    1. IPCS Interactive Problem Control System

    2. IPCS IBM product Reading dumps SVC dumps Console / Region dumps SYSM dumps “SLIP TRAP” dumps

    3. SVC Dumps Contains all information available within that “region” or “initiator” Normally manually requested May be programmatically requested Usually by system utility routines Produced to a large flat file

    4. SVC Dumps Data Set Information Command ===> Data Set Name . . . . : TSTSS.DS0400.D020507.T163721.BCKCPS2H.S00007 General Data Current Allocation Management class . . : MIGFAST2 Allocated blocks . : 16,262 Storage class . . . : STRIPE52 Allocated extents . : 13 Volume serial . . . : DLS308 + Device type . . . . : 3390 Data class . . . . . : SVCDUMP Current Utilization Organization . . . : PS Used blocks . . . . : 16,262 Record format . . . : FBS Used extents . . . : 13 Record length . . . : 4160 Block size . . . . : 24960 1st extent blocks . : 1250 Secondary blocks . : 9847 Data set name type : EXTENDED SMS Compressible . : NO Creation date . . . : 2002/05/07 Referenced date . . : 2002/05/07 Expiration date . . : ***None*** To display multiple volumes press Enter or enter Cancel to Exit.

    5. Console / Region Dumps Operator requested S/122 or S/222 Systems Programming options to Re-direct to flat file More info than a standard SYSUDUMP Less info than a standard SVC Dump

    6. SYSMDUMP Used in place of a SYSUDUMP Provides a flat file instead of a SYSOUT file Allocated via JCL statements IPCS readable Same general format as an SVC dump but less information Event driven

    7. SYSMDUMP //********************************************************************* //* CPCS DD STATEMENTS //*-------------------------------------------------------------- //SITEDDG DD DUMMY,DCB=BLKSIZE=80 //DMBIBMY DD DUMMY,DCB=BLKSIZE=80 //DMBCAPN DD DUMMY,DCB=BLKSIZE=80 //SORTDIAG DD DUMMY //ABNLDUMP DD DUMMY //SYSPRINT DD SYSOUT=* //SYSDBOUT DD SYSOUT=* //SNAPDCB DD SYSOUT=* //CEEUDUMP DD SYSOUT=* //MSGDD DD SYSOUT=* //IGZSRTCD DD DUMMY //SYSUDUMP DD SYSOUT=* //SYSMDUMP DD DSN=&ENV.CK.#&RMT.CPC11N.SYSMDUMP(+1), // DISP=(NEW,CATLG,CATLG), // SPACE=(CYL,(50,100)), // UNIT=SYSDA, // DCB=(RECFM=FBS,LRECL=4160,BLKSIZE=24960) //SYSABOUT DD SYSOUT=* //SNAPDD DD SYSOUT=* //SNAPMCDD DD SYSOUT=* //CEEDUMP DD SYSOUT=* //MICRSNAP DD SYSOUT=* //SYSOUT DD SYSOUT=*

    8. SYSMDUMP Dynamic Allocation same as SYSUDUMP SYSMDUMP DSAT DYNDEV=DISK, DYNDDN=SYSMDUMP, DYNDSN=TSTCK.#GCPC11N.SYSMDUMP(+1), DYNSTAT=NEW, DYNNORM=CATLG, DYNCOND=CATLG, DYNUNIT=3390, DYNSTYP=CYL, DYNPSPA=50, DYNSSPA=100, DYNRECF=FBS, DYNLRCL=4160, DYNBSIZ=24190 SYSUDUMP DSAT DYNDEV=PRTR,DYNDDN=SYSUDUMP,DYNCLASS=R

    9. SLIP TRAP dumps Event driven but selected SYS1.PARMLIB IEADMP00 “SET” to capture a specific condition or content in memory Normally “Environment” issue not “Application” S/13E – S/33E dumps

    10. IPCS Normally executed via CLIST from TSO command line (Opt 6) Files pre-allocated for each individual user at time of use File sizes are large Dump inventories

