  1. WELCOME TO sunmafiber.com E: info@sunmafiber.com M: +86-27 8720 8018 W: www.sunmafiber.com

  2. Between four hundred and one hundred degrees of magnification can be achieved by Fiber optic microscopes, and on the needs of the user, the level of magnification will depend. because of their specialized nature, Fiber optic microscopes are not available from the same sources, which provide digital or regular microscopes, and by companies, fiber end face microscope is usually bought instead of individuals.

  3. Fiber Optic Microscopes Types In several varieties, Fiber optic microscopes come; similar to those on compound microscopes, the simplest of them have eyepieces through which their users look. Its own video screen is there in a more sophisticated model of fiber optic microscope; for those who on a regular basis use a fiber optic microscope, this is the preferred technology.

  4. To provide images of the end faces of fiber optic connector ferrules, a fiber end face probe is used so that with their transmission performance, any problems can be seen. Its operator can detect any scratches, debris, or dirt with the microscope, which with the transmission, may be interfering. Operating for up to forty hours on three or four AAA batteries, most fiber optic microscopes are handheld units.

  5. Fiber Optic Microscopes Traits To secure the fiber optic cables, You should look for models including connectors if you're thinking about buying a fiber optic microscope; otherwise, to hold the microscope still with one hand and hold the cable steady with the other, you'll find yourself having to struggle. as compared to those without cable holders, the microscopes with them will cost more than but as compared to make up for the difference in cost, the time you'll save inspecting the cables will more. You can also buy fused biconical taper machine online.

  6. Wuhan Sunma Technology Co,.LTD. Address: 88, Mingyuan Road, Optic Valley, Hongshan, Wuhan 430074, Hubei, China Tel : +86-27 8720 8018, +86-27 5177 9650 Fax: +86-27 5177 8865 E-mail: info@sunmafiber.com Website: http://www.sunmafiber.com/
