  1. Microsoft .NET ServicesA Closer Look Clemens Vasters Technical Lead Microsoft Corporation

  2. Agenda • What is a Service Bus? • Connectivity Challenges • Naming • Service Registry and Discovery • Messaging, Connectivity and Events

  3. Internet Service Bus Service Orchestration Federated Identity and Access Control Naming Service Registry Messaging Fabric Your Services Clients On-Premise ESB MS/3rd Party Services ESB Desktop, RIA, Web Desktop, RIA, & Web

  4. Connectivity Challenges • IPv4 Address Shortage • Dynamic IP address allocation • Network Address Translation (NAT) • Internet is pwn3d by the bad guys • Firewalls layered over firewalls over firewalls Network Address Translation Network Firewall Dynamic IP Machine Firewall ? Sender Receiver

  5. How Do People Deal With It? • Dynamic DNS • NAT Port Mappings / UPnP • Open Inbound Firewall Ports Brittle, Difficult, Insecure – and sometimes – Impractical Consequence: We see recurring patterns of workarounds Network Address Translation Network Firewall Dynamic IP Machine Firewall ? Sender Receiver

  6. Who needs it? • Any Instant Messaging/Communication App • Access Control, Relay, Direct Connect • Any Multiplayer Game • Access Control, Relay, Direct Connect • Any Home Media Integration System • Access Control, Relay, Direct Connect • Any Enterprise Integration System • Access Control, VPN/VAN

  7. Service Bus – Naming Federated Identity and Access Control Naming Service Registry Messaging Fabric

  8. Service Bus Naming • Federated, hierarchical, DNS-integrated, transport-neutral naming system Solution NameA Name1 Solution NameB Name2 Root Solution NameC Name3

  9. Anything wrong with DNS? • DNS has some practical constraints: • High update propagation latency • Increasing pollution by ISPs (“DNS assistance”) • Names hosts, not services • Limited write-access model (often out-of-band) • Service Bus Naming System • R/W access with access control via Registry • Updates reflected instantaneously • Names name endpoints, not machines

  10. Canonical Form of URI Projections scheme://naming-scope/name/name X A 1 Y B 2 Root Z C 3 URI ‘Host’: Naming Authority URI ‘Path’: Federated Name Structure

  11. Global Naming Structure (PDC) scheme://servicebus.windows.net/services/solution/name/… Required Prefix solution name SBWN services 2 Root 3

  12. Global Naming Structure (Post-PDC) scheme://solution.servicebus.windows.net/name/… Solution NameA Name1 Solution NameB Name2 Root Solution NameC Name3

  13. Service Bus – Service Registry Federated Identity and Access Control Naming Service Registry Messaging Fabric

  14. Service Registry • The service registry is registry for service endpoints, not a general purpose directory • Registry is layered over the naming system • Provides programmatic access to naming • Discover: Atom 1.0 feed hierarchy • Publish: Atom Publishing Protocol, WS-Transfer WS-Transfer Client Service Registry AtomPub Naming

  15. Registry Feed Structure • Accessing the root registry feed for solutions • http://servicebus.windows.net/services/solution/ • Root of a hierarchy of feeds solution svc WS-Transfer Client SBWN services Naming Root AtomPub solution svc

  16. Services in Registry Feeds • <?xml version="1.0" encoding="utf-8"?><feed xmlns="http://www.w3.org/2005/Atom"xmlns:wsa="http://www.w3.org/2005/08/addressing"> <title>Title</title> <link href="http://connect.biztalk.net/services/my/svc"rel="self"/> <id>urn:uuid:82a76c80-d498-12d5-b91C-0103839e0ef6</id> … <entry> <title>MyEndpoint</title> <link href="http://cbn/services/my/svc/ep1"/> <id>urn:uuid:1225c695-cfb8-4ebb-aaaa-80da344efa6a</id> <wsa:EndpointReference> <wsa:Address> http://servicebus.windows.net/services/my/svc/ep1 </wsa:Address> </wsa:EndpointReference> </entry> </feed>

  17. .NET Service Bus Registry demo

  18. Service Bus – Messaging Federated Identity and Access Control Naming Service Registry Messaging Fabric

  19. Service Bus - Messaging • Primary Programming Model: WCF • Family of Bindings for the Service Bus

  20. WCF Relay Bindings For WCF Pros • Works just like WCF: • Envelopes: SOAP 1.1, SOAP 1.2, None • All WS-* end-to-end security scenarios • Transport-level message path protection (SSL) • Reliable Messaging, Streaming • Full Extensibility Model • Web programming model (WebGet/-Invoke) • Metadata Exchange • Not supported: • (By Design) Atomic Transaction Flow • (By Design) Protocol-level transport authentication • (PDC Issue) WebScriptingBehavior JavaScript proxy • (PDC Issue) Direct Tcp Modes with RM or WS-* Sec.

