a state of the art review on mathematical modelling of flood propagation

A state of the art review on mathematical modelling offlood propagation

First IMPACT Workshop

Wallingford, UK,

16-17 May 2002

F. Alcrudo

University of Zaragoza

Spain

overview
Overview
  • The modelling process
  • Mathematical models of flood propagation
  • Solution of the Model equations
  • Validation
the modelling process
The modelling process
  • Understanding of flow characteristics
  • Formulation of mathematical laws
  • Numerical methods
  • Programming
  • Validation of model by comparison of results against real life data
  • Prediction: Ability to FOREtell not to PASTtell
the modelling process4
The modelling process

REALITY

Analisis

Computer Simulation

& Validation

Data uncertainties

Conceptual

errors & uncertainties

Discretization errors

COMPUTER MODEL

MATHEMATICAL MODEL

Numerics &

Implementation

slide5

The flow characteristics

  • 3-D
  • time dependent
  • incompresible
  • free surface
  • fixed bed

(no erosion – deposition)

  • turbulent (very high Re)
slide6

Mathematical models

  • 3-D Navier-Stokes (DNS)
      • Chimerical
  • 3-D RANS
      • Turbulence models ?
      • Still too complex
  • Euler (inviscid)
      • Simpler, requires much less resolution
      • Could be an option soon
slide7

Mathematical models

  • Tracking of the free surface
      • VOF method (Hirt & Nichols 1981)
      • MAC method (Welch et al. 1966)
      • Moving mesh methods
slide8

NS, RANS & Euler

  • 2-D dam break and overturning waves
    • Zwart et al. 1999
    • Mohapatra et al. 1999
    • Stansby et al. (Potential) 1998
    • Stelling & Busnelli 2001...
  • River flows
    • Casulli & Stelling (Q-hydrostatic) 1998
    • Sinha et al. 1998, Ye &McCorquodale 1998...
slide9

h

v

u

Simplified mathematical models

Shallow Water Equations (SWE)

  • Depth integrated NS
  • Mass and momentum conservation in horizontal plane
  • Pseudo compressibility
slide10
Inertial & Pressure fluxes
      • Convective Momentum transport
      • Hydrostatic pressure distribution
slide11
Diffusive fluxes
      • Fluid viscosity
      • Turbulence
      • Velocity dispersion (non-uniformity)

Benqué et al. (1982)

slide12
Sources
      • Bed slope
      • Bed friction (empirical)
      • Infiltration / Aportation (Singh et al. 1998 Fiedler et al. 2000)
slide14

Issues in SWE models

  • Corrections for non-hydrostatic pressure, non-zero vertical movement
    • Boussinesq aproximation (Soares 2002)
    • Stansby and Zhou 1998 (in NS-2D-V)
    • Flow over vertical steps (Zhou et al. 2001)

(Exact solutions Alcrudo & Benkhaldoun 2001)

  • Corrections for non-uniform horizontal velocity ?

(Dispersion effects)

slide15

Issues in SWE models (cont.)

  • Turbulence modelling in 2D-H
    • Nadaoka & Yagi (1998) river flow
    • Gutting & Hutter (1998) lake circulation (K-e)
    • Gelb & Gleeson (2001) atmospheric SWE model
  • Bottom friction
    • Non-uniform unsteady friction laws ?
    • Distributed friction coefficients (Aronica et al. 1998)
    • Bottom induced horizontal shear generation (Nadaoka & Yagi 1998)
slide16

Simplified models

  • Kinematic & diffusive models
    • Arónica et al. (1998)
    • Horrit and Bates (2001)
  • Flat Pond models
    • Tous dam break inundation (Estrela 1999)
solution of the model equations restricted to swe models
Solution of the model equations(Restricted to SWE models)
  • Discretization strategies
  • Mesh configurations
  • Numerical schemes
      • Space-Time discretizations
      • Front propagation
      • Source term integration
  • Wetting and drying
slide19

Discretization strategies

  • Finite differences
      • Decaying use (less flexible)
      • Usually structured grids
      • Scheme development/testing (Liska & Wendroff 1999, Glaister 2000 ...)
      • Practical appications (Bento-Franco 1996, Heinrich et al. 2000, Aureli et al. 2000)
slide20
Finite volumes
      • Both structured & unstructured grids
      • Cell-centered or cell-vertex
      • Extremely flexible & intuitive
      • Many practical applications (CADAM 1998-1999, Brufau et al. 2000, Soares et al. 1999, Zoppou 1999)
      • Most popular
slide21
Finite elements
      • Variational formulation
        • Conceptually more complex
        • More difficult front capture operator (Ribeiro et al. 2001, Hauke 1998)
      • Practical applications
        • Hervouet 2000, Hervouet & Petitjean 1999
        • Supercritical / subcritical, tidal flows, Heniche et al. 2000
slide22

