Vertical Autoclave 29 L

Labnic Vertical Autoclave is a top-loading unit with a maximum working temperature of 135 u00b0C and a design temperature of 139 u00b0C. It operates at pressures of 0.22 MPa and 0.25 MPa, with a timer range of 4 to 120 minutes. It features an automatic cold air exhaust, over-temperature protection and reliable performance.u00a0

susanlabnic
Download Presentation

Vertical Autoclave 29 L

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Vertical Autoclave www.labnic.com | info@labnic.com

  2. Overview Vertical Autoclave LBN-VA15i1s a top loading vertical autoclave that provides high quality, repeatable performance and accountability for a wide range of applications. It has an easy to use control panel and a chamber made of stainless steel. It provides workable capacity of 29 liters operating under 135/139 C temperature range. The LCDdisplay, which is both durable and high in resolution, provides an intuitive operation with real-time display of set and actual temperatures. Specifications : Volume 29 Liters 135 / 139 C Maximum Working / Design Temperature Maximum Working / Design Pressure 0.22 / 0.25 MPa Timer Range 4 120 min Basket Dimension x280340 mm Number of Baskets 1 Power 2.3 KW Power Supply 220V–10%, 50 Hz Internal Dimension 300485 mm Housing Dimension (WDH) 445445900 mm Packing Size 5705701060 mm Net Weight 54 Kg Gross Weight 64 Kg

  3. Features : Made of SUS304 stainless steel material Hand-wheel type quick open door Self-expanding type sealing ring Exhaust cold air automatically Microcomputer intelligent control Self-exhaust during over pressure Pressure safety interlock Over temperature protection Alarm indication in case of sterilization ends or fault indication Equipped with G1/2A internal thread samples test hole Applications : It is highly used in research and development centers, educational institutes, laboratories and different quality assurance facilities for material tests, culture media preparationand sterilization of various materials. Labnic Scientific USA

  4. Email: info@labnic.com | Website: www.labnic.com
