Presentation Transcript
summary
Summary

After 25 years of retrenchment, nuclear power is firmly on the agenda, both in UK and around the world – driven by the issues of:

Climate Change;

Energy Security.

UK will replace (at least twice over) the current ~10GWe nuclear capacity;

Global potential for >1000 new large reactors in next 30 years

– replacing the current 400 reactors (~350 GWe) growing the share of global electricity from 15% to ~35%

Design topics covered:

Thermal nuclear reactors design essentials;

Some design safety & reactor vessel considerations;

Extending the fuel resource available for nuclear fission power in thermal systems;

Longer term development of Advanced Systems;

Part 1

Part 2

Reactor Design

Design Safety

Fuel Resource

Advanced Systems

Part 2

Part 1

issues for the 21 st century
Issues for the 21st century?

Response to World Credit Crunch;

Climate Change;

Nuclear Proliferation;

International terrorism.

Gordon Brown Mansion House Nov 2009

Nuclear is (for a good or ill) linked to at least 3 of these issues:

Credit crunch –> UK over reliance on financial services – new manufacturing?

Climate Change -> Expanding and de-carbonising electricity supply;

Nuclear Proliferation -> New fuel cycles that avoid creating or protect potential nuclear bomb materials.

civil nuclear power global market
Civil Nuclear Power Global Market

Current capacity:

Nuclear energy currently provides approximately 15% of the world’s electricity.

Currently around 440 nuclear plants, across 30 countries, with a total capacity of over 370 GW.

Future Capacity:

There may be a global build rate of up to 12 nuclear reactors per year between 2007-2030, which expected to rise to 23-54 reactors a year between 2030-2050.

Market value:

A recent assessment by Rolls-Royce estimated that:

Global civil nuclear market is currently worth around £30bn a year;

By 2023 market could be worth around £50bn per year;

Of this, approximately £20bn pa will be new build, £13bn pa in support to existing nuclear plant, and £17bn pa in support of new build reactors.

The Road to 2010 Cabinet Office July 2009

Westinghouse AP1000

simplified reactor physics fission
Simplified Reactor Physics - Fission

Thermal reactor fission:

Uranium 235 is the only

naturally occurring fissile

atom - typical fission reaction

n + U235 Xe140 + Sr94 + ~2n + 193Mev

thermal fast

High thermal n absorption

Fission Product distribution

low fast n absorption

Intermediate energy resonances linked to quantum states - loss of n

Uranium 235 fission cross section

simplified reactor physics criticality 4 factor equation
Simplified Reactor Physics – Criticality (4 factor equation)

In an infinite homogenous reactor :

  • Fission of Uranium produces more neutrons than are absorbed by fuel as thermal neutrons – η & 200 MeV of energy
  • Fission neutrons augmented by some fast fission - ε
  • As neutron slowed down, some are lost to process by capture in fuel resonance (1 - p) & others by moderator absorption (1 - f);
  • Surviving thermal neutrons lead to new fission – less than 1 sub-critical, more than 1 supercritical.

Infinite multiplication factor k∞ = ε * η * p * fAll these are factor are functions of cross-sections - hence the probabilities are all functions of neutron energy

the first nuclear reactor
The First Nuclear Reactor
  • Enrico Fermi and a team from Metallurgy Department of University of Chicago built and controlled the first sustained nuclear reaction;
  • In a racquets court in Staggs Field athletics stadium of the University of Chicago on 2 Dec 1942;
  • Reactor constructed from Graphite blocks and Uranium metal constructed in ‘pile’ in 30’ * 60’ room with Cadmium coated control rods;
  • The team proved that sustained fission or a multiplication factor k >1 could be achieved , and the measurements were made for the first practical sustained nuclear reactor;
  • Three types of control rods:
    • Electric motor operated controlling rods;
    • Emergency ‘zip’ rod driven in by gravity;
    • Liquid Cadium salts to be released into a control tube.
  • Sustained fission demonstrated by neutron count growing exponentially i.e. keff >1

CP1 – Chicago Pile 1

simplified reactor physics designs
Simplified Reactor Physics – Designs

Thermal reactor fission:

Infinite multiplication factor k∞ = ε * η * p * f

(homogenous infinite reactor)

  • Most (80%) of the 193 MeV (3.1 * 10-11 J/fission) of energy is released in the fission products as kinetic energy –dissipated within a few microns as heat - fission products interacting with the surrounding material;
  • 8% as beta and gamma radiation from the decay of fission products – decaying to more stable isotopes;
  • Other energy in neutrons, prompt gamma rays and neutrinos.

