Presentation Transcript
agenda
Agenda
  • Intelligent Optical Networks
    • Systems, topologies, capabilities
  • Intellegent Network Control
    • Technologies, standards, interoperability
networks for science
Networks for Science

Needs

Solutions

  • Very high bandwidth pipes
    • Scale: Campus to International
    • Diverse service types
  • Agility and Dynamism
    • Multi-site collaborative groups
    • Service endpoint agility
    • Rapid provisioning
  • Internetworking
    • Integrate with packet infrastructure
    • Support existing optical services
  • Wavelength Provisioning
    • Aggregate traffic onto wavelengths near the user
    • Transparently switch wavelengths at a broad scope
  • Unified Control Plane
    • Reuse existing IP technologies
    • Standardized methods
    • GMPLS
  • Standardized Data Plane
    • G.709, other standards
    • Incorporate external (“alien”) ITU-T grid wavelengths
optical systems
Optical Systems

RayExpress

eROADM

RayROADM

MD-ROADM

OADM

ROADM

Multi-degree ROADM

  • 40 channel DWDM
  • 8 channel CWDM
  • 640 km Optical reach with family of EDFAs
  • 1,000+ km with Raman
  • GMPLS enabled
  • Dynamically select passthrough or add/drop, per-wavelength
  • Embedded OPM, automatic per-wavelength equalization
  • All-optical, 40G-ready
  • GMPLS enabled
  • 4x4 DWDM switching
  • 40 channels per degree
  • Integrated pre/post-amps
  • All-optical, 40G-ready
  • GMPLS enabled
scalable wavelength switching

iWSS

Scalable Wavelength Switching
  • Single port 1x1x40 switch
    • MEMS or AWG technology
    • Block (add/drop), Pass
    • eROADM, RayROADM
  • Multi-port 1x5x40 switch
    • MEMS technology
    • Select waves from multiple ports
    • Stackable, up to 4x4 matrix
  • Monolithic 10x10x40 iWSS
    • MEMS technology
    • High density, low per-wave cost
digital wrapper multiplexing
Digital Wrapper Multiplexing

Digital Wrapper

Pointer

Transport integration

  • Standardized data plane
  • Single encapsulation format
  • Advanced capabilities
    • FEC
    • PMs
  • G.709 ITU-T standard

Adjustments for

Each OC48

Alignm

Client Layer Signal

Client Layer Signal

OPU1 OH

ODU1

STS48

(e.g. STM-16, ATM, GFP)

ODU1 OH

Performence

Monitors for

Each OC48

4x

Alignm

Alignm

Alignm

Client Layer Signal

OPU1 OH

OPU2 OH

Alignm

Client Layer Signal

OPU1 OH

ODU2

(e.g. STM-16)

ODU1 OH

Client Layer Signal

Client Layer Signal

OPU1 OH

(e.g. STM-16)

ODU1 OH

Client Layer Signal

ODU2 OH

OPU1 OH

(e.g. STM-16)

ODU1 OH

STS48

(e.g. STM-16, ATM, GFP)

ODU1 OH

  • Result:
    • Identical capabilities across diverse payloads
    • improved monitoring, robustness

OTU2

Alignm

Alignm

OH

Alignm

Alignm

Client Layer Signal

OTU2

OPU1 OH

OTU2

OPU2 OH

Alignm

Client Layer Signal

OPU1 OH

(e.g. STM-16)

ODU1 OH

OPU2 Payload

Client Layer Signal

Client Layer Signal

OPU1 OH

FEC

(e.g. STM-16)

ODU1 OH

Client Layer Signal

ODU2 OH

OPU1 OH

(e.g. STM-16)

ODU1 OH

STS48

(e.g. STM-16, ATM, GFP)

ODU1 OH

Performence

Monitors Top

Level 10G

Stream

Forward Error

Correction for

Top Level 10G

Stream

network topologies
Network Topologies

Ring

Configurable Ring

Ring Interconnect / Mesh

  • Selectable service endpoints
  • Diverse/mesh pathways
  • MD-ROADM
  • Fixed service endpoints
  • Ring pathways
  • OADM
  • Selectable service endpoints
  • Ring pathways
  • eROADM, RayROADM
optical standards
Optical Standards
  • Client Interfaces
      • Ethernet: 2xGbE, 8xGbE, 10G-WAN, 10G-LAN
      • SONET/SDH: 4xOC3/OC12, 1xOC48, 4xOC48, 1xOC192 (also STM equivalents)
      • ESCON: 1xESCON, 2xESCON, 12xESCON
      • FC/FICON: 1xFC, 2xFC, 1xFICON, 2xFICON
      • G.709: 1xOTU1, 1xOTU2
      • SFP/XFP pluggable optics
      • Optical/Section PMs, RMON
  • Transmission Interfaces
      • 2R Transparent, 3R Transparent, optional PMs
      • OTU1, OTU2, optional FEC
      • External Wavelength, integrated VOA control
      • 40 lambda ITU-T grid DWDM (1530 – 1560nm)
      • 8 lambda CWDM support
  • Certifications
      • NEBS
      • OSMINE
      • RoHS
gmpls
GMPLS
  • Superset of MPLS
    • Identical concepts, mechanisms, protocols
      • IP-based, reuse existing stable/tested/battle-hardened protocols
    • Expands the concept of a “label”
      • In MPLS, a label ties a packet to a flow
      • In GMPLS, labels can identify TDM streams (SONET/SDH), Wavelengths (DWDM), Fibers (OXCs), as well as packet flows
  • Unified control of diverse network technologies
    • One set of concepts to learn, tools to deploy
      • LSPs, labels, signaling, routing, path computation
    • Manage different types of flows using single set of tools
      • Same provisioning methods for IP and optical networks
    • Lessons learned from MPLS deployments
      • Bidirectional LSP setup, support for out-of-band communications, etc
tunnel lsp example
Labels distributed between specific end-points