    11. IPCS ------------------------ IPCS PRIMARY OPTION MENU ---------------------------- OPTION ===> ******************** 0 DEFAULTS - Specify default dump and options * USERID - R1921 1 BROWSE - Browse dump data set * DATE - 02/05/08 2 ANALYSIS - Analyze dump contents * JULIAN - 02.128 3 UTILITY - Perform utility functions * TIME - 16:47 4 INVENTORY - Inventory of problem data * PREFIX - R1921 5 SUBMIT - Submit problem analysis job to batch * TERMINAL- 3278 6 COMMAND - Enter subcommand, CLIST or REXX exec * PF KEYS - 24 T TUTORIAL - Learn how to use the IPCS dialog ******************** X EXIT - Terminate using log and list defaults Enter END command to terminate IPCS dialog

    13. IPCS defaults ------------------------- IPCS Default Values --------------------------------- Command ===> You may change any of the defaults listed below. The defaults shown before any changes are LOCAL. Change scope to GLOBAL to display global defaults. Scope ==> LOCAL (LOCAL, GLOBAL, or BOTH) If you change the Source default, IPCS will display the current default Address Space for the new source and will ignore any data entered in the Address Space field. Source ==> NODSNAME Address Space ==> Message Routing ==> NOPRINT TERMINAL Message Control ==> CONFIRM VERIFY FLAG(WARNING) Display Content ==> NOMACHINE REMARK REQUEST NOSTORAGE SYMBOL Press ENTER to update defaults. Use the END command to exit without an update.

    14. IPCS defaults ------------------------- IPCS Default Values ------------------ LOCAL updated Command ===> You may change any of the defaults listed below. The defaults shown before any changes are LOCAL. Change scope to GLOBAL to display global defaults. Scope ==> LOCAL (LOCAL, GLOBAL, or BOTH) If you change the Source default, IPCS will display the current default Address Space for the new source and will ignore any data entered in the Address Space field. Source ==> DSNAME('TSTSS.DS0400.D020507.T163721.BCKCPS2H.S00007') Address Space ==> Message Routing ==> NOPRINT TERMINAL Message Control ==> CONFIRM VERIFY FLAG(WARNING) Display Content ==> NOMACHINE REMARK REQUEST NOSTORAGE SYMBOL Press ENTER to update defaults. Use the END command to exit without an update. F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    15. IPCS browse ------------------------- IPCS - ENTRY PANEL --------------------------------- Command ==> CURRENT DEFAULTS: Source ==> DSNAME('TSTSS.DS0400.D020507.T163721.BCKCPS2H.S00007') Address space ==> OVERRIDE DEFAULTS: (defaults used for blank fields) Source ==> DSNAME('TSTSS.DS0400.D020507.T163721.BCKCPS2H.S00007') Address space ==> Password ==> POINTER: Address ==> (blank to display pointer stack) Remark ==> (optional text) F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=STACK F7=UP F8=DOWN F9=SWAP F10=CURSOR% F11=CURSOR? F12=CURSOR

    16. IPCS browse DSNAME('TSTSS.DS0400.D020507.T163721.BCKCPS2H.S00007') POINTERS -------------- Command ===> SCROLL ===> CSR ASID(X'00E5') is the default address space PTR Address Address space Data type 00001 00000000 ASID(X'00E5') AREA Remarks: **************************** END OF POINTER STACK ***************************** F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=STACK F7=UP F8=DOWN F9=SWAP F10=CURSOR% F11=CURSOR? F12=CURSOR

    17. IPCS browse DSNAME('TSTSS.DS0400.D020507.T163721.BCKCPS2H.S00007') POINTERS -------------- Command ===> SCROLL ===> CSR ASID(X'00E5') is the default address space PTR Address Address space Data type s0001 00000000 ASID(X'00E5') AREA Remarks: **************************** END OF POINTER STACK ***************************** F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=STACK F7=UP F8=DOWN F9=SWAP F10=CURSOR% F11=CURSOR? F12=CURSOR

