on approximating a geometric prize collecting traveling salesman problem with time windows

On approximating a geometric prize-collecting traveling salesman problem with time windows

Reuven Bar-Yehuda

Guy Even

Shimon (Moni) Shahar

slide2

1.5 hours

4 hours

2 hours

2 hours

2 hours

1 hour

1 hour

1 hour

Motivation – nurse visiting patients

10:00-11:00

6:00-7:00

12:00-8:00

16:00-17:00

0.5 hour rest

17:00-18:00

7:00-5:00

7:00-6:00

12:00-8:00

leave home at 5:00 get back at 20:00

prize collecting tsp with time windows
Prize-collecting TSP with time windows
  • Definition:
    • Sites in a metric space (e.g. the plane).
    • A time-interval for each site (release-time, deadline).
    • Moving agent with speed in [0,1].
    • Goal: max #sites the agent visits on-time.
    • Extra: service-time per site.
known results scheduling with locations
Known results: scheduling with locations
  • Feasibility is NPC even for points on a line [Tsitsiklis92].
  • Polynomial algorithm for the case where all intervals are [0,t_i] (using dynamic programming) [Khanna]
  • Min makespan (completion time of last job):
    • 1.5-approx for points on a line with release times, processing times, and no deadlines [KNI98].
    • 2-approx for points on a line, no deadlines, multiple agents (vehicles) [KN01].
    • PTAS for trees with O(1) leaves, single & multiple agents [AS02].
our results
Our results
  • Logarithmic approximation for points on a line.
  • Optimal algorithm for points in any metric space, for special case: no round-trips within time windows.
  • Heuristic for any metric space. Achieves an approximation ratio that depends on a “density” measure.
points on a line

t

Points on a line
  • Speed in [0,1], so dist(A,B) = amount of time required to travel from A to B.
  • Construct the following 2D view of an instance:
  • speed = 1/slope

Slope in 900+[-450,+450]

Simplify tour: discrete speed

in {-1,0,1}.

X

point on a line cont

t-X

t+X

Point on a line (cont.)
  • Now we rotate the view by 450, and obtain a weakly x-monotone tour {00,450,900}.

2-D generalization of the “max monotone subsequence” problem

an 8 approx for unit intervals

1

1

1

1

1

1

2

1

1

1

1

1

1

An 8-approx for unit intervals
  • Construct a 1/2 -square grid.
  • Each interval intersects exactly 2 grid lines.
  • Direct the grid up & right.
  • Assign edge weights (#intersecting intervals).
  • Find a longest path on the obtained DAG.

An instance (slanted intervals in the plane).

analysis definitions

Cj

Ci

Analysis - definitions
  • horizontal slice is the region defined by two consecutive horizontal lines.
  • vertical slice is the region defined by two consecutive vertical lines.
  • Ci dominates Cj if:
    • Right(Ci)  Left(Cj) &&
    • Top (Ci)  Bott(Cj)
  • Domination ensures that concatenation of sub-tours is feasible.
analysis cont

Segment counted twice

Analysis (cont.)

THM: The longest path in the graph intersects no less than OPT/8 intervals.

  • Each interval intersects 2 grid-segments
  •  weight(path) : wrong by at most a factor of 2.
analysis cont11

Optimal path

Analysis (cont.)

“decompose” OPT into alternating horizontal and vertical blocks. (each block within a slice).

  • Sub-tours through red (blue) blocks can be concatenated.
  • If there is a grid-path that is 4-approx in each block, pick red or blue blocks. This gives an 8-approx.
analysis cont12

OPT in a block

Analysis (cont.)

Select either left-top path or bottom-right path in the DAG.

Every interval in block must intersect the perimeter

 OPT intersects at most 2 times more intervals than the better path.

 Error in weight of path is at most by a factor of 2.

