cuda lecture 1 introduction to massively parallel computing

CUDA Lecture 1Introduction to Massively Parallel Computing

Prepared 6/4/2011 by T. O’Neil for 3460:677, Fall 2011, The University of Akron.

cpus and gpus
CPUs and GPUs
  • A quiet revolution and potential buildup
    • Computation: TFLOPs vs. 100 GFLOPs
    • CPU in every PC – massive volume and potential impact

T12

GT200

G80

3GHz Xeon Quad

G70

Westmere

3GHz Core2 Duo

NV30

NV40

Introduction to Massively Parallel Processing – Slide 2

topic 1 the demand for computational speed
Topic 1: The Demand for Computational Speed

Introduction to Massively Parallel Processing – Slide 2

why faster computers
Why Faster Computers?
  • Solve computation-intensive problems faster
    • Make infeasible problems feasible
    • Reduce design time
  • Solve larger problems in the same amount of time
    • Improve an answer’s precision
    • Reduce design time
  • Gain competitive advantage

Introduction to Massively Parallel Processing – Slide 4

why faster computers1
Why Faster Computers?
  • Another factor: modern scientific method

Nature

Observation

Numerical

Simulation

Physical

Experimentation

Theory

Introduction to Massively Parallel Processing – Slide 5

the need for speed
The Need for Speed
  • A growing number of applications in science, engineering, business and medicine are requiringcomputing speeds that cannot be achieved by the current conventional computers because
    • Calculations too computationally intensive
    • Too complicated to model
    • Too hard, expensive, slow or dangerous for the laboratory.
  • Parallel processing is an approach which helps to make these computations feasible.

Introduction to Massively Parallel Processing – Slide 6

the need for speed1
The Need for Speed
  • One example: grand challenge problems that cannot be solved in a reasonable amount of time with today’s computers.
    • Modeling large DNA structures
    • Global weather forecasting
    • Modeling motion of astronomical bodies
  • Another example: real-timeapplications which have time constrains.
    • If data are not processed during some time the result become meaningless.

Introduction to Massively Parallel Processing – Slide 7

one example weather forecasting
One Example: Weather Forecasting
  • Atmosphere modeled by dividing it into 3-dimensional cells. Calculations of each cell repeated many times to model passage of time.
  • For example
    • Suppose whole global atmosphere divided into cells of size 1 mile  1 mile  1 mile to a height of 10 miles (10 cells high) – about 5108 cells.
    • If each calculation requires 200 floating point operations, 1011 floating point operations necessary in one time step.

Introduction to Massively Parallel Processing – Slide 8

one example weather forecasting1
One Example: Weather Forecasting
  • Example continued
    • To forecast the weather over 10 days using 10-minute intervals, a computer operating at 100 megaflops (108 floating point operations per second) would take 107 seconds or over 100 days.
    • To perform the calculation in 10 minutes would require a computer operating at 1.7 teraflops (1.71012 floating point operations per second).

Introduction to Massively Parallel Processing – Slide 9

concurrent computing
Concurrent Computing
  • Two main types
    • Parallel computing: Using a computer with more than one processor to solve a problem.
    • Distributed computing: Using more than one computer to solve a problem.
  • Motives
    • Usually faster computation
      • Very simple idea – that n computers operating simultaneously can achieve the result n times faster
      • It will not be n times faster for various reasons.
    • Other motives include: fault tolerance, larger amount of memory available, …

Introduction to Massively Parallel Processing – Slide 10

parallel programming no new concept
Parallel Programming No New Concept

“... There is therefore nothing new in the idea of parallel programming, but its application to computers. The author cannot believe that there will be any insuperable difficulty in extending it to computers. It is not to be expected that the necessary programming techniques will be worked out overnight. Much experimenting remains to be done. After all, the techniques that are commonly used in programming today were only won at considerable toil several years ago. In fact the advent of parallel programming may do something to revive the pioneering spirit in programming which seems at the present to be degenerating into a rather dull and routine occupation …”

