C4 3 Speed Automatic Transmission

c43 speed automatic transmission the c4 3 speed automatic transmission is a popular choice for many drivers because it offers Excellent performance and reliability. This transmission is available in a variety of different configurations, <br><br>You Can Buy from Link Below u2013 <br><br>https://www.totalperformance.net.au/c4-streetfighter-converter-for-26-spline-in-case-d~20941<br><br>Direct Approach u2013 (03) 9362 0266, 1800 351 351<br>

total9
Download Presentation

C4 3 Speed Automatic Transmission

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. C4 3 Speed Automatic Transmission

  2. Max up your car performance with C4 3-speed automatic transmission, exclusively available at Total Performance. Get genuine, quality auto parts with simple payment options, all at Total Performance. Visit the website now!

  3. Ford started making the C4 gearbox in 1964. The 2-speed Ford-O-Matic transmission was intended to be replaced by the C4, also known as the 3-speed Cruise-O-Matic transmission. The C4 was primarily available in automobiles during its first year of production, including the Ford Fairlane and the Mercury Comet. The Ford F-Series trucks and eventually the Ford Bronco received this transmission the following year as well. The Ford Mustang and Ford Torino were two further well-known vehicles that featured this transmission. C4 Automatic Transmission: Technical Specs Due mostly to its simplicity and small weight, the C4 transmission has grown to be a very popular gearbox for use in hot rods and other racing applications. These vehicles typically feature C4 gearboxes that have been modified. Some aftermarket businesses assert that this transmission can manage more than 1,000 horsepower with their upgrades.

  4. The C4 is a longitudinally mounted automatic transmission. Aside from that, the transmission had three gear ratios: 2.46 for the first, 1.46 for the second, and 1 for the third. A transmission ratio of 2.18 was chosen for reverse. C4 Automatic Transmission: Materials and Dimensions Compared to the 2-speed Ford-O-Matic, the C4 is a lot lighter. One of the main factors is that the Ford-O-Matic was built of cast iron, but the C4 was composed of aluminum alloy. The bell housing, main case, and tail housing of the C4 could all be separated into separate sections. These three are made of an aluminum alloy. Depending on whether the case fill or pan fill option is chosen, the C4 automatic transmission is a little over 20 inches long. Compared to the 228 pounds of the Ford-O-Matic, the C4 weighed only 110 pounds dry and without a torque converter.

  5. You Can Buy from Link Below – https://www.totalperformance.net.au/c4-streetfighter-converter-for-26-spline-in-case-d~20941 • Direct Approach – (03) 9362 0266, 1800 351 351