Overall: 8-approximation

remarks
Remarks
  • For [1,2) intervals this is a 16-apx algorithm.
  • This can be extended to a 16log(I)-approx. alg. for arbitrary intervals, where I = Imax/Imin.
  • The size of the DAG is weakly polynomial. It becomes strongly poly if we consider only grid lines that intersect some interval.
an o log n approximation
An O(log n) approximation
  • If I = Imax/Imin is is super-poly, then O(log I)> O(log n).
  • We need a different approach to divide the intervals into “disjoint-sets”.
  • We use an interval tree for this partition.
recursive bisection
Recursive bisection

Claim: separating vertical line (at most half the intervals lie strictly on each side).

recursive bisection cont

Level 2

Level 2

2nd comb

Recursive bisection (cont.)
  • A comb defines subset of intervals that intersect exactly one comb-tooth.
  • bisect recursively  log(n) “combs”
  • comb Ci such that: Ci OPT contains at least OPT/log n intervals.

Level 1

o log n approximation
O(log(n)) Approximation
  • Partition the intervals into (log n) combs.
  • For each comb, 12-approximate an optimal tour.
  • O(log(n)) approximation.
approximation for comb
Approximation for comb
  • Construct a DAG.
  • Form a grid.
  • Find the longest path.
  • An interval crosses exactly 1 vertical line.
  • An interval can cross many horz lines (but a grid-path crosses at most 2).
approx ratio 12
Approx ratio = 12
  • Decompose OPT into alternating sub-tours:
    • horizontal sub-tours inside a slice
    • vertical sub-tours between two comb teeth
    • Note the slices are non-uniform, but the proof still holds.
no round trips within time windows
No round-trips within time windows

DEF:

  • for all pairs (vi,vj):

dist(vi,vj) + dist(vj,vi) > interval (vi).

  • Service time:

dist(vi,vj) + dist(vj,vi) + serv(vj) > interval(vi).

IDEA: can’t zig-zag between sites.

dynamic program for no round trips within time windows
Dynamic program for no round-trips within time windows

Intuition: examine two tours A,B such that:

  • Both visit k sites
  • Both end at site vi.
  • tour A ends at time tA.
  • tour B ends at time tB.
  • tA < tB
  •  A+best-aug(A)  B+best-aug(B)
  • Proof: aug(B) is also aug(A). Prize-collecting is additive because aug(B) cannot visit sites visited by A.
dynamic program for no round trips within time windows cont
Dynamic program for no round-trips within time windows (cont.)

The algorithm works in layers, where in each layer, it keeps a list of states. A state in layer i is a pair (v,t) which signifies: a path that ends in v at time t after visiting i sites.

  • Layer 0: (origin, t=0)
dynamic program for no round trips within time windows cont23
Dynamic program for no round-trips within time windows (cont.)
  • Layer i+1 (induction step): For each state (vi,t) in Layer i go from (vi ,t) to all vj.
    • Consider the state (vj,t+dist(vi,C)
    • After deadline? Don’t add to layer i+1.
    • On time? is it earlier than previous states that end in vj ? If so replace.
    • Before release time? Use release time instead of arrival time.
analysis of the dynamic program
Analysis of the dynamic program
  • Correctness: lexicographic order all optimal tours by considering vector of service times.

observation: algorithm computes an optimal tour that is minimal in this order.

Running time:

  • each layer has at most one interesting point per interval.
  • each point produces at most n candidates for next layers.
  • number of layers is at most n.

The running time is O(n3).

generalized no round trip
Generalized no-round trip
  • The density of an instance is:

() = maxuv {I(u) / (Luv + Lvu) }

    • Density bounds number of zig-zags.
    • The approximation ratio of the dynamic program is:  () +1.
    • This follows from the fact that between every two visits of the same site, at least 1/ () of its length passed.
  • Non-unit profits: the problem is knapsack hard, and an approximation scheme of (1+) is possible.
remarks26
Remarks
  • This algorithm works also for asymmetric distances.
  • It shows that difficulty is due to “close” intervals.
further research
Further research
  • Improve approximation ratio in 1-D.
  • Nothing known for 2-D.
