Presentation Transcript
home automation in the wild challenges and opportunities
Home Automation in the Wild:Challenges and Opportunities

A.J. Brush

Bongshin Lee

Ratul Mahajan

Sharad Agarwal

Stefan Saroiu

Colin Dixon

smart homes
Smart Homes
  • Is it possible to create a home environment that is aware of its occupants whereabouts and activities?

Georgia Tech Aware Home

Develop a home that essentially programs itself by observing the lifestyle and desires of the inhabitants, and learning to anticipate and accommodate their needs

The Adaptive House, Mozer et al.

don t forget hollywood
Don’t forget Hollywood

It's up to Ben to match wits with PAT's central intelligence and "out-smart" the Smart House once and for all!

home automation
Home Automation

Capability to automate and control multiple disparate systems

Motion sensor

Door sensor

Camera

Programmed light switches

Wall Panels

Phone Access

Lucero, S., Burden, K. Home Automation and Control, ABI Research 2010

adopting home a utomation
Adopting Home Automation

Do-It-Yourself (DIY)

Outsourced

Our goal: Better understand current state of home automation and learn from people’s long term use.

study method
Study Method
  • 14 households with one or more of the following:
  • Remote lighting control
  • Multi-room audio/video systems
  • Security cameras
  • Motion detectors

Outsourced

DIY

Home Tour

Questionnaire

Inventory

Semi-Structured Interview

Chetty, M., Sung, J-Y., Grinter, R. How Smart Homes Learn: The Evolution of the Networked Home and Household. Proc. UbiComp 2007, 127-144.

related work inspirations
Related Work Inspirations
  • Technology guruand consumers
  • Financial considerations
  • Automation for religious purposes
  • Long-term general use of home automation

Poole, E., Chetty, M., Grinter, R., Edwards, W.K. More than Meets the Eye: Transforming the User Experience of Home Network Management. Proc. DIS 2008.

Rode, J., Toye, E., Blackwell, A. The Domestic Economy: a Broader Unit of Analysis for End User Programming. Proc. CHI 2005.

Grinter, R., Edwards, W., Chetty, M., Poole, E.S., Sung, J.-Y., Yang, J., Crabtree, A., Tolmie, P., Rodden, T., Greenhalgh,C., Benford, S. The ins and outs of home networking: The case for useful and usable domestic networking. ACM ToCHI 16, 2(2009).

Woodruff, A., Augustin, S., Foucalt, B. Sabbath Day Home Automation: “It‟s Like Mixing Technology and Religion” Proc. CHI 2007.

living with automation
Living with Automation

Convenience

“It allows me to be lazy, honestly, because every day [before automation]

I would go double check the locks, make sure all the lights are off on all the floors and make sure that everything’s closed.” Technology consumer from DIY house 6, D6_C

slide9
Why?

Peace of Mind

Control

O: over various devices

DIY: over what they installed and enabled.

Monitoring

diversity in installation desires
Diversity in Installation & Desires

From X10 to control a few lights to embedded panels in every room

Control

Media

Security

Environment

augmented not smart
Augmented, Not Smart

User-controlled

Rule-based

not ready for broad adoption
Not ready for broad adoption

4 barriers

Cost, Inflexibility, Manageability, Security

Caveat 1: Not problems for our participants

Caveat 2: Not answering whether functionality

is generally appealing

barrier 1 high cost of ownership
Barrier 1: High Cost of Ownership

+

DIY: $200 - $60,000, $5,000 median

DIYs trade-off lower monetary cost for time

O: $13,500 – $120,000 $40,000 median

barrier 1 high cost of ownership1
Barrier 1: High Cost of Ownership

Two Surprises

Consultant visits not a big factor

Low perceived value of additional applications

barrier 2 inflexibility
Barrier 2: Inflexibility

Integration Ease or Flexibility

DIY: Use expertise to overcomeOutsource: Choose one brand

Structural or Retrofit?

(9 put automation in place during structural changes)

Surprise:

Thinking ahead to moving…

barrier 3 poor manageability
Barrier 3: Poor Manageability

Our households were well-equipped to manage

Complex UI

Consultant Required

“I started explaining the panel (how to call fire department) to them and they looked in dread. People just don’t want to touch it. And my own mother sat in our house in the dark, because she was scared to touch any of the controls.”

Difficult to customize for Outsourced

barrier 3 poor manageability1
Barrier 3: Poor Manageability

Iteration required

“I thought when I went into this, I’d want my alarm system integrated and I’d want these automatic features firing off in the background like, you know, I’d wake up and music is playing in my bathroom and the lights come up, you know all these Jetson type things. And the challenge with that, while they’re all great, I don’t live that structured of a life, not waking up into [it] every day, and I'm not going in the shower every day at the same time. And you know, I don't want to hear music all the time. So I don’t think the routineness of automation is what I was really wanting.” (D8_G)

barrier 4 difficulty achieving security
Barrier 4: Difficulty Achieving Security

Remote access

  • Eight households currently have remote access enabled
  • Tension between convenience and security

Very technically savvy participants concerned about vulnerability of remote access

Cameras

Door locks

simple user groups for future needs
Simple User Groups for Future Needs
  • What restrictions would you place (if any) on applications you were interested in buying?
  • Presence based security
  • All other restrictions:
    • Adult household member
    • Child household member
    • Guest
    • Household technology guru
implications for research
Implications for Research

Bandwidth Needs vs. Structural Changes

implications for research1
Implications for Research

Bandwidth Needs vs. Structural Changes

  • Standalone Devices vs. Home Integration
  • Individually managed sub-systems
  • Cross-device functionality challenging
  • Hard to incrementally add functionality
implications for research2
Implications for Research

Bandwidth Needs vs. Structural Changes

  • Standalone Devices vs. Home Integration
  • Individually managed sub-systems
  • Cross-device functionality challenging
  • Hard to incrementally add functionality

Simple Confidence-building Security vs. Desired Functionality

concluding remarks
Concluding Remarks
  • Interviewed 14 households with home automation, DIY and Outsourced
  • 4 Barriers to broader adoption:
    • Cost of ownership (Time & Money)
    • Inflexibility
    • Poor Manageability
    • Difficulty Achieving Security
  • Identify directions for future research
    • Eliminate the need for structural changes
    • Enable composition of home devices
    • Simple security that can be confidently configured
thanks
Thanks!

HomeOS:

The Home Needs an Operating System (and a App Store)

HotNets IX

Dixon, C., Mahajan, R., Agarwal, S., Brush, A., Lee, B., Saroui, S., Bahl, V.,

Ask us if you are interested….

A.J. Brush

Bongshin Lee

Ratul Mahajan

Sharad Agarwal

Stefan Saroiu

Colin Dixon