Mesh configurations

  • Structured
      • Cartesian / Boundary fitted (mappings)
      • Less flexible / Easy interpolation
  • Unstructured
      • Flexible but Indexing / Bookkeeping overheads
      • More elaborated Interpolation (Sleigh 1998, Hubbard 1999)
      • Easy refining (Sleigh 1998, Soares 1999) and adaptation (Benkhaldoun 1994, Ivanenko et al. 2000)
  • Quad-Tree
slide23

Mesh configurations

  • Quad-Tree
      • Cartesian with grid refining/adaptation
      • Hierarchical structure / Interpolation operators
      • Needs bookkeeping
      • Usually specific boundary treatments (Cartesian cut-cell approach Causon et al. 2000, 2001)
      • Practical applications (Borthwick et al. 2001)
slide24

Numerical schemes

  • Space – Time discretization
      • Space discretizations +
      • Time integration of resulting ODE
  • Time integration
      • Explicit usu 2-step, Runge-Kutta (Subject to CFL constraints)
      • Implicit (not frequent)
slide25
Front propagation
      • Shock capturing or through methods
      • Approximate Riemann solvers (Most popular Roe, WAF second)
      • Higher order interpolations + limiters (either flux or variables), TVD, ENO
      • Mostly in FV & FD but progressively incorporated into FE (Sheu & Fhang 2001)
      • Plenty of methods (or publications)
slide26
Multidimensional upwind
      • Wave recognition schemes (opposed to classical dimensional splitting)
      • Consistent Higher resolution of wave patterns
      • Usually in unstructured (cell vertex) grids (mostly triangles)
      • Considerably more expensive
      • Hubbard & Baines 1998, Brufau & Garcianavarro 2000 ...
slide27
Source term integration (bed slope)
      • Flow is source term dominated in most practical applications
      • Flux discretization must be compatible with source term
      • Source term upwinding (Bermudez & Vazquez 1994)
      • Pressure – splitting (Nujic 1995)
      • Flux lateralisation (Capart et al. 1996, Soares 2002)
      • Surface gradient method (Zhou et al. 2001)
      • Discontinuous bed topography (Zhou et al. 2002)
slide28
Wetting-drying
      • Intrinsic to flood propagation scenarios
      • Instabilities due to coupling with friction formulae and to sloping bottom (Soares 2002)
      • Threshold technique (CADAM 1998), simple, widely used but no more than a trick
      • Fictitious negative depth (Soares 2002)
      • Boundary treatment at interface (Bento-Franco 1996, Sleigh 1998), modification of bottom function (Brufau 2000)
      • Bottom function modification, ALE (Quecedo and Pastor (2002) in Taylor Galerkin FE
validation
Validation
  • Model accuracy
    • Differences between model output & real life
    • Determined with respect to experimental data
  • Accuracy loss:
    • Uncertainty Due to lack of knowledge
    • Errors Recognizable defficiencies
slide30
Main losses of accuracy in flood propagation models
    • Errors in the math description (SWE or worse)
    • Uncertainties in data (topography, friction levels, initial flood characteristics)
  • Additional errors
    • Inaccurate solution of model equations (grid refining)
slide31
Much validation work of numerical methods against analytical /other numerical solutions
      • Chippada et al., Hu et al., Aral et al. 1998
      • Holdhal et al., Liska & Wendroff , Zoppou & Roberts etc ... 1999
      • Causon et al., Wang et al., Borthwick et al. etc ... 2001
  • Validation against data from laboratory experiments
      • CADAM work, Tseng et al. 2000, Sakarya & Toykay 2000 etc ...
  • Validation against true real flooding data
      • CADAM 1999, Hervouet & Petitjean (1999), Hervouet (2000), Horritt (2000), Heinrich et al. (2001), Haider (2001)
      • Sensitiviy analysis (usually friction)
      • Urban flooding ?
conlusions
Conlusions
  • Present feasible mathematical descriptions of flood propagation are known to be erroneous but ...
      • Better mathematical models are still far ahead
  • The level of accuracy of present models has not yet been thoroughly assessed
  • There are enough methods at hand to solve the mathematical models (most are good enough)
  • Exhaustive validation programs against real data are needed