Ingress initiates LSP

Data flow

28

92

15

35

47

Tunnel LSP: Example
  • Request propagated to egress
  • Egress responds with label
  • Response propagated upstream to ingress
controlled light path
Reuse of MPLS and IP Control

Ingress initiates light path setup

Data flow

λ5

λ2

λ8

λ2

λ2

Controlled Light Path
  • Request propagated to egress
  • Egress responds with lambda
  • Response propagated upstream to ingress
control plane standards
Control Plane Standards
  • Routing
      • RFC2328 (OSPF v2)
      • RFC3630 (OSPF-TE v2)
      • RFC4202 (GMPLS Routing)
      • RFC4203 (OSPF-GMPLS)
  • Signaling
      • RFC2205 (RSVP)
      • RFC3209 (RSVP-TE)
      • RFC3471 (GMPLS Signaling)
      • RFC3473 (RSVP-GMPLS)
  • In Progress
      • draft-ietf-ospf-ospfv3-traffic-06
      • draft-ietf-ccamp-rsvp-restart-ext-05
      • draft-ietf-ccamp-crankback-05
      • draft-ietf-ccamp-gmpls-segment-recovery-02
      • draft-ietf-ccamp-gmpls-recovery-e2e-signaling-03
      • draft-ietf-ccamp-gmpls-alarm-spec-03
      • draft-ietf-ccamp-gmpls-addressing-02

Mature, several interoperable implementations

subtended rings a to c
Subtended rings, A to C

A

B

E1

E2

R1

R2

E4

E3

C

D

provision a to c manual
Provision A to C, Manual

At A, execute:

  • Set SIM port service type or rate
  • Set SIM port customer name
  • Set destination SIM port
  • Enable SIM port
  • Set SIM protection
  • Set SIM preferred plane
  • If “red” XCVR is EAML, set bw
  • Enable “red” XCVR tx laser
  • If “green” XCVR is EAML, set bw
  • Enable “green” XCVR tx laser

At MR1, execute:

  • Connect A -> E1, passthru
  • Connect E1 -> A, passthru
  • Connect A -> E4, passthru
  • Connect E4 -> A, passthru
  • Equalize A -> E1
  • Equalize E1 -> A
  • Equalize A -> E4
  • Equalize E4 -> A

At MR2, execute:

  • Connect C -> E2, passthru
  • Connect E2 -> C, passthru
  • Connect C -> E3, passthru
  • Connect E3 -> C, passthru
  • Equalize C -> E2
  • Equalize E2 -> C
  • Equalize C -> E3
  • Equalize E3 -> C

At C, execute:

  • Set SIM port service type or rate
  • Set SIM port customer name
  • Set destination SIM port
  • Enable SIM port
  • Set SIM protection
  • Set SIM preferred plane
  • If “red” XCVR is EAML, set bw
  • Enable “red” XCVR tx laser
  • If “green” XCVR is EAML, set bw
  • Enable “green” XCVR tx laser
provision a to c control plane
Provision A to C, Control Plane
  • At A, execute:
    • Set destination IP address to C
    • Set destination SIM card
    • Set source SIM card
    • Select SIM card port
    • Set SIM port service type or rate
    • Set SIM port customer name
    • Set destination SIM port
    • Commit service
    • DONE!
interoperability isocore
Interoperability (ISOCORE)

Juniper

Navtel

Movaz

Movaz

Sycamore

Navtel

Sycamore

Tellabs

Tellabs

Avici

Avici

Completed 10/03

Report available to

ISOCORE members

Juniper

= OC48

= OC12

= GbE

interoperability unh
Interoperability (UNH)

Fast Ether as Control LINK

OC48 as TE-LINK

OC48 or others as TE-LINK

Lambda as TE-LINK

N*OC48 or OC-192? as TE-LINK

Juniper_1

Juniper_2

Movaz_2

Rayexpress

Cisco_A

Movaz_1

Rayexpress

Avici_B

Avici_A

Cisco_B

Alcatel_4

Alcatel_3

Sycamore_1

SN16000

Sycamore_2

SN16000

Completed 01/04

Report available

network applications
Addresses all applications spaces with a unified hardware platform and operations environment

Supports Pt-Pt, Ring, and Mesh Topologies

Cost optimized transponders and amplifiers for each application space

Offers leading edge technology, such as wavelength switching, integrated Raman, ROADM with integrated power monitoring, and GMPLS Control Plane

Network Applications

Customer Prem.

CWDM

8WL

0-80km

Metro Access

DWDM

40WL

0-100km

Metro IOF

DWDM

40WL

0-300km

Regional

DWDM

40 WL

0-600km

Short Long-Haul

DWDM

40WL

0-1000km

DWDM

DWDM

Metro Core / IOF

CWDM Access

slide19