    18. IPCS browse ASID(X'00E5') ADDRESS(00.) STORAGE -------------------------------------------- Command ===> SCROLL ===> CSR 00000000 040C0000 811BC878 00000000 00000000 | ....a.H......... | 00000010 00FD4318 00000000 070C2000 8AB35462 | ................ | 00000020 070C1000 8AB215D4 070C4000 8AB700FA | .......M.. ..... | 00000030 070E0000 00000000 070C1000 8AB3546A | ................ | 00000040 00000000 00000000 00000000 00FD4318 | ................ | 00000050 00000000 00000000 040C0000 810BF2B8 | ............a.2. | 00000060 040C0000 80FFAF00 00080000 80B2EBE0 | ...............\ | 00000070 00080000 FE59E940 040C0000 813B4B80 | ......Z ....a... | 00000080 00000000 00001004 00020001 00060011 | ................ | 00000090 00002001 00000000 00000000 00000000 | ................ | 000000A0 0C00EF00 013B9F88 00000000 00000000 | .......h........ | 000000B0 00000000 00000000 00013EC1 030AA858 | ...........A..y. | 000000C0 28000100 00000000 00000000 00000000 | ................ | 000000D0 00000000 7E53A000 00000000 7FFFFC00 | ....=......."... | 000000E0 B79674F0 F14F4B00 00000000 00000000 | .o.01|.......... | 000000F0.:01BF.--All bytes contain X'00' 000001C0 5FB1FE50 7FFFE07F 7D2F7FC0 00000001 | ^..&".\"'."{.... | 000001D0 00010001 7D3EE040 FE000000 7FFFE07F | ....'.\ ....".\" | 000001E0.:01EF.--All bytes contain X'00' 000001F0 78CCB918 7FFFE07F FF8FD3DA 04110010 | ....".\"..L..... | 00000200 D7E2C140 00000040 00F1C008 7E4E8008 | PSA ... .1{.=+.. | 00000210 00F73000 7E53F000 00000000 00000000 | .7..=.0......... | 00000220 00FD2B80 00FBD180 00000000 00000000 | ......J......... | 00000230 00000000 00000000 00000000 00000001 | ................ | 00000240 00000000 00000000 00000000 073DE598 | ..............Vq | 00000250 070C0000 813B7A80 070E0000 00000000 | ....a.:......... | 00000260 AD070950 AD040950 AD040950 AD000950 | ...&...&...&...& | 00000270 AD070950 00000000 00000704 00000000 | ...&............ | F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=STACK F7=UP F8=DOWN F9=SWAP F10=CURSOR% F11=CURSOR? F12=CURSOR

    19. IPCS browse L nnnnnnnn command Point and click cursor commands

    20. IPCS browse DSNAME('TSTSS.DS0400.D020507.T163721.BCKCPS2H.S00007') POINTERS -------------- Command ===> SCROLL ===> CSR ASID(X'00E5') is the default address space PTR Address Address space Data type 00001 00000000 ASID(X'00E5') AREA Remarks: 00002 00FD4318 ASID(X'00E5') AREA Remarks: 00003 00FD5B8C ASID(X'00E5') AREA Remarks: **************************** END OF POINTER STACK ***************************** F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=STACK F7=UP F8=DOWN F9=SWAP F10=CURSOR% F11=CURSOR? F12=CURSOR