Practical systems: - different effects of: enrichment, neutron leakage/reflection, moderator/fuel volume ratio, structural materials, control elements, burnable poisons & re-fuelling strategy etc.

PWR (light water - H20) CANDU (heavy water - D20)

Fast fission ε 1.27 1.0

Fissions per absorption ηT 1.89 1.31

Fuel resonance capture 1 - p 0.37 0.16

Moderator capture 1 - f 0.06 0.03

Infinite multiplication k∞ 1.41 1.12

Thermal diffusion length 2.8 cm 1.7m

Core Power rating 100MW/m3 8MW/m3

Enrichment 4.2% 0.7% (natural U)

light water reactors are dominant pressurised water boiling water reactors
Light Water Reactors are DominantPressurised Water & Boiling Water Reactors
  • PWR
  • Derived from submarine propulsion reactors & widely installed around the world ~ half of world capacity;
  • Low thermal efficiency ~33%;
  • Major problem was Three Mile Island in 1981 where minor fault led to confusing signals & operators damaged reactor;
  • Initial materials problems led to low reliability - since rectified
  • Now preferred in EU, Russia & China, sharing market in US with BWR
  • BWR
  • Simpler plant with integrated core cooling and power cycle, high radiation dose from operation;
  • Core and steam separation integrated in one vessel;
  • Activated Nitrogen16 limits access to turbine during operation;
  • Some doubts about safety containment;
  • More complex coolant chemistry;
  • Popular in US, Sweden and Japan.
pressurised water reactor
Pressurised Water Reactor
  • PWR overview:
  • Operating conditions :
    • Pressure: 16 MPa
    • Average temperature: 280-290oC
  • Reactor core consist of bundles of enriched ~3% Uranium Oxide or (MoX) in open bundles with Zircalloy fuel clad tubes;
  • Vertical control rods operated from the top of the reactors;
  • Multiple loops (3 or 4) carrying sub-cooled water, flowing upwards through core;
  • Refuelling at 3 years intervals from top of core by means of removable vessel head;
  • Complex coolant injection and decay heat removal systems – issue addressed by latest Westinghouse design AP1000;
  • Able to separate chemistry strategies of primary and secondary/condenser water;
  • Most popular reactor design ~50% of installed capacity: US, France, Germany, Spain & now Russia & China – high availability, long fuel cycles & low operator dose.
  • .
boiling water reactor
Boiling Water Reactor
  • BWR overview
  • Operating conditions:
    • Pressure (saturated) ~7.3 MPa
      • Average temperature 310oC
  • Reactor core consist of bundles of enriched ~3% Uranium Oxide or (MoX) in shrouded bundles with Zircalloy fuel clad tubes;
  • Vertical control rods operated from bottom of core – do not drop into core to shut-down reactor;
  • Reactor cooling flow by augmented natural convection;
  • Steam separators above the core with direct feed to wet steam turbines – some carry over of contamination;
  • Complex power control and multi-level emergency core cooling systems;
  • Refuelling at 2 year intervals from top of core by means of removable vessel head;
  • Coolant chemistry has to cover contamination from condenser water as well as core requirements – not preferred for coast sites because of potential chloride contamination?
  • Defence against major accident must take account of reactor & turbine building – containment, aircraft crash etc.
candu heavy water reactor
CANDU Heavy Water Reactor
  • Canadian design - using natural uranium metal and pressurised heavy water in horizontal Zircalloy pressure tubes, surrounded by heavy water moderator/reflector tank;
  • Operating Conditions: Temp: 280oC Press: 10MPa
  • Large dimension core with low power density 8MW/m2;
  • Conventional wet steam secondary power cycle with low thermal efficiency – 33%;
  • Regular on-load refuelling using built-in horizontal charge machine;
  • Complex D2O handling & Tritium is produced & emitted;
  • Large evolutionary program in Canada with exports based on good operating performance in 1980s : China, Korea, Romania, Argentina, India and Pakistan etc.
  • More recently, beset with Zircalloy pressure tube delayed hydrogen cracking problems, requiring wholesale replacement of pressure tubes;

