    1. Electrical Engineering Division Janet L. Barth Division Chief Code 560, B23, S120 (301) 286-5118 NASA Goddard Space Flight Center

    2. Mission of the Electrical Engineer Division Provide expert leadership in the design, development, and testing of flight electrical/electronic systems and associated technologies for GSFC and NASA missions. Electronics developed by 560 engineers are in orbit around the Earth, the Moon, and planets providing valuable data leading to exciting scientific discoveries and helping to pave the way for human exploration of our solar system. The types of missions supported include airborne, balloon, sounding rocket, and space fight. NASA Goddard Space Flight Center Electrical Engineering Division

    3. Organization – Electrical Engineering Division Chief: Janet L. Barth Associate Chief: George Jackson Associate Chief: Robert Lebair Chief Technologist: Wesley Powell Chief Architect: Richard Schnurr Chief Engineer: Steve Graham ST: Bernie Edwards ST: Henning Leidecker Staff Engineer: Mitch Davis CSO: Lynn Baker Parts, Packaging & Assembly Technologies Code 562 Kusum Sahu Instrument Electronics Development Code 564 David Sohl Communication Systems Code 567 Brian Gosselin Wallops Electrical Engineering Code 569 Daniel Mullinix Flight Data Systems & Radiation Effects Code 561 Kenneth Li Avionics & Electrical Systems Code 565 Beverly Settles Power Systems Code 563 Thomas Yi Flight Systems Integration & Test Code 568 Robert Kasa NASA Goddard Space Flight Center Electrical Engineering Division

    4. 561 - Flight Data Systems & Radiation Effects Design engineers test a board for the LRO command & data handling system. • command & data handling systems and networks • reconfigurable architectures • data storage, recorders, processors • advanced technology • radiation environment modeling • radiation effects analysis & testing NASA Goddard Space Flight Center Electrical Engineering Division

    5. 562 - Parts, Packaging & Assembly Technologies • flight EEE parts engineering • advanced packaging technology • flight packaging & assembly • failure analysis Component engineer performs Destructive Parts Analysis (DPA) analysis using the Hirox microscope system. NASA Goddard Space Flight Center Electrical Engineering Division

    6. 563 - Power Systems • instrument & spacecraft power processing electronics • photovoltaic energy conversion • electrochemical energy storage • power management & distribution Design and test engineers evaluatecircuits for the MMS Power Switching Electronics system. NASA Goddard Space Flight Center Electrical Engineering Division

    7. 564 – Instrument Electronics Development • detector interfaces • detector environmental control • signal & science data processing • ASIC development • instrument & spacecraft interfaces • instrument control & housekeeping Lead engineer performs checkout of instrument electronics. NASA Goddard Space Flight Center Electrical Engineering Division

    8. 565 – Avionics & Electrical Systems • advanced electrical systems architectures • electrical interfaces • grounding • EMI/EMC • electrical ground support equipment • simulators • space & ground data networks • flight & ground support equipment harnessing Electrical systems engineers run acceptance tests on a ground support system. NASA Goddard Space Flight Center Electrical Engineering Division

    9. 567 - Communication Systems Communications systems engineers review results of LRO high gain antenna system testing. NASA Goddard Space Flight Center Electrical Engineering Division • spacecraft communication subsystems • NASA near-earth space network and ground network communications • high data-rate Ka-band space-flight hardware • international standards for coding, modulation, and data compression • flight microwave remote sensing instruments

    10. 568 - Flight Systems Integration & Test • integration of flight components & subsystems into observatory spacecraft & instrument systems • environmental and functional testing of observatory • spacecraft & instrument systems I&T engineers perform safe-to-mate checks of the flight harness during integration of the propulsion and deployment electronics on LRO. NASA Goddard Space Flight Center Electrical Engineering Division

    11. 569 - Wallops Electrical Engineering • electrical/electronics systems for ballooncraft • unmanned aerial vehicles (UAVs) • sounding rockets & suborbital payloads • radar/tracking • telemetry processing • range safety • ground systems Launch of the CREAM balloon-borne science payload with Wallops command data module, integration and testing, and flight operations. NASA Goddard Space Flight Center Electrical Engineering Division

    12. GFSC Near Term Missions MAVEN JPL/MSL SAM NextGen TDRS JWST GPM JDEM LDCM ICESAT-II LADEE NPP Suborbital MMS Glory GEMS 12 NASA Goddard Space Flight Center Electrical Engineering Division

    13. GSFC Recent Missions Glory 11/10 Fermi (GLAST) 6/08 LRO 6/09 SDO (LWS) 2/10 HST SM-4 5/09 2009 2010 GOES 15 (GOES-P) 3/10 GOES-14 (GOES-O) 6/09 NOAA N’ 2/09 TacSat-3 5/09 MLAS 7/09 13 Launched Successfully NASA Goddard Space Flight Center Electrical Engineering Division
