Minerals. What is a Mineral?. Naturally-formed solid substance with a crystal structure. Pyromorphite. What do all minerals have in common?. All: Are formed by natural processes. Are NOT alive and NEVER were alive Have a definite volume and shape

loader
I am the owner, or an agent authorized to act on behalf of the owner, of the copyrighted work described.
capcha
Download Presentation

Minerals


An Image/Link below is provided (as is) to download presentation

Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.


- - - - - - - - - - - - - - - - - - - - - - - - - - E N D - - - - - - - - - - - - - - - - - - - - - - - - - -
    Presentation Transcript
    1. Minerals

    2. What is a Mineral? • Naturally-formed solid substance with a crystal structure Pyromorphite

    3. What do all minerals have in common? All: • Are formed by natural processes. • Are NOT alive and NEVER were alive • Have a definite volume and shape • Are elements or compounds with a unique chemical makeup • Are made up of particles that are arranged in a pattern that is repeated over and over (called a CRYSTAL)

    4. Watch “Crystals” by Brainpop… • .What element are diamonds made from? • . What do all crystals have in common?

    5. Groups of Minerals • Minerals are grouped by the elements they are made of. Beryl (Emerald) Calcite Amethyst

    6. MICA Quartz

    7. Silver Copper Diamond Gold Iron Ruby

    8. Calcite with Duftite inclusions

    9. BariteBaSo4 Barite on CalciteBaSo4 / CaCO3

    10. How do minerals form? • 1) Cooling of magma (hot, liquid rock and minerals inside the earth (from the mantle)) • Fast Cooling = No Crystals (mineraloids) • Medium Cooling = small crystals • Slow Cooling = large crystals

    11. How do minerals form? • 2) Elements dissolved in liquids (usually water)

    12. Physical Properties of Minerals(can be used to identify the mineral) Color • Can be misleading • Can vary with the type of impurities

    13. Physical Properties of Minerals(can be used to identify the mineral) Luster • Surface reflection • metallic = shiny like metal • non-metallic = dull, non-shiny surface Pyrite has a metallic luster Calcite has a non-metallic luster

    14. Physical Properties of Minerals(can be used to identify the mineral) Streak • The color of the powdered form of the mineral • The color of the streak can be different than the mineral • Minerals must be softer than the streak plate

    15. Streak…can help identify quartz BUT... http://www.childrensmuseum.org/geomysteries/cube/b3.html

    16. Physical Properties of Minerals(can be used to identify the mineral) Hardness • How easily a mineral scratches materials • Mohs Hardness Scale • Scale from 1 (softest) to 10 (hardest) • Test by seeing if the mineral can scratch different objects (like human fingernail, copper, penny, glass, steel file)

    17. Find out more… • “Electronic” Hardness Test http://www.childrensmuseum.org/geomysteries/cube/b2.html

    18. Physical Properties of Minerals(can be used to identify the mineral) Cleavage & Fracture • The way the mineral breaks • Cleavage—minerals break along smooth, flat surfaces and every fragment has the same general shape • Fracture—minerals that break at random with rough or jagged edges

    19. 1. 4. 3. 2. Cleavage or Fracture?

    20. Physical Properties of Minerals(can be used to identify the mineral) Other Properties • Specific gravity (*excellent clue to mineral’s identity) • Attraction to magnets • Bending of light • Reaction with hydrochloric acid • Smell & taste http://www.childrensmuseum.org/geomysteries/cube/b4.html

    21. Watch Brainpop—“Mineral Identification” • . If a mineral can scratch your fingernail, the mineral is _______________ than your fingernail. • 2. What is luster?

    22. Watch Classifying Minerals Clip