Core & Moderator tank

Candu 6 -Fuel subassemblies

nuclear safety philosophy
Nuclear Safety Philosophy
  • Developed world safety approach:
  • Design base events which are always protected with a significant margin of safety;
  • Large scale events rendered very unlikely by:
    • providing defence in depth/multiple barriers to release;
    • including features and best practise in the design to extent that is ALARP.

Frequency

pa

Complete Protection with high degree of certainty

10-4

Chernobyl ~2 days after the prompt criticality followed by a core fire in 1986

Fundamental faults – design: positive void coefficient & control rod design - plus ,very poor operating knowledge & controls.

Larger releases - by design made most unlikely

Area of acceptance of design

ALARP – best practice continually challenged

10-7

Release

Probabilistic safety target

chernobyl criticality accident
Chernobyl – Criticality Accident
  • RBMK reactor in the Ukraine on 26 April 1986 at 0123 hrs was undergoing an experiment – to investigate low power operation;
  • Automatic shut-down system was switched off because of difficulties operating at the low power levels required by the test and most of the control rods withdrawn - all but 6 (safe level ~30);
  • Experiment led to reduced cooling & boiling in the channels increasing core reactivity, which was made worse by the shut-down system adding further reactivity, leading to a very large increase in core power *100 ;
  • Fuel pellets exploded, damaging cooling the fuel channels – escaping steam blew off top of reactor – followed by a second explosion from hydrogen produced from either Zr-water or Graphite water reactions;
  • Much of core & graphite moderator was ejected and graphite caught fire continuing the release of radioactivity, which was spread by the weather patterns across Ukraine, Russia & W Europe;
  • About 40 operators and fire fighters died within 3 months as a result of exposure to radiation as they put out the fire and brought the situation under control (plus further ~200 later from effects);
  • 17 mile exclusion zone around the plant with 10,000 people displaced;
  • Broader concerns about health effects across Europe - but the measured effects is an increased level of ~4000 cases of treatable thyroid cancer in children;.

RBMK vertical Fuel & Cooling channels Graphite moderator

decay heat energy
Decay Heat & Energy

Decay Heat (Beta & Gamma): P(t) = 0.0622P0(t-0.2 – (t+t0)-0.2)

Integrated stored energy G(t) = 0.0622P0 * 1/0.8 (t0.8 -(t+t0)0.8 + t00.8 )

For: P0 = 3000MW

t0 = 2 years = 2*365*24*3600 = 6.3 * 107 EOL

P (1day) = 0.0046 *3000 ~ 14 MW - equivalent to Latent Ht ~7 kg/s of water

G (1day) = 534 *3000 ~ 1600 GJ - equiv to LH of 800m3 of water RPV ~500m3

- energy required to melt large civil core ~200GJ !!

three mile island loss of coolant accident
Three Mile Island – Loss of Coolant Accident
  • Loss of cooling accident at Three Mile Island, Pennsylvania on Wed 29 March 1979 which was:
    • Exacerbated by operator error and bad human factors design,
    • Led to partial melt-down of the core, and
    • Gaseous fission product release from the station, and
    • Mass evacuation of surrounding area.
  • Steps:
    • Equipment failure in the steam cycle plant, led to feed-water s hut-of loss and automatic reactor shut-down;
    • Back-up feed system was down for maintenance;
    • Decay heat build-up raised primary pressure & relief valve operated;
    • Relief valve did not shut , was not recognised & 120m3 of primary coolant discharge in 3 hours;
    • Operator did not recognise symptoms, stopped injecting water, switched off the coolant pumps allowing, core coolant to boil displacing water into the Pressuriser and uncovering the core;
    • Much of the core melted within about 4 hours , releasing fission products – 13 million curies of noble gases (Xenon & Kryton) plus ~17 curies of Iodine 131 to the circuit - via the relief valve outside the reactor.
  • Reactor has been disassembled with the damaged core and the vessel removed – but accident changed the whole approach to the design and operation of nuclear reactors.
nuclear safety approach affects the design
Nuclear Safety approach affects the design