- S. Gill, “Parallel Programming”, The Computer Journal, April 1958

Introduction to Massively Parallel Processing – Slide 11

the problems of parallel programs
The Problems of Parallel Programs
  • Applications are typically written from scratch (or manually adapted from a sequential program) assuming a simple model, in a high-level language (i.e. C) with explicit parallel computing primitives.
  • Which means
    • Components difficult to reuse so similar components coded again and again
    • Code difficult to develop, maintain or debug
    • Not really developing a long-term software solution

Introduction to Massively Parallel Processing – Slide 12

another complication memory
Another Complication: Memory

Processors

Registers

Highest level

Small, fast, expensive

Memory level 1

Memory level 2

Memory level 3

Lowest level

Large, slow, cheap

Main Memory

Introduction to Massively Parallel Processing – Slide 13

review of the memory hierarchy
Review of the Memory Hierarchy
  • Execution speed relies on exploiting data locality
    • temporal locality: a data item just accessed is likely to be used again in the near future, so keep it in the cache
    • spatial locality: neighboring data is also likely to be used soon, so load them into the cache at the same time using a ‘wide’ bus (like a multi-lane motorway)
    • from a programmer point of view, all handled automatically – good for simplicity but maybe not for best performance

Introduction to Massively Parallel Processing – Slide 14

the problems of the memory hierarchy
The Problems of the Memory Hierarchy
  • Useful work (i.e. floating point ops) can only be done at the top of the hierarchy.
    • So data stored lower must be transferred to the registers before we can work on it.
      • Possibly displacing other data already there.
    • This transfer among levels is slow.
      • This then becomes the bottleneck in most computations.
      • Spend more time moving data than doing useful work.
  • The result: speed depends to a large extent on problem size.

Introduction to Massively Parallel Processing – Slide 15

the problems of the memory hierarchy1
The Problems of the Memory Hierarchy
  • Good algorithm design then requires
    • Keeping active data at the top of the hierarchy as long as possible.
    • Minimizing movement between levels.
  • Need enough work to do at the top of the hierarchy to mask the transfer time at the lower levels.
    • The more processors you have to work with, the larger the problem has to be to accomplish this.

Introduction to Massively Parallel Processing – Slide 16

topic 2 cpu architecture
Topic 2: CPU Architecture

Introduction to Massively Parallel Processing – Slide 17

starting point von neumann processor
Starting Point: von Neumann Processor
  • Each cycle, CPU takes data from registers, does an operation, and puts the result back
  • Load/store operations (memory registers) also take one cycle
  • CPU can do different operations each cycle
  • Output of one operation can be input to next
  • CPUs haven’t been this simple for a long time!

Introduction to Massively Parallel Processing – Slide 18

why moore s law
Why? Moore’s Law

“The complexity for minimum component costs has increased at a rate of roughly a factor of two per year... Certainly over the short term this rate can be expected to continue, if not to increase. Over the longer term, the rate of increase is a bit more uncertain, although there is no reason to believe it will not remain nearly constant for at least 10 years. That means by 1975, the number of components per integrated circuit for minimum cost will be 65,000. I believe that such a large circuit can be built on a single wafer.”

- Gordon E. Moore, co-founder, Intel

Electronics Magazine, 4/19/1965

Photo credit: Wikipedia

Introduction to Massively Parallel Processing – Slide 19

moore s law
Moore’s Law
  • Translation: The number of transistors on an integrated circuit doubles every 1½ - 2 years.

Data credit: Wikipedia

Introduction to Massively Parallel Processing – Slide 20

moore s law1
Moore’s Law
  • As the chip size (amount of circuitry) continues to double every 18-24 months, the speed of a basic microprocessor also doubles over that time frame.
  • This happens because, as we develop tricks, they are built into the newest generation of CPUs by the manufacturers.

Introduction to Massively Parallel Processing – Slide 21

so what to do with all the extra transistors
So What To Do With All The Extra Transistors
  • Instruction-level parallelism (ILP)
    • Out-of-order execution, speculation, …
    • Vanishing opportunities in power-constrained world
  • Data-level parallelism
    • Vector units, SIMD execution, …
    • Increasing opportunities; SSE, AVX, Cell SPE, Clearspeed, GPU, …
  • Thread-level parallelism
    • Increasing opportunities; multithreading, multicore, …
    • Intel Core2, AMD Phenom, Sun Niagara, STI Cell, NVIDIA Fermi, …

Introduction to Massively Parallel Processing – Slide 22

modern processor superscalar
Modern Processor: Superscalar
  • Most processors have multiple pipelines for different tasks and can start a number of different operations each cycle.
  • For example consider the Intel core architecture.

