  1. PBN a FPL 2012 19.5.2011 IATCC Jeneč ŘLP ČR s.p. Tomáš Duka

  2. PBN a FPL 2012 PBN Performance based navigation (navigace podle výkonnosti) • ICAO Doc 9613 • sjednocení názvosloví a požadavků na vybavení ( Evropa B-RNAV, P-RNAV, FMS/GPS, B-RNAV+, …RNP) ( USA RNAV type A, RNAV type B) PBN - Specifikace RNAV PBN - Specifikace RNP - vyžadují „on board monitoring and alerting“ 2

  3. PBN a FPL 2012 4

  4. PBN a FPL 2012 Použití v ČR B-RNAV = RNAV-5 P-RNAV ≈ RNAV-1 RNP APCH = RNAV(GNSS) • RNAV NPA - LNAV • APV BARO - LNAV/VNAV • APV SBAS (EGNOS, WAAS) - LPV 5

  5. PBN a FPL 2012 FPL 2012 Pole 10: A GBAS landing system B LPV (APV SBAS) G GNSS R PBN approved 5

  6. PBN a FPL 2012 FPL 2012 Pole 18: PBN/…. A 1 RNAV 10 B 1 RNAV 5 – všechny senzory B 2 RNAV 5 - GNSS B 3 RNAV 5 – DME/DME B 4 RNAV 5 – VOR/DME B 5 RNAV 5 – INS nebo IRS B 6 RNAV 5 – LORAN C 5

  7. PBN a FPL 2012 FPL 2012 Pole 18: PBN/…. C 1 RNAV 2 – všechny senzory C 2 RNAV 2 - GNSS C 3 RNAV 2 – DME/DME C 4 RNAV 2 – DME/DME/IRU D 1 RNAV 1 – všechny senzory D 2 RNAV 1 - GNSS D 3 RNAV 1 – DME/DME D 4 RNAV 1 – DME/DME/IRU 5

  8. PBN a FPL 2012 FPL 2012 Pole 18: PBN/…. L 1 RNP 4 O 1-4 Basic RNP 1 S 1 RNP APCH S 2 RNP APCH + Baro VNAV T 1 RNP AR APCH + RF (radius to fix) T 2 RNP AR APCH 5

  9. www.rlp.cz