Events & Hazards

Opened ended process for identification of potential hazards

Plant Faults

External Haz

Internal Haz

Normal Operation

Analyse event & accident sequences with frequencies

Consider primary & secondary means of protection

---> Design basis of structures, containment & safety systems, including human factors

Probabilistic Risk Analysis

Low frequency < 10-4 pa

/high consequence

Design Basis Analysis

High frequency >10-4 pa

Demonstrate with high degree

of certainty

nuclear safety some vessel design cases
Nuclear Safety - some Vessel Design Cases
  • Normal Operation:
  • Warm-up & Cool down to operating conditions
  • Power transients:
    • Normal
    • Power & pressure overshoot
  • Scram shut-down/cool-down of reactor
  • Cases include:
  • Brittle fracture;
  • Low cycle fatigue;
  • Max pressure & protection;
  • Cold shock.

Design Basis Analysis

High frequency >10-4 pa

Demonstrate protection with

a high degree of certainty

  • Cases include:
  • Neutron irradiation damage;
  • Cold shock;
  • Defect identification and eradication by design & construction.
  • Accident Sequences:
  • Brittle fast fracture of vessel due to in-built defects
  • Response to loss of coolant accidents
  • Vessel cracking due to in-built defects

Probabilistic Risk Analysis

Low frequency < 10-4 pa

/high consequence

design optimisation process for components
Design Optimisation Process for Components
  • Design
  • Operation & Performance requirements
  • Configuration & sizing
  • Materials & Man’f
  • Material properties & composition
  • Manufacture processes & Assurance of integrity
  • Safety
  • Event sequences
  • Degraded modes examined
  • Control & protection systems

Iterative process

Concept

System design

Component design

  • Stressing
  • Modelling of design & loads
  • Stress intensity factors & critical defect sizing
some pressure vessel design considerations
Some Pressure Vessel Design Considerations
  • Reactor Vessel (RPV) contains the core - fissile & heat generating material:
    • Design topics:
      • Retain primary circuit pressure up to ~180 bar & temperatures up to 340oC ;
      • Able to operate at sub-cooled down to ambient temperatures ~ 20oC;
      • Exposed to high level of energetic neutrons from fissile reaction s;
      • Maintain core covered with water from the day when it is loaded until/including when removed after 3 years;
      • RPV integrity is absolutely fundamental to plant safety that RPV cracking or other failure has be ‘incredibly’ unlikely – < 1 in million years - nothing that is feasible of being done to ensure integrity will not be done;
  • Issues to be addressed:
    • Pressure requirements lead to choice of ferritic steels – low temperature brittle fracture?
    • Neutrons embrittle this type of steel – choice of alloy & control of trace elements 7 microstructure;
    • Thermal and pressure cycles drive crack growth;
    • RPVs constructed from welded plates – absence of inclusions/defect & built-in stresses;
    • Measures to ensure that failure is rendered incredible??

Design Safety

pwr vessel materials topics
PWR Vessel & Materials topics

Control rod motor support tube – dis-similar tube to head welds

Vessel nozzle welds – low cycle fatigue

Fracture of neutron embrittled Reactor Vessel

Issues include: 60 year plant life; assurance of safety margins; manufacture & inspection standards, effectiveness of enhanced material testing.

idealised pressure vessel design
Idealised Pressure Vessel Design
  • Purpose:
  • Contain pressure to control cooling at power – sub-cooled for PWR & saturated for BWR
  • Maintain core covered with water - post shutdown, in all conditions, including accidents – decay heat ~1% of full power for long periods of time.
  • Design objectives;
  • Lower stress
  • Strong material
  • High toughness
  • Low brittle transition
  • Assurance of zero defects
  • Long life ~60 years

Core

Neutron Flux Profile

Two topics:

Assurance of vessel Integrity through-life

Ductility & Operating limits

pressure vessel ductility irradiation hardening sets plant operating limits
Pressure Vessel DuctilityIrradiation hardening sets plant operating limits

Stress Intensity factor

Op Pt

*

290C 15MPa

Saturated water line

ASME

Lower bound reference temp-toughness curve

ΔT

Temp

  • Embrittlement processes:
  • Degree of embrittlement from irradiation is very dependant on trace elements Ni, Cu & P
  • Generation of lattice defects in displacement cascades by high-energy recoil atoms from neutron scattering;
  • Diffusion of primary defects also leading to enhanced solute diffusion and formation of nano-scale defect-solute cluster complexes, solute clusters, and distinct phases, primarily copper-rich precipitates (CRPs)
  • Dislocation pinning and hardening by these nano-features
  • Hardening-induced DTt shifts

ASME Lower bound reference toughness-temp curve shift ΔT

Embrittlement of nuclear reactor vessels - Odette & Lucas JOM 2001

pressure vessel design integrity
Pressure Vessel Design - Integrity
  • Neutron Embrittlement
  • Water is a good moderator -> large RPV diameter
  • Steel is a good reflector –> un-stressed thermal shields
  • Vessel made from low alloy high strength steel of controlled composition: A533B plates, or A508 forgings, quenched and tempered - C(0.05–0.2%), Mn(0.7–1.6%), Mo(0.4–0.6%), Ni(0.2– 1.4%), Si(0.2–0.6%), & Cr (0.05–0.5%).
  • Construct from forgings with minimum welds – avoiding regions of high neutron flux;
  • Vessels are tempered & stress relieved, typically at about 620±15°C for about 30 h, resulting in as-fabricated yield stress values of ~ 475±50 MPa.

Nozzle

Zone

  • Design objectives;
  • Lower stress
  • Strong material
  • High toughness
  • Low brittle transition
  • Assurance of zero defects
  • Long life ~60 years

Core

Neutron Flux Profile

Weld

Zone

incredibility of failure vessel design
Incredibility of Failure - Vessel Design

Because core safety depends on keeping fuel covered with water, its failure must be ‘incredible’

Three broad strategies – each pursued fully – a practical example of ALARP:

  • Zero defects in manufacture;
    • Qualified processes completed by skilled & qualified welders & technicians;
    • Multiple & varied inspection of welds by manufacturer;
    • Investigation & repair of all detectable defects;
    • Independent inspection of welds by qualified third party.

2.Examination of vessel through-out life to ensure that defects are not present/or not growing:

    • Pre-service inspection of vessel provides the base-line;
    • Inspection of critical parts of vessel during re-fuelling outages

3. Vessel is tolerant of any defect that might be present.

    • Stresses will below critical crack growth levels for postulated cracks based on the demonstrated inspection capability;
    • Evaluate broadest set of operating transients to determine crack growth low cycle fatigue;
    • Take account of irradiation hardening & thermal aging
1 manufacture for zero defects ability to detect repair weld defects
1. Manufacture for zero defectsAbility to Detect & Repair Weld Defects

From: Transactions, SMiRT 19, Toronto, August 2007

Small Voids in Base metal – machine weld

Identified by ultrasonic testing

Complex Repair Flaw - Lack of Fusion

Collection of small flaws in a weld repair that make up a larger defect is not fixed.

2 nde verification sizewell b
2. NDE Verification – Sizewell B
  • Inspection verification of manufacturers & pre-service inspection contractors by AEA Technology
  • Multiple inspection agencies:
  • Creusot- Loire - Forgings;
  • Framatome – Main welds
  • Babcock Energy – Supplier - Machining & Outfitting
  • Rolls-Royce – Pre-service inspection
  • OIS – Studs & Nuts
  • Shows:
  • Value of certifying inspection agencies, &
  • Inspectors can correctly & repeatedly identify and size defects.
3 detailed analysis all severe accidents thermal stressing analysis loca an example
3. Detailed Analysis all Severe AccidentsThermal Stressing Analysis LOCA – an example

Small break LOCA

Temperature profile

Konvoi 3 loop PWR

Tangential stress profile

inlet nozzle analysis

Analysis to show that stresses when applied to critical defect size, does not lead to catastrophic crack growth or vessel fracture.
