  1. GIWW Western Closure GateWOCA Tour Nov. 29, 2010

  2. The pumping station is shaping up

  3. The T-wall across the canal

  4. This is where the sector gate will sit when open

  5. Intake to one of the 11 pumps

  6. Pump intake

  7. The pump impellor – from inside the pump – 10 feet in diameter

  8. Pump intakes with debris grates and scrappers