    21. IPCS analysis ------------------- IPCS MVS ANALYSIS OF DUMP CONTENTS ------------------------ OPTION ===> To display information, specify the corresponding option number. 1 SYMPTOMS - Symptoms ******************** 2 STATUS - System environment summary * USERID - R1921 3 WORKSHEET - System environment worksheet * DATE - 02/05/08 4 SUMMARY - Address spaces and tasks * JULIAN - 02.128 5 CONTENTION - Resource contention * TIME - 17:17 6 COMPONENT - MVS component data * PREFIX - R1921 7 TRACES - Trace formatting * TERMINAL- 3278 * PF KEYS - 24 ******************** Enter END command to terminate MVS dump analysis. F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    22. IPCS analysis / symptoms IPCS OUTPUT STREAM ------------------------------------------ Line 1 Cols 1 78 Command ===> SCROLL ===> CSR * * * * S Y M P T O M * * * * Primary Symptom String: RIDS/IDA0192A#L RIDS/IDA0557A AB/S00C4 RIDS/IDAOCEA1#R VALU/H100C4710 REGS/0F158 REGS/0C158 PRCS/00000011 Symptom Symptom data Explanation --------------- ------------- ----------- RIDS/IDA0192A#L IDA0192A#L Routine identifier RIDS/IDA0557A IDA0557A Routine identifier AB/S00C4 00C4 ABEND code - system RIDS/IDAOCEA1#R IDAOCEA1#R Routine identifier VALU/H100C4710 100C4710 Error related hexadecimal value REGS/0F158 0F158 Program register REGS/0C158 0C158 Program register PRCS/00000011 00000011 Return code The dump does not contain a secondary symptom string. F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    27. IPCS analysis / worksheet IPCS OUTPUT STREAM ------------------------------------------ Line 0 Cols 1 78 Command ===> SCROLL ===> CSR ****************************** TOP OF DATA *********************************** MVS Diagnostic Worksheet Dump Title: IEC999I IFG0RR0A,........,BCKCPS2H,BCHX2PRD,WORKAREA = 936B40 CPU Model 9672 Version 60 Serial no. D30465 Address 0D Date: 05/07/2002 Time: 16:37:28.414930 Local Original dump dataset: TSTSS.DS0400.D020507.T163721.BCKCPS2H.S00007 Information at time of entry to SVCDUMP: HASID 00E5 PASID 00E5 SASID 00E5 PSW 070C1000 00E97E2C CML ASCB address 00000000 Trace Table Control Header address 7F8A2000 Dump ID: 007 Error ID: Seq 14910 CPU 0000 ASID X'00E5' Time 16:37:21.2 SDWA address 00937918 SYSTEM RELATED DATA CVT SNAME (154) S0400 VERID (-18) F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    30. IPCS analysis / summary IPCS OUTPUT STREAM ------------------------------------------ Line 0 Cols 1 78 Command ===> SCROLL ===> CSR ****************************** TOP OF DATA *********************************** * * * * K E Y F I E L D S * * * * JOBNAME BCKCPS2H SELECTED BY: CURRENT ERROR ASCB: 00B53400 FWDP..... 00ADAE80 ASID..... 00E5 CSCB..... 35BDF500 TSB...... 00000000 AFFN..... FFFF ASXB..... 009FDE90 DSP1..... 00 FLG2..... 00 SRBS..... 0000 LOCK..... 00000000 ASSB..... 07CAF280 TCB: 009FE0A8 CMP...... 00000000 PKF...... 00 LMP...... FF DSP...... FF TSFLG.... 00 STAB..... 009FD570 NDSP..... 00000000 JSCB..... 009FDD14 BITS..... 00000000 DAR...... 00 RTWA..... 00000000 FBYT1.... 00 Task non-dispatchability flags from TCBFLGS4: Top RB is in a wait PRB: 009FDC88 WLIC..... 00020001 OPSW..... 070C1000 812EDCF0 LINK..... 019FE0A8 EP....... IEAVAR00 ENTPT.... 