  1. VERSION X GETTING READY FOR 200X

  2. AGENDA New Architecture & Firmware The Next Generation GUI Integrated iView Reporting Features

  3. New Architecture & Firmware

  4. Version X – Firmware Architecture • Introducing Light Weight CyberoamOS. • Firmware based – No more bulky Upgrades. • Multiple Firmware: Factory Default + Firmware of your choice. • No more RMAs due to OS Corruption and Upgrade Corruption. • Negligible chances of Database Corruption/inconsistencies. • ExtensibleArchitecture

  5. Salient Features of the NG GUI

  6. Accordion Menu & TABs for easy navigation of menu items

  7. Easy Access Top Panel

  8. Appliance Actions available on Dashboard – Reboot, Shutdown

  9. Static Status bar at bottom – Visible all the time

  10. Unsubscribed modules visibility on the menu itself

  11. Select Column Control, Direct Access from the Button

  12. Move column positions directly from select column control

  13. Filters on Manage Pages

  14. Filters on Manage Pages

  15. Pagination where ever required

  16. No Java Script Pop Ups - Web 2.0 Pop UP

  17. Grouping control with search facility – easy to search objects and add it to a group

  18. Tabbed Data Entry control for Bulk Addition

  19. Informative Tooltip giving detail information on the policy attached – including Edit Option

  20. Informative Tooltip giving detailed information on the policy attached – including Edit Option

  21. CR Custom Control – control with search functionality, and Add facility to add object from the control itself

  22. CR Custom Control – control with search functionality, and Add facility to add object from the control itself

  23. Integrated iView Reporting

  24. iView (Cyberoam Aggregated Reporting & Logging Software) • Subscription free On-Appliance Reporting • Real-time Monitoring and Alerting • Over 1100+ Drilldown Reports • Reports in HTML, MHTML, PDF, & CSV formats & Email Alerts • Web 2.0 GUI and Reporting interface.

  25. IPv6 Ready

  26. Cyberoam – With IPv6 Ready Logo – Only 2 IPV4

  27. IPv6 Ready • Only the 2nd UTM • IPv4IPv6 tunneling • IPv6IPv4 tunneling

  28. 3G & Wimax USB Modem Support

  29. 3G & Wimax USB Card Connectivity

  30. Instant Messaging Logging & Control

  31. Instant Messaging Logging & Control • Yahoo & Windows Live Messaging • Control Who Communicates with Whom • Control Webcam usage • Control Voice Usage • Individual as well as Group Control

  32. Instant Messaging & Control Control communication medium (chat, video, voice) Archive Communication Data Protection Control who can chat with whom Productivity

  33. Next Generation Layer 7 Firewall

  34. 80 80 80 21 443 80 443 443 21 443 1st Generation Firewalls Port 80 Port 443

  35. Skype Mail Mail Web Web FTP Web Bit Torrent Application Firewalls – CR Version 9

  36. CRM ERP Sales force You Tube IM Application Web mail Casual Traffic Next Generation Firewalls – Version X Application Firewall Crowd of Applications Bandwidth Management

  37. CRM ERP Sales force You Tube IM Application Web mail Casual Traffic Next Generation Firewalls Application Firewall Crowd of Applications Bandwidth Management

  38. Identity without IP

  39. Thin Client Support • Windows Thin Client Support • Windows Terminal Services • Citrix Presentation Server • Apply User Based Policies and Controls

  40. SSL VPN Enhancements

  41. SSL VPN Enhancements • Application Access Mode within Web Browzer • HTTP, HTTPS • RDP • Telnet , SSH • FTP • SSL VPN Client • Save Password • Auto Start VPN Connection

  42. Stability & Performance

  43. Stability & Performance • Firmware based approach • ~10 second Soft Reboot Time • Fast GUI Access • Extensible Architecture vs ASIC • Preparing for upcoming threats • Extensive Logging and Log Viewer for Instant Troubleshooting

  44. … And Much More

  45. …And Much More • Role Based Access Control • Multiple Authentication Support for User • External Authentication for Administrator • Customer My Account Revamp • HTTP DDoS attack protection • Naming Firewall Rules for easy troubleshooting • HTTP & FTP scanning over custom ports

  46. …And Much More • Inline Captive Portal • HTTPS • Super Enhanced Packet Capture Log & Log Viewer • VLAN over WAN • Support for MD5 Authentication for RIP & OSPF • Enhanced IPS Actions • Drop Connection • Drop Attack Source
