Highway Resurfacing Materials Cost Estimate Tool

1. Highway Resurfacing Materials Cost Estimate Tool Richard D. Bellows Spring 2005

2. Overview Project Overview Background: Current Method of Cost Estimating Advantages of GIS Limitations Visual Basic and ArcView 9 Example Future Development Conclusion Questions ?

3. Current Method of Cost Estimate of MaterialsTexas Department of TransportationKarnes City Area Office

4. Advantages of GIS The need to collect the geometry of the roadway sections is eliminated. Less labor intensive Ability to Customize to Fit Parameters Expanded for other Applications After the initial entree Does not take two people three days to collect data and enter it. You can adjust the results based on the budget or amount of materials. Can be expanded to include other highway applications such as guard rail, signs, culverts, bridges, base layers, etc. After the initial entree Does not take two people three days to collect data and enter it. You can adjust the results based on the budget or amount of materials. Can be expanded to include other highway applications such as guard rail, signs, culverts, bridges, base layers, etc.

5. Project Overview Road data with lengths Export I-37 Divide the line feature into 2 mile sections Buffer sections Calculate Areas Append

6. Road data with lengths

7. Export I-37

8. Limitations Initial undertaking Layers must be updated Current material costs

9. Visual Basic Editor

10. Create a button

11. Create a dialog box or form

12. Examples Cost Estimate HMA REF 56.920 – 70.933 Thickness = 5 in Cost Estimate Seal Coat REF 56.920 – 70.933 Grade 4 Rock

13. Future Developments Include other features of highway resurfacing Striping Pavement Markers

14. Conclusions The use of GIS as a cost estimating tool for highway resurfacing is very effective. Easily adjusted to fit constraining parameters It can be expanded for other applications

15. Questions ?