Introduction to Massively Parallel Processing – Slide 23

modern processor superscalar1
Modern Processor: Superscalar
  • Each core in an Intel Core 2 Duo chip has
    • 14 stage pipeline
    • 3 integer units (ALU)
    • 1 floating-point addition unit (FPU)
    • 1 floating-point multiplication unit (FPU)
      • FP division is very slow
    • 2 load/store units
    • In principle capable of producing 3 integer and 2 FP results per cycle

Introduction to Massively Parallel Processing – Slide 24

modern processor superscalar2
Modern Processor: Superscalar
  • Technical challenges
    • Compiler to extract best performance, reordering instructions if necessary
    • Out-of-order CPU execution to avoid delays waiting for read/write or earlier operations
    • Branch prediction to minimize delays due to conditional branching (loops, if-then-else)
    • Memory hierarchy to deliver data to registers fast enough to feed the processor
  • These all limit the number of pipelines that can be used and increase the chip complexity
    • 90% of Intel chip devoted to control and data

Introduction to Massively Parallel Processing – Slide 25

tradeoff performance vs power
Tradeoff: Performance vs. Power

(courtesy Mark Horowitz and Kevin Skadron)

Power

Performance

Introduction to Massively Parallel Processing – Slide 26

current trends
Current Trends
  • CPU clock stuck at about 3 GHz since 2006 due to problems with power consumption (up to 130W per chip)
  • Chip circuitry still doubling every 18-24 months
    • More on-chip memory and memory management units (MMUs)
    • Specialized hardware (e.g. multimedia, encryption)
    • Multi-core (multiple CPUs on one chip)
  • Thus peak performance of chip still doubling every 18-24 months

Introduction to Massively Parallel Processing – Slide 27

a generic multicore chip
A Generic Multicore Chip
  • Handful of processors each supporting ~1 hardware thread
  • On-chip memory near processors (cache, RAM or both)
  • Shared global memory space (external DRAM)

Global Memory

Processor

Memory

Processor

Memory

Introduction to Massively Parallel Processing – Slide 28

a generic manycore chip
A Generic Manycore Chip
  • Many processors each supporting many hardware threads
  • On-chip memory near processors (cache, RAM or both)
  • Shared global memory space (external DRAM)

Global Memory

Processor

Memory

Processor

Memory

• • •

Introduction to Massively Parallel Processing – Slide 29

example intel nehalem 4 core processor
Example: Intel Nehalem 4-core processor
  • Four 3.33 GHz cores, each of which can run 2 threads
  • Integrated MMU

Introduction to Massively Parallel Processing – Slide 30

so the days of serial performance scaling are over
So The Days of Serial Performance Scaling are Over
  • Cannot continue to scale processor frequencies
    • No 10 GHz chips
  • Cannot continue to increase power consumption
    • Can’t melt chips
  • Can continue to increase transistor density
    • As per Moore’s Law

Introduction to Massively Parallel Processing – Slide 31

future applications reflect a concurrent world
Future Applications Reflect a Concurrent World
  • Exciting applications in future mass computing market have been traditionally considered “supercomputing applications”
    • Molecular dynamic simulation, video and audio coding and manipulation, 3D imaging and visualization, consumer game physics, virtual reality products, …
    • These “super apps” represent and model physical, concurrent world
  • Various granularities of parallelism exist, but…
    • Programming model must not hinder parallel implementation
    • Data delivery needs careful management

Introduction to Massively Parallel Processing – Slide 32

the new moore s law
The “New” Moore’s Law
  • Computers no longer get faster, just wider
  • You must rethink your algorithms to be parallel!
  • Data-parallel computing is most scalable solution
    • Otherwise: refactor code for 2 cores, 4 cores, 8 cores, 16 cores, …
    • You will always have more data than cores – build the computation around the data