  21. NetOnewayRelayBinding Service Bus sb://servicebus.windows.net/services/solution/a/b/ BackendNaming RoutingFabric Route Subscribe Frontend Nodes NLB TCP/SSL 808/828 TCP/SSL 828 outbound connect one-way net.tcp outbound connect bidi socket Msg Msg Sender Receiver NATFirewallDynamic IP

  22. NetEventRelayBinding Service Bus sb://servicebus.windows.net/services/solution/a/b/ BackendNaming RoutingFabric Route Subscribe Frontend Nodes TCP/SSL 808/828 TCP/SSL 828 TCP/SSL 828 outbound connect one-way net.tcp outbound connect bidi socket outbound connect bidi socket Msg Msg Msg Sender Receiver Receiver

  23. One-Way Messaging and Events demo

  24. NetTcpRelayBinding / Relayed Service Bus sb://servicebus.windows.net/services/solution/a/b/ BackendNaming RoutingFabric Oneway RendezvousCtrl Msg Frontend Nodes Ctrl 2 NLB 3 TCP/SSL 818 outbound socket rendezvous outbound socket connect 1 Socket-SocketForwarder Ctrl Sender Receiver 4

  25. NetTcpRelayBinding / Hybrid Service Bus sb://servicebus.windows.net/services/solution/a/b/ BackendNaming RoutingFabric Oneway RendezvousCtrl Msg Frontend Nodes TCP/SSL 818, 819 NAT Probing NAT Probing relayed connect relayed rendezvous upgrade Ctrl upgrade Sender Receiver NAT Traversal Connection

  26. TCP-based Connections demo

  27. [WS|Basic|Web]HttpRelayBinding Service Bus sb://servicebus.windows.net/services/solution/a/b/ BackendNaming RoutingFabric Oneway RendezvousCtrl Msg Frontend Nodes Ctrl 2 NLB 3 HTTP/S80/443 outbound socket rendezvous HTTPHTTPSrequest 1 HTTP-SocketForwarder Ctrl Sender Receiver 4

  28. HTTP Based Connections demo

  29. Service Bus – Access Control Integration Federated Identity and Access Control Naming Service Registry Messaging Fabric

  30. Relay Access Control Model - Listener 1 Access ControlSTS Acquire Access Token#Listen RST/RSTR 2 Pass Access Token with Subscription AcTk 3 Token Evaluated #Listen Token Header AcTk Service BusRelay Receiver

  31. Relay Access Control Model - Sender Access ControlSTS 1 RST/RSTR Acquire Access Token#Send AcTk #Send Service BusRelay Sender Receiver AcTk Token Header 3 Token Evaluated and Removed 2 4 Pass Access Token with Message Message Passed on to Receiver

  32. Integrated Access Control • Access Control Governed by Rules • Managed in the Access Control Service • Services must be authorized to listen in namespace • Evaluation of all claims in the cloud • No notion of “identity” in the relayed service • Service can turn off client access control • Local evaluation of end-to-end claims • Full control over authN/Z model (but less protection) • Clean composition w/ standard SOAP/HTTP model • WS-Security Header reserved for E2E Message Security • Transparent to HTTP-Header AuthN/AuthZ schemes

  33. .NET Access Control demo

  34. Notes on Security • We encourage you to hide your payloads • Use WS-Security to protect end-to-end path • You own all keys used to protect payloads • Transport security • SSL channels terminate in the Service Bus • Socket connections relayed on-machine • Oneway/Event relayed on backend fabric • What do we look at in the Service Bus? • SOAP: Action/wsa:Action, wsa:To, wsa:Action • HTTP: Method, URI • Access Tokens

  35. Service Bus – Workflow Integration Workflow Federated Identity and Access Control Naming Service Registry Messaging Fabric

  36. .NET Workflow Services demo

  37. Q & A

  38. Summary • Pervasive, Secure Connectivity for Services • Secure NAT Traversal, “DMZ in the sky” • WCF-Integrated Programming Model
