二阶 RC 网络系统

二阶 RC 网络系统. 试列写图中所示 RC 无源网络的微分方程。输入为 u i (t) ，输出为 u 0 (t) 。. 解 根据基尔霍夫定理，可列出以下式子：. 整理得：. 令 T 1 = R 1 C 1 ， T 2 = R 2 C 2 ， T 3 = R 1 C 2 则得. 该网络的数学模型是一个二阶线性常微分方程。.
