  1. Brückenschaltung 1

  2. Schaltung 1 U3 = 40V U4 = 20 V R3 = 40 Ohm R4 = 20 Ohm

  3. Schaltung 1 U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  4. Schaltung 1 R1 = 80 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  5. U1 = ?? U2 = ?? Schaltung 1 R1 = 80 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  6. U1 = 40V U2 = ?? Schaltung 1 R1 = 80 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  7. U1= 40V U2 = 20 V Schaltung 1 R1 = 80 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  8. U1 = 40V U2 = 20 V Schaltung 1 1= ??? R1 = 80 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  9. U1 = 40V U2 = 20 V Schaltung 1 1= +20V R1 = 80 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  10. U1 = 40V U2 = 20 V Schaltung 1 1= +20V R1 = 80 Ohm R2 = 40 Ohm U12= ??? U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  11. U1 = 40V U2 = 20 V Schaltung 1 1= +20V R1 = 80 Ohm R2 = 40 Ohm U12= 0V U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  12. U1 = 40V U2 = 20 V Schaltung 1 1= +20V Die Spannung an der Brücken-diagonale beträgt OV -> Die Brücke ist ABGEGLICHEN R1 = 80 Ohm R2 = 40 Ohm U12= 0V U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  13. Brückenschaltung 2

  14. Schaltung 2 U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  15. Schaltung 2 R1 = 40 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  16. U1 = ??? U2 = ??? Schaltung 2 R1 = 40 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  17. U1 = 30V U2 = 30 V Schaltung 2 R1 = 40 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  18. U1 = 30V U2 = 30 V Schaltung 2 1=??? R1 = 40 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  19. U1 = 30V U2 = 30 V Schaltung 2 1= +30V R1 = 40 Ohm R2 = 40 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  20. U1 = 30V U2 = 30 V Schaltung 2 1= +30V R1 = 40 Ohm R2 = 40 Ohm U12= ??? U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  21. U1 = 30V U2 = 30 V Schaltung 2 1= +30V R1 = 40 Ohm R2 = 40 Ohm U12= +10V U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  22. Brückenschaltung 3

  23. Schaltung 3 U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  24. Schaltung 3 R1 = 50 Ohm R2 = 10 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  25. U1 = ??? U2 = ??? Schaltung 3 R1 = 50 Ohm R2 = 10 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  26. U1 = 50V U2 = 10 V Schaltung 3 R1 = 50 Ohm R2 = 10 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  27. U1 = 50V U2 = 10 V Schaltung 3 1=??? R1 = 50 Ohm R2 = 10 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  28. U1 = 50V U2 = 10 V Schaltung 3 1= +10V R1 = 50 Ohm R2 = 10 Ohm U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  29. U1 = 50V U2 = 10 V Schaltung 3 1= +10V R1 = 50 Ohm R2 = 10 Ohm U12= ??? U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  30. U1 = 50V U2 = 10 V Schaltung 3 1= +10V R1 = 50 Ohm R2 = 10 Ohm U12= -10V U3 = 40V U4 = 20 V 2= +20V R3 = 40 Ohm R4 = 20 Ohm

  31. ENDE
