Drafting Tools
Drafting Tools. By: Ghadir Wael Elsaigh . T-Square. It is used to draw horizontal, straight, and 0 degree lines. Parallel Bar. Used on the drafting board to draw horizontal, straight lines. Triangles. A 30, 60, 90 triangle is used to draw lines at 30, 60, and 90 degrees.