Introduction to Massively Parallel Processing – Slide 33

stretching traditional architectures
Stretching Traditional Architectures
  • Traditional parallel architectures cover some super apps
    • DSP, GPU, network and scientific applications, …
  • The game is to grow mainstream architectures “out” or domain-specific architectures “in”
    • CUDA is the latter

Introduction to Massively Parallel Processing – Slide 34

topic 3 graphics processing units gpus
Topic 3: Graphics Processing Units (GPUs)

Introduction to Massively Parallel Processing – Slide 35

gpus the big development
GPUs: The Big Development
  • Massive economies of scale
  • Massively parallel

Introduction to Massively Parallel Processing – Slide 36

gpus the big development1
GPUs: The Big Development
  • Produced in vast numbers for computer graphics
  • Increasingly being used for
    • Computer game “physics”
    • Video (e.g. HD video decoding)
    • Audio (e.g. MP3 encoding)
    • Multimedia (e.g. Adobe software)
    • Computational finance
    • Oil and gas
    • Medical imaging
    • Computational science

Introduction to Massively Parallel Processing – Slide 37

gpus the big development2
GPUs: The Big Development
  • The GPU sits on a PCIe graphics card inside a standard PC/server with one or two multicore CPUs

Introduction to Massively Parallel Processing – Slide 38

gpus the big development3
GPUs: The Big Development
  • Up to 448 cores on a single chip
  • Simplified logic (no out-of-order execution, no branch prediction) means much more of the chip is devoted to computation
  • Arranged as multiple units with each unit being effectively a vector unit, all cores doing the same thing at the same time
  • Very high bandwidth (up to 140GB/s) to graphics memory (up to 4GB)
  • Not general purpose – for parallel applications like graphics and Monte Carlo simulations
  • Can also build big clusters out of GPUs

Introduction to Massively Parallel Processing – Slide 39

gpus the big development4
GPUs: The Big Development
  • Four major vendors:
    • NVIDIA
    • AMD: bought ATI several years ago
    • IBM: co-developed Cell processor with Sony and Toshiba for Sony Playstation, but now dropped it for high-performance computing
    • Intel: was developing “Larrabee” chip as GPU, but now aimed for high-performance computing

Introduction to Massively Parallel Processing – Slide 40

cpus and gpus1
CPUs and GPUs
  • A quiet revolution and potential buildup
    • Computation: TFLOPs vs. 100 GFLOPs
    • CPU in every PC – massive volume and potential impact

T12

GT200

G80

3GHz Xeon Quad

G70

Westmere

3GHz Core2 Duo

NV30

NV40

Introduction to Massively Parallel Processing – Slide 41

cpus and gpus2
CPUs and GPUs
  • A quiet revolution and potential buildup
    • Bandwidth: ~10x
    • CPU in every PC – massive volume and potential impact

T12

GT200

G80

G70

3GHz Xeon Quad

NV40

3GHz Core2 Duo

Westmere

NV30

Introduction to Massively Parallel Processing – Slide 42

gpu evolution
GPU Evolution
  • High throughput computation
    • GeForce GTX 280: 933 GFLOPs/sec
  • High bandwidth memory
    • GeForce GTX 280: 140 GB/sec
  • High availability to all
    • 180M+ CUDA-capable GPUs in the wild

Introduction to Massively Parallel Processing – Slide 43

gpu evolution1
GPU Evolution

“Fermi”3B xtors

GeForce 8800

681M xtors

GeForce FX

125M xtors

GeForce 3

60M xtors

GeForce® 256

23M xtors

RIVA 128

3M xtors

1995

2000

2005

2010

Introduction to Massively Parallel Processing – Slide 44

lessons from the graphics pipeline
Lessons from the Graphics Pipeline
  • Throughput is paramount
    • Must paint every pixel within frame time
    • Scalability
  • Create, run and retire lots of threads very rapidly
    • Measured 14.8 Gthreads/sec on increment() kernel
  • Use multithreading to hide latency
    • One stalled thread is o.k. if 100 are ready to run

Introduction to Massively Parallel Processing – Slide 45

why is this different from a cpu
Why is this different from a CPU?
  • Different goals produce different designs
    • GPU assumes work load is highly parallel
    • CPU must be good at everything, parallel or not
  • CPU: minimize latency experienced by one thread
    • Big on-chip caches, sophisticated control logic
  • GPU: maximize throughput of all thread
    • Number of threads in flight limited by resources  lots of resources (registers, bandwidth, etc.)
    • Multithreading can hide latency  skip the big caches
    • Share control logic across many threads

Introduction to Massively Parallel Processing – Slide 46

nvidia gpu architecture

Texture

Texture

Texture

Texture

Texture

Texture

Texture

Texture

Texture

Host

Input Assembler

Thread Execution Manager

Parallel DataCache

Parallel DataCache

Parallel DataCache

Parallel DataCache

Parallel DataCache

Parallel DataCache

Parallel DataCache

Parallel DataCache

Load/store

Load/store

Load/store

Load/store

Load/store

Load/store

Global Memory

NVIDIA GPU Architecture
  • GeForce 8800 (2007)

Introduction to Massively Parallel Processing – Slide 47

g80 characteristics
G80 Characteristics
  • 16 highly threaded streaming multiprocessors (SMs)
  • > 128 floating point units (FPUs)
  • 367 GFLOPs peak performance (25-50 times that of current high-end microprocessors)
    • 265 GFLOPs sustained for applications such as visual molecular dynamics (VMD)
  • 768 MB DRAM
  • 86.4 GB/sec memory bandwidth
  • 4 GB/sec bandwidth to CPU

Introduction to Massively Parallel Processing – Slide 48

g80 characteristics1
G80 Characteristics
  • Massively parallel, 128 cores, 90 watts
  • Massively threaded, sustains 1000s of threads per application
  • 30-100 times speedup over high-end microprocessors on scientific and media applications
    • Medical imaging, molecular dynamics, …

Introduction to Massively Parallel Processing – Slide 49

nvidia gpu architecture1
NVIDIA GPU Architecture
  • Fermi GF100 (2010)
    • ~ 1.5 TFLOPs (single precision), ~800 GFLOPs (double precision)
    • 230 GB/sec DRAM bandwidth

Introduction to Massively Parallel Processing – Slide 50

streaming multiprocessors
Streaming Multiprocessors

Introduction to Massively Parallel Processing – Slide 51

streaming multiprocessors sms
Streaming Multiprocessors (SMs)
  • 32 CUDA cores per SM (512 total)
  • 8x peak FP64 performance
    • 50% of peak FP32 performance
  • Direct load/store to memory
    • Usual linear sequence of bytes
    • High bandwidth (hundreds of GB/sec)
  • 64K of fast, on-chip RAM
    • Software or hardware managed
    • Shared amongst CUDA cores
    • Enables thread communication

Introduction to Massively Parallel Processing – Slide 52

key architectural ideas
Key Architectural Ideas
  • SIMT (Single Instruction Multiple Thread) execution
    • Threads run in groups of 32 called warps
      • Minimum of 32 threads all doing the same thing at (almost) the same time
    • Threads in a warp share instruction unit (IU)
      • All cores execute the same instructions simultaneously, but with different data
      • Similar to vector computing on CRAY supercomputers
    • Hardware automatically handles divergence
    • Natural for graphics processing and much scientific computing; also a natural choice for many-core chips to simplify each core

Introduction to Massively Parallel Processing – Slide 53

key architectural ideas1
Key Architectural Ideas
  • Hardware multithreading
    • Hardware resource allocation and thread scheduling
    • Hardware relies on threads to hide latency
  • Threads have all resources needed to run
    • Any warp not waiting for something can run
    • Context switching is (basically) free

Introduction to Massively Parallel Processing – Slide 54

lessons from the graphics pipeline1
Lessons from the Graphics Pipeline
  • Lots of active threads is the key to high performance:
    • no “context switching”; each thread has its own registers, which limits the number of active threads
    • threads on each SM execute in warps – execution alternates between “active” warps, with warps becoming temporarily “inactive” when waiting for data
    • for each thread, one operation completes long before the next starts – avoids the complexity of pipeline overlaps which can limit the performance of modern processors
    • memory access from device memory has a delay of 400-600 cycles; with 40 threads this is equivalent to 10-15 operations, so hopefully there’s enough computation to hide the latency

