XX = EYUAPI('TERMINATE RESPONSE(W_RESPONSE) REASON(W_REASON)') XX = EYUTERM() Josef Knon - Systemprogrammierer

  9. REXX-Sample PERFORM OBJECT if cmd = 'NEW' then CMD = 'NEWCOPY' if cmd = 'PHA' then CMD = 'PHASEIN' if cmd = 'ENA' then CMD = 'ENABLE' if cmd = 'DIS' then CMD = 'DISABLE' W_CMD = cmd .... W_CRITERIA = '(PROGRAM='pgm').' W_CRITERIALEN = 'LENGTH'(W_CRITERIA) • XX = EYUAPI('PERFORM OBJECT(PROGRAM)' , 'CRITERIA(W_CRITERIA)' , 'LENGTH('W_CRITERIALEN')' , 'ACTION('W_CMD')' , 'COUNT(W_RECCNT)' , 'RESULT(W_RESULT)' , 'THREAD(W_THREAD3P)' , 'RESPONSE(W_RESPONSE)' , 'REASON(W_REASON)') If XX <> 0 Then Signal UNEXPECTED If W_RESPONSE <> EYURESP(OK) Then Signal NO_GET Josef Knon - Systemprogrammierer

  10. Das Einstiegs-Bild Josef Knon - Systemprogrammierer

  11. Anzahl Transaktionen Josef Knon - Systemprogrammierer

  12. CPSM Help PF1 Josef Knon - Systemprogrammierer

  13. Events Josef Knon - Systemprogrammierer

  14. DSA Josef Knon - Systemprogrammierer

  15. Close File Josef Knon - Systemprogrammierer

  16. Purge Task Josef Knon - Systemprogrammierer

  17. Entfernen eines CICSes aus demaktiven WLM Josef Knon - Systemprogrammierer

  18. WLM Josef Knon - Systemprogrammierer

  19. Log über User-Aktivitäten Josef Knon - Systemprogrammierer

  20. RACF-Security • CLASS Resource ACCESS • CPSMOBJ ** ALTER • OPERCMDS MVS.ACTIVATE UPDATE • OPERCMDS MVS.CANCEL.* UPDATE • OPERCMDS MVS.CANCEL.STC.* UPDATE • OPERCMDS MVS.MODIFY.* UPDATE • OPERCMDS MVS.START.STC.* UPDATE • CONSOLE CICPPLX1 READ • CONSOLE CICTPLX1 READ Josef Knon - Systemprogrammierer