8BD081C8 TCB: 009FFE88 CMP...... 00000000 PKF...... 00 LMP...... FF DSP...... FF F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    33. IPCS analysis / contention IPCS OUTPUT STREAM ------------------------------------------ Line 0 Cols 1 78 Command ===> SCROLL ===> CSR ****************************** TOP OF DATA *********************************** ANALYZE processing may not be valid for a VIRTUAL dump CONTENTION EXCEPTION REPORT JOBNAME=IOS. ASID=0001 UCBCTC=00F07CB8 JOBNAME=IOS. HOLDS THE FOLLOWING RESOURCE(S): RESOURCE #0026: There are 0001 units of work waiting for this resource NAME=I/O Device 4342 (CTC ) VOLSER= DATA=(IOS) Device not ready. STATUS FOR THIS UNIT OF WORK: This address space is on the SRM IN queue. JOBNAME=IOS. ASID=0001 UCBCTC=00F07F38 JOBNAME=IOS. HOLDS THE FOLLOWING RESOURCE(S): RESOURCE #0024: There are 0001 units of work waiting for this resource NAME=I/O Device 434A (CTC ) VOLSER= DATA=(IOS) Device not ready. STATUS FOR THIS UNIT OF WORK: This address space is on the SRM IN queue. F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    35. IPCS analysis / component ------------------ IPCS MVS DUMP COMPONENT DATA ANALYSIS ---------------------- OPTION ===> SCROLL ===> CSR To display information, specify "S option name" or enter S to the left of the option desired. Enter ? to the left of an option to display help regarding the component support. S Name Abstract ALCWAIT Allocation wait summary AOMDATA AOM analysis APPCDATA APPC/MVS Data Analysis ASCHDATA APPC/MVS Scheduler Data Analysis ASMCHECK Auxiliary storage paging activity ASMDATA ASM control block analysis AVMDATA AVM control block analysis CICS530 CICS/TS ANALYSIS COMCHECK Operator communications data COUPLE XCF Coupling analysis CTRACE Component trace summary DAEDATA DAE header data DB2DATA DB2 analysis DIVDATA Data in virtual storage DLFDATA Data Lookaside Facility data DLFTRACE Data Lookaside Facility trace GRSDATA ENQ/DEQ resources ICMPHDR TCP/IP ICMP Header Formatter IMSDUMP IMS analysis IOSCHECK Active input/output requests IPCSDATA IPCS control data IPHDR TCP/IP IP Header Formatter F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    38. IPCS analysis / component / sumdump IPCS OUTPUT STREAM ---------------------------------------- Line 151 Cols 1 78 Command ===> SCROLL ===> CSR RTM2WA SUMMARY -------------- +001C Completion code 840C4000 +008C Abending program name/SVRB address 009FD8B0 00000000 +0094 Abending program addr 00000000 GPRs at time of error 0-3 00000068 00933390 3AC0D400 3AC0DAD8 4-7 0093A4A8 00FD9AB4 3B19DB0C 3B19D538 8-11 0093A4A8 80BBD000 00000000 00000000 12-15 3090A190 3B19D538 8A6DF846 3090A190 +007C EC PSW at time of error 070C3000 B090A2E8 00040011 00933000 +00DC SDWACOMP 00000000 +00E8 Return code from recovery routine-00 Continue with termination-implies percolation +00E0 Retry Address returned from recovery exit 00000000 +00E4 RB Address for retry 00000000 +000C CVT Address 00FD4318 +0038 RTCT Address 00FBFA88 +00C8 SCB Address 00943F40 +0354 SDWA Address 00937918 +0014 SVRB Address 00948B98 +016C Previous RTM2WA for the task 00000000 +0170 Previous RTM2WA for recursion 00000000 F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    39. IPCS analysis / component / systrace IPCS OUTPUT STREAM ------------------------------------------ Line 0 Cols 1 78 Command ===> SCROLL ===> CSR ****************************** TOP OF DATA *********************************** --------------------------------------------------- SYSTEM TRACE TABLE ------- -- ------------------ -- ------------------ PR ASID WU-ADDR- IDENT CD/D PSW----- ADDRESS- UNIQUE-1 UNIQUE-2 