Introduction to Massively Parallel Processing – Slide 55

chip comparison
Chip Comparison
  • Intel Core 2 / Xeon / i7
    • 4-6 MIMD (Multiple Instruction / Multiple Data) cores
      • each core operates independently
      • each can be working with a different code, performing different operations with entirely different data
    • few registers, multilevel caches
    • 10-30 GB/s bandwidth to main memory

Introduction to Massively Parallel Processing – Slide 56

chip comparison1
Chip Comparison
  • NVIDIA GTX280:
    • 240 cores, arranged as 30 units each with 8 SIMD (Single Instruction / Multiple Data) cores
      • all cores executing the same instruction at the same time, but working on different data
      • only one instruction de-coder needed to control all cores
      • functions like a vector unit
    • lots of registers, almost no cache
    • 5 GB/s bandwidth to host processor (PCIe x16 gen 2)
    • 140 GB/s bandwidth to graphics memory

Introduction to Massively Parallel Processing – Slide 57

chip comparison2
Chip Comparison
  • One issue with SIMD / vector execution: what happens with if-then-else branches?
    • Standard vector treatment: execute both branches but only store the results for the correct branch.
    • NVIDIA treatment: works with warps of length 32. If a particular warp only goes one way, then that is all that is executed.

Introduction to Massively Parallel Processing – Slide 58

chip comparison3
Chip Comparison
  • How do NVIDIA GPUs deal with same architectural challenges as CPUs?
    • Very heavily multi-threaded, with at least 8 threads per core:
      • Solves pipeline problem, because output of one calculation can be used an input for next calculation for same thread
      • Switch from one set of threads to another when waiting for data from graphics memory

Introduction to Massively Parallel Processing – Slide 59

topic 4 compute unified device architecture cuda
Topic 4: Compute Unified Device Architecture (CUDA)

Introduction to Massively Parallel Processing – Slide 60

enter cuda
Enter CUDA
  • Scalable programming model
  • Minimal extensions to familiar C/C++ environment
  • Heterogeneous serial-parallel computing

Introduction to Massively Parallel Processing – Slide 61

motivation

17X

45X

100X

13–457x

35X

110-240X

Motivation

Introduction to Massively Parallel Processing – Slide 62

gpu programming
GPU Programming
  • Big breakthrough in GPU computing has been NVIDIA’s development of CUDA programming environment
    • Initially driven by needs of computer games developers
    • Now being driven by new markets (e.g. HD video decoding)
    • C plus some extensions and some C++ features (e.g. templates)

Introduction to Massively Parallel Processing – Slide 63

gpu programming1
GPU Programming
  • Host code runs on CPU, CUDA code runs on GPU
  • Explicit movement of data across the PCIe connection
  • Very straightforward for Monte Carlo applications, once you have a random number generator
  • Harder for finite difference applications

Introduction to Massively Parallel Processing – Slide 64

software view
Software View
  • At the top level, we have a master process which runs on the CPU and performs the following steps:
    • initialize card
    • allocate memory in host and on device
    • repeat as needed
      • copy data from host to device memory
      • launch multiple copies of execution “kernel” on device
      • copy data from device memory to host
    • de-allocate all memory and terminate

Introduction to Massively Parallel Processing – Slide 65

software view1
Software View
  • At a lower level, within the GPU:
    • each copy of the execution kernel executes on an SM
    • if the number of copies exceeds the number of SMs, then more than one will run at a time on each SM if there are enough registers and shared memory, and the others will wait in a queue and execute later
    • all threads within one copy can access local shared memory but can’t see what the other copies are doing (even if they are on the same SM)
    • there are no guarantees on the order in which the copies will execute

Introduction to Massively Parallel Processing – Slide 66

cuda scalable parallel programming
CUDA: Scalable Parallel Programming
  • Augment C/C++ with minimalist abstractions
    • Let programmers focus on parallel algorithms, not mechanics of parallel programming language
  • Provide straightforward mapping onto hardware
    • Good fit to GPU architecture
    • Maps well to multi-core CPUs too
  • Scale to 100s of cores and 10000s of parallel threads
    • GPU threads are lightweight – create/switch is free
    • GPU needs 1000s of threads for full utilization

Introduction to Massively Parallel Processing – Slide 67

key abstractions in cuda
Key Abstractions in CUDA
  • Hierarchy of concurrent threads
  • Lightweight synchronization primitives
  • Shared memory model for cooperating threads

Introduction to Massively Parallel Processing – Slide 68

hierarchy of concurrent threads

Thread t

Block b

t0 t1 … tB

Hierarchy of Concurrent Threads
  • Parallel kernels composed of many threads
    • All threads execute the same sequential program
  • Threads are grouped into thread blocks
    • Threads in the same block can cooperate
  • Threads/blocks have unique IDs

Introduction to Massively Parallel Processing – Slide 69

cuda model of parallelism
CUDA Model of Parallelism
  • CUDA virtualizes the physical hardware
    • Thread is a virtualized scalar processor: registers, PC, state
    • Block is a virtualized multiprocessor: threads, shared memory
  • Scheduled onto physical hardware without pre-emption
    • Threads/blocks launch and run to completion
    • Blocks should be independent

Introduction to Massively Parallel Processing – Slide 70

cuda model of parallelism1
CUDA Model of Parallelism

Block

Memory

Block

Memory

Global Memory

• • •

Introduction to Massively Parallel Processing – Slide 71

not a flat multiprocessor
Not a Flat Multiprocessor
  • Cf. PRAM (Parallel Random Access Machine) model
  • Global synchronization isn’t cheap
  • Global memory access times are expensive

Processors

Global Memory

Introduction to Massively Parallel Processing – Slide 72

not distributed processors
Not Distributed Processors
  • Cf. BSP (Bulk Synchronous Parallel) model, MPI
  • Distributed computing is a different setting

• • •

Processor

Memory

Processor

Memory

Interconnection Network

Introduction to Massively Parallel Processing – Slide 73

is heterogeneous computing
Is Heterogeneous Computing

Multicore CPU Manycore GPU

Introduction to Massively Parallel Processing – Slide 74

c for cuda
C for CUDA
  • Philosophy: provide minimal set of extensions necessary to expose power
    • Function and variable qualifiers
    • Execution configuration
    • Built-in variables and functions valid in device code

Introduction to Massively Parallel Processing – Slide 75

topic 5 case studies
Topic 5: Case Studies

Introduction to Massively Parallel Processing – Slide 76

previous projects uiuc ece 498al
Previous Projects, UIUC ECE 498AL

Introduction to Massively Parallel Processing – Slide 77

speedup of applications
Speedup of Applications
  • GeForce 8800 GTX vs. 2.2 GHz Opteron 248

Introduction to Massively Parallel Processing – Slide 78

speedup of applications1
Speedup of Applications
  • 10x speedup in a kernel is typical, as long as the kernel can occupy enough parallel threads
  • 25x to 400x speedup if the function’s data requirements and control flow suit the GPU and the application is optimized

Introduction to Massively Parallel Processing – Slide 79

final thoughts
Final Thoughts
  • Parallel hardware is here to stay
  • GPUs are massively parallel manycore processors
    • Easily available and fully programmable
  • Parallelism and scalability are crucial for success
  • This presents many important research challenges
    • Not to mention the educational challenges

Introduction to Massively Parallel Processing – Slide 80

end credits
End Credits
  • Reading: Chapter 1, “Programming Massively Parallel Processors” by Kirk and Hwu.
  • Based on original material from
    • The University of Akron: Tim O’Neil, Kathy Liszka
    • Hiram College: Irena Lomonosov
    • The University of Illinois at Urbana-Champaign
      • David Kirk, Wen-mei W. Hwu
    • The University of North Carolina at Charlotte
      • Barry Wilkinson, Michael Allen
    • Oregon State University: Michael Quinn
    • Oxford University: Mike Giles
    • Stanford University: Jared Hoberock, David Tarjan
  • Revision history: last updated 6/4/2011.

Introduction to Massively Parallel Processing – Slide 81
