  1. ACSR Conductor

  2. Aluminium Conductors Steel Reinforced (ACSR), also known as Bare aluminium conductors, are one of the most widely used conductors for transmission. The conductor consists of one or more layers of aluminium wires stranded over a high strength steel core that can be single or multiple strands depending on the requirement. There can be various stranding combinations of Al and steel wires lending flexibility to obtain suitable current carrying capacity and mechanical strength for the application

  3. Its low weight combined with high tensile strength allows larger span runs. Electrical losses by corona effect are greatly reduced, due to the larger diameter size. Economical transmission and distribution of electrical energy can be achieved by ACSR, at very high voltages and distances.

  4. Flexibility requirements through Battery Energy Storage and carbon footprint reduction: • In other parts of the world, gas power plants are used as flex resources. However, their impact in India is limited owing to the shortage of fuel. This has led to 15GW of gas plants being completely stranded, while another 25GW operate at less than one-fifth of their capacity. • Flexibilization of existing coal thermal plants is most commonly pointed out as the approach to carry the lion’s share of the burden of RE integration by several studies conducted in India. However, few of these studies dig deeper into the true cost and capability of coal plants to flex to integrate renewables.

  5. Thank You https://www.sterlitepower.com/acsr-conductor