UNIQUE-3 PS UNIQUE-4 UNIQUE-5 UNIQUE-6 PS ******** TRACE DATA IS NOT AVAILABLE FROM ALL PROCESSORS BEFORE THIS TIME. 06 00E5 072EB1F0 SRB 070C0000 810748E0 000000E5 00A95A00 00A95A2C 0095DE88 80 06 00E5 00000000 SSRV 2 80FEC0FC 00171184 7F000000 00000000 00000000 06 00E5 0095DE88 DSP 078D1000 001045F0 00000000 00000001 FFEFCE18 00 06 00E5 0095DE88 SVC 3C 078D0000 800A8B6E 00FD4318 00000100 00171A04 06 00E5 0095DE88 SVCR 3C 078D0000 800A8B6E 00000000 00000000 00171A04 06 00E5 0095DE88 SVC 3C 078D3000 800A8B9E 00FD4318 00000084 00171A04 06 00E5 0095DE88 SVCR 3C 078D3000 800A8B9E 00000000 00000000 00171A04 06 00E5 0095DE88 SVC 3C 078D0000 800A8B6E 00FD4318 00000100 00171A04 06 00E5 0095DE88 SVCR 3C 078D0000 800A8B6E 00000000 00000000 00171A04 06 00E5 0095DE88 SVC 3C 078D3000 800A8B9E 00FD4318 00000084 00171A04 06 00E5 0095DE88 SVCR 3C 078D3000 800A8B9E 00000000 00000000 00171A04 06 00E5 0095DE88 SVC 3C 078D0000 800A8B6E 00FD4318 00000100 00171A04 06 00E5 0095DE88 SVCR 3C 078D0000 800A8B6E 00000000 00000000 00171A04 06 00E5 0095DE88 SVC 3C 078D3000 800A8B9E 00FD4318 00000084 00171A04 06 00E5 0095DE88 SVCR 3C 078D3000 800A8B9E 00000000 00000000 00171A04 06 00E5 0095DE88 SVC 3C 078D0000 800A8B6E 00FD4318 00000100 00171A04 06 00E5 0095DE88 SVCR 3C 078D0000 800A8B6E 00000000 00000000 00171A04 F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    40. IPCS analysis / component / vsmlist IPCS OUTPUT STREAM ------------------------------------------ Line 0 Cols 1 78 Command ===> SCROLL ===> CSR ****************************** TOP OF DATA *********************************** VIRTUAL STORAGE MANAGEMENT DUMP FORMAT ROUTINE THE FOLLOWING KEYWORDS ARE IN EFFECT: CONTROLBLOCKS GLOBAL CURRENT ERROR DETAIL SUBPOOL TRANSLATION TABLE RESIDES AT ADDRESS 0170D1B8 VSM GLOBAL DATA AREA AT ADDRESS 02F1A1D8 +0000 ID....... GDA SQAT5.... 0170D6C0 AQAT5.... 02F1CC18 +000C ADF45.... 02F22A7C ADL45.... 08F1D850 SZF45.... 02F22A7C +0018 SZL45.... 02F22CBC ESQT5.... 0170D78C EAQT5.... 02F1CC18 +0024 EADF5.... 02F22CD4 EADL5.... 03A58988 ESZF5.... 02F22CD4 +0030 ESZL5.... 02F22F14 SQAT6.... 0170D45C AQAT6.... 02F1D418 +003C ADF26.... 02F233DC ADL26.... 07F41CD0 SZF26.... 02F233DC F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    42. IPCS analysis / traces --------------------------- IPCS Trace Processing ----------------------------- OPTION ===> To display trace information, enter the corresponding option number. 1 CTRACE - Component trace 2 GTFTRACE - Generalized trace facility 3 MTRACE - Master trace 4 SYSTRACE - System traces 5 CPUTRACE - Hardware instruction trace buffer 6 MERGE - Merge multiple traces T TUTORIAL - Details on these traces Enter END command to terminate IPCS trace processing. F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    43. IPCS analysis / traces / ctrace ---------------------- CTRACE PRIMARY OPTION MENU ---------------------------- OPTION ===> To display CTRACE information, enter the corresponding option. Q QUERY - Specify parameters for QUERY report D DISPLAY - Specify parameters to display CTRACE entries S START - Start CTRACE subcommand as specified below R RESET - Reset the CTRACE parameters END/PF3 = terminate CTRACE processing. F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    44. IPCS analysis / traces / gtftrace ------------------------ GTFTRACE DISPLAY PARAMETERS -------------------------- COMMAND ==> Start time ==> (DDD,HH.MM.SS) Stop time ==> (DDD,HH.MM.SS) GMT/LOCAL ==> (G or L, GMT is default) BEGIN ==> (O = oldest, F = first) User exit ==> EOF ==> Dsname ==> DDname ==> To select any of the following record types enter any character: CCW ==> DSP ==> EXT ==> IO ==> IOX ==> PI ==> RNIO ==> RR ==> SLIP ==> SRM ==> SSCH ==> SVC ==> SYS ==> USR ==> To specify values for the following filtering options enter any character: ASCBs ==> ASIDs ==> CICS ==> CPU# ==> JOBs ==> SYSN ==> To specify filtering options for the following records enter any character: IO ==> PI ==> SSCH ==> SSCHIO ==> SVC ==> USR ==> GTF S = start GTF. R = reset all fields. END/PF3 = terminate GTF. F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    45. IPCS Utility --------------------------------- IPCS UTILITY MENU -------------------------- OPTION ===> ******************** 1 COPYDDIR - Copy dump directory data * USERID - R1921 2 COPYDUMP - Copy a dump data set * DATE - 02/05/08 3 COPYTRC - Copy trace data * JULIAN - 02.128 4 DSLIST - Process list of data set names * TIME - 18:09 5 DAE - Process DAE data * PREFIX - R1921 * TERMINAL- 3278 Enter END command to terminate * PF KEYS - 24 ******************** F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    46. IPCS inventory IPCS INVENTORY - R1921.#IPCS.VR1921.DEBUG ------------------------------------- Command ===> SCROLL ===> CSR AC Dump Source Status DSNAME('TSTSS.DS0400.D020507.T163721.BCKCPS2H.S00007') . . . . . OPEN Title=IEC999I IFG0RR0A,........,BCKCPS2H,BCHX2PRD,WORKAREA = 936B40 Psym=RIDS/IDA0192A#L RIDS/IDA0557A AB/S00C4 RIDS/IDAOCEA1#R VALU/H100C4710 R **************************** END OF IPCS INVENTORY **************************** F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    47. IPCS submit ------------------- IPCS MVS DUMP BATCH JOB OPTION MENU -------------------- OPTION ===> ******************** 1 SADUMP - Prepare stand alone dump for analysis * USERID - R1921 2 SVCDUMP - Prepare SVC dump for analysis * DATE - 02/05/08 3 SYSMDUMP - Prepare SYSMDUMP for analysis * JULIAN - 02.128 4 SUPPLEMENT - Perform supplementary dump analysis * TIME - 18:13 5 EREP - Process software data using EREP * PREFIX - R1921 * TERMINAL- 3278 JOB STATEMENT INFORMATION: (Verify before proceeding) * PF KEYS - 24 ******************** ===> ===> ===> ===> ===> ===> Enter END to terminate batch job processing. F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    48. IPCS command ------------------------- IPCS Subcommand Entry ------------------------------- Enter a free-form IPCS subcommand or a CLIST or REXX exec invocation below: ===> ----------------------- IPCS Subcommands and Abbreviations -------------------- ADDDUMP | DROPDUMP, DROPD | LISTMAP, LMAP | RUNCHAIN, RUNC ANALYZE | DROPMAP, DROPM | LISTSYM, LSYM | SCAN ARCHECK | DROPSYM, DROPS | LISTUCB, LISTU | SELECT ASCBEXIT, ASCBX | EQUATE, EQU, EQ | LITERAL | SETDEF, SETD ASMCHECK, ASMK | FIND, F | LPAMAP | STACK CBFORMAT, CBF | FINDMOD, FMOD | MERGE | STATUS, ST CBSTAT | FINDUCB, FINDU | NAME | SUMMARY, SUMM CLOSE | GTFTRACE, GTF | NAMETOKN | SYSTRACE COPYDDIR | INTEGER | NOTE, N | TCBEXIT, TCBX COPYDUMP | IPCS HELP, H | OPEN | VERBEXIT, VERBX COPYTRC | LIST, L | PROFILE, PROF | WHERE, W CTRACE | LISTDUMP, LDMP | RENUM, REN | F1=HELP F2=SPLIT F3=END F4=RETURN F5=RFIND F6=RCHANGE F7=UP F8=DOWN F9=SWAP F10=LEFT F11=RIGHT F12=RETRIEVE

    49. Why IPCS ? XA 2.2 ESM SYSUDUMP limitations TCB chain Cross TCB memory CICS / Batch